OBJECTIVE—In some studies intensive diabetes treatment in patients with type 2 diabetes may be associated with increased cardiovascular events. It is not clear whether these events are related to hypoglycemic episodes. To determine whether episodes of hypoglycemia were more likely to be associated with cardiac ischemia than normoglycemia or hyperglycemia, we carried out a study in 21 patients with coronary artery disease (CAD) and type 2 diabetes treated with insulin who had good glycemic control.

RESEARCH DESIGN AND METHODS—We carried out 72-h continuous glucose monitoring along with simultaneous cardiac Holter monitoring for ischemia. Patients also recorded symptoms of cardiac ischemia (chest pain) and symptoms of hypoglycemia.

RESULTS—Satisfactory continuous glucose monitoring system recordings were obtained in 19 patients. We recorded 54 episodes of hypoglycemia (blood glucose <70 mg/dl; 26 of these were symptomatic) and 59 episodes of hyperglycemia (blood glucose >200 mg/dl; none symptomatic). Of the 54 episodes of hypoglycemia, 10 were associated with symptoms of chest pain, during 4 of which electrocardiographic abnormalities were documented. In contrast, only 1 episode of chest pain occurred during 59 episodes of hyperglycemia. No chest pain or electrocardiographic abnormalities occurred when the blood glucose was within the normal range. The difference between the frequency of ischemia during hypoglycemia and the frequency during both hyperglycemia and normoglycemia was statistically significant (P < 0.01). There were 50 episodes during which the blood glucose changed by >100 mg over a 60-min period, and ischemic symptoms occurred during 9 of these episodes (P < 0.01 compared with stable normoglycemia or hyperglycemia).

CONCLUSIONS—Hypoglycemia is more likely to be associated with cardiac ischemia and symptoms than normoglycemia and hyperglycemia, and it is particularly common in patients who experience considerable swings in blood glucose. These data may be important in the institution of insulin treatment and attempting near-normal glycemia in patients with known CAD. Further research is needed to determine strategies to prevent ischemia associated with hypoglycemia.

Diabetes is associated with an increased risk of development of coronary artery disease (CAD). Pa-tients with CAD and diabetes have higher mortality and morbidity than patients without diabetes. Data from studies such as the U.K. Prospective Diabetes Study suggest that very good glycemic control is associated with fewer cardiovascular events (1). However, tight glycemic control may increase the risk of hypoglycemia. Increased cardiovascular events were noted in the Veterans Affairs Cooperative Study on Glycemic Control and Complications (VA CSDM), after the institution of tight glycemic control (2). It is possible that acute hypoglycemia may trigger ischemia and cardiovascular events. Hypoglycemia and rapid changes in blood glucose have been shown to increase counterregulatory hormones such as epinephrine and norepinephrine, which may induce vasoconstriction, platelet aggregation, and thereby ischemia (3,4). Furthermore, in the presence of hypokalemia and raised serum catecholamines, often present during hypoglycemia, cardiac repolarization could be prolonged enough to induce cardiac arrythmias (5). Animal studies have documented the effect of hypoglycemia on myocardial ischemic injury (6). Although the literature is replete with anecdotal cases of hypoglycemia-triggered cardiac events, it has previously been difficult to document an association between hypoglycemia and cardiac ischemia in humans (7,8).

Several studies have documented electrocardiogram (ECG) changes, especially an increased QT interval and a pro-arrhythmic state in acutely induced hypoglycemia in both type 1 and type 2 diabetes (9). However, these were not in ambulatory patients with known CAD and were not specific for cardiac ischemia (10,11)

With the availability of a continuous glucose sensor, combined with continuous ECG monitoring, new technologies make it possible to examine relationships between hypoglycemia and cardiac ischemia (12,13). We therefore conducted this study to determine the feasibility of simultaneous monitoring of ECG and blood glucose and to determine whether an association exists between changes in the two parameters

Patient characteristics

A total of 21 patients were enrolled, and 19 completed the study. Two patients were not able to successfully use the continuous glucose monitoring system (CGMS). The study included patients with type 2 diabetes with a history of frequent hypoglycemia and an HbA1c of <8%. Patients had CAD defined as a history of myocardial infarction, coronary bypass surgery, or angioplasty. The group consisted of 12 men and 7 women, with a mean age of 58 ± 16 years. The HbA1c (means ± SE) was 7.1 ± 0.8%. Total cholesterol, LDL, HDL, and triglyceride levels were 160 ± 31, 95 ± 28, 36 ± 13, and 186 ± 95 mg/dl, respectively. Eight patients had coronary artery bypass grafts alone; six patients had percutaneous, transfemoral coronary angiography alone; and five patients had both procedures. The mean duration of known diabetes 12.9 ± 5.6 years, and the average age at diagnosis was 50.4 + 7.1 years. All patients were being treated with insulin, and six patients were treated with metformin in addition to insulin. Patients were taking either bedtime NPH (n = 5) or twice-daily NPH (n = 14) insulin. None of the patients adjusted their insulin doses based on glucose readings. A total of 15 patients were on β-blockers (Table 1).

Methods

An ECG (supine position) and cutaneous blood glucose were obtained at baseline. Patients were excluded if the baseline ECG had one of the following: voltage criteria for LVH with >0.1 mv of ST-segment depression, an abnormal baseline ST-segment depression of >0.1 mv, Wolff-Parkinson-White syndrome, and digoxin use with baseline abnormal repolarization in the ST-segment. A GE/Marquette Holter system was used to monitor for cardiac ischemia, and a CGMS (Minimed, CA) was placed on the patient simultaneously. Patients were instructed and trained on the use of the CGMS and Holter monitor for ∼1 h. Patients were instructed to monitor their capillary blood glucoses at least four times a day and if they were aware of hypoglycemia. Continuous glucose and cardiac ischemia monitoring was performed over a period of 72 h. Patients were also asked to record symptoms of typical chest pain and hypoglycemia separately over the 72-h period. Patients were encouraged to maintain their usual daily activities at home during this monitoring period. Patients were also asked to record their meal and exercise timings.

At the end of the testing period of 72 h, the Holter monitor and CGMS were removed. Holter tracings and ECGs were read by a cardiologist, and glucose monitoring results were read by an endocrinologist, both blinded to each others results. The entire 72 h of the CGMS recording was used. Significant ischemic changes were defined as a transient horizontal or down-sloping ST-depression ≥0.1 mv, measured 80 ms after the J point, lasting for at least 1 min. ST-segment elevations were evaluated similarly, except in leads with pathological Q waves (14). Blood glucose values of <70 mg/dl were considered to be hypoglycemia, and >200 mg/dl was considered to be hyperglycemia. Insulin secretion decreases as plasma glucose levels fall within the physiological range, and counterregulatory hormone secretion increases as plasma glucose levels fall just below the physiological range at substantially higher glucose levels than those required to produce symptoms and impair cognitive function (1518). Thus, it is appropriate to define “hypoglycemia” as a blood glucose level <70 mg/dl in a study such as this one. Changes in blood glucose >100 mg/dl within a 60-min period were also noted.

Statistical analysis

Hypoglycemic and hyperglycemic episodes were compared with episodes of cardiac ischemia or ECG abnormalities. Hypoglycemic and hyperglycemic episodes occurring within the preceding 30 min of an ischemic event were noted. Symptoms of typical chest pain were similarly compared with both blood glucose levels and ECG abnormalities. Rapid changes in blood glucose were also compared with ECG changes. Statistical analysis was performed using the Yates-corrected χ2 test.

A total of 54 episodes of hypoglycemia (CGMS glucose <70 mg/dl) were recorded. Patients reported symptoms of hypoglycemia in 26 of the 54 episodes. Patients also reported chest pain in 10 of 54 hypoglycemic episodes. Of these 10 chest pain episodes, 4 were associated with significant ECG abnormalities (Table 2). Hyperglycemia (CGMS glucose >200 mg/dl) occurred a total of 59 times. Of these 59 episodes, only one patient reported chest pain, and there were no ECG abnormalities.

There were 50 episodes during which the CGMS glucose changed rapidly, i.e., by >100 mg/dl over a 60-min period. All of these episodes were associated with a rapid fall in glucose concentrations, rather than a rapid rise. Of these 50 episodes, patients reported chest pain in 9 episodes, 2 of which were associated with ECG abnormalities. There were no episodes of chest pain or ECG changes during normoglycemia. There were 28 episodes of recorded asymptomatic hypoglycemia, of which 2 episodes showed ECG abnormalities (Table 2).

The difference between the frequency of ischemia during hypoglycemia and the frequency during both hyperglycemia and normoglycemia was statistically significant (P < 0.01). The difference between the frequency of ischemic episodes with rapid glucose changes (>100 mg · dl−1 · h−1) and with both hyperglycemia and normoglycemia was also statistically significant (P < 0.01).

The mean number of episodes of hypoglycemia was 3.2 + 1.6, and the mean number of episodes of rapid changes was 3.8 + 2.1. The average time spent in hypoglycemia was 3.01 + 0.5 h, the time in hyperglycemia was 6.44 + 0.92 h, and the time in normoglycemia was 61.72 + 5.6 h (Table 1). Only two episodes of hypoglycemia were related to exercise, and neither were associated with chest pain or ischemia on the Holter monitor.

Out-of-hospital ambulatory Holter monitoring of ST-segment abnormalities in patients with CAD has shown that most ischemic events occur during activities of daily living (12). Patients with CAD and diabetes have more episodes of silent ischemia than patients without diabetes (19). Although angina is usually recognized as the cardinal symptom of underlying CAD, silent ischemia is actually the most common manifestation of myocardial ischemia (20,21). The presence of silent ischemia is predictive of future cardiac events and cardiovascular mortality (22). Several studies have shown that hypoglycemia predisposes to cardiac arrhythmias, although these findings were not specific for ischemia (10,11). These studies were not performed in patients with known CAD. Koh et al. (23) have shown that in patients with CAD who did not have diabetes, typical ECG changes of ischemia were present during hypoglycemia. Animal and some human studies have showed that hypoglycemia may increase the size of the infarct in myocardial infarction (68). Elderly patients are especially vulnerable to the cardiac effects of hypoglycemia.

There is scant evidence to either support or negate the relationship between cardiac ischemia and hypoglycemia. This may be due to the past lack of availability of adequate technology. Our results show that some patients with diabetes have definite ECG abnormalities during hypoglycemia suggestive of cardiac ischemia. Some of these patients had typical chest pain, whereas some were asymptomatic. It is estimated that ∼30% of patients with CAD will have silent ischemia by Holter monitoring (24). However, Holter monitoring is not particularly sensitive for cardiac ischemia and may therefore underestimate the prevalence of cardiac ischemia during hypoglycemia (25,26).

Rapid drops in glucose levels, even when within the normal range, were associated with increased episodes of chest pain and ECG abnormalities. Catecholamine release and increased myocardial work and oxygen consumption has been shown to occur with hypoglycemia and rapid falls in blood glucose (6,27). However, the degree of catecholamine response is related to the nadir plasma glucose concentration. Therefore, the relevance of the association of chest pain with rapid decrements in subcutaneous glucose is unclear (28).

Many of the episodes of hypoglycemia were asymptomatic, suggesting hypoglycemia unawareness in these patients. Several studies have documented impaired counterregulatory hormone release associated with hypoglycemia unawareness (17). In a study in patients with type 1 diabetes without CAD, Young et al. (29) demonstrated that myocardial adaptation to hypoglycemia is impaired during hypoglycemia. Their hypothesis was that the lack of adequate catecholamine release leads to a decrease in the normal augmentation of myocardial function during hypoglycemia. However, several studies have shown that the catecholamine response in type 2 diabetes is adequate (30,31). Other possible mechanisms include abnormal intracellular metabolism or abnormal endothelial responses to stress in patients such as ours who have type 2 diabetes and established coronary disease. Many of our patients were on β-blockers, which may mask the catecholamine-induced symptoms. Because many patients with type 2 diabetes and coexistent CAD may be on β-blockers and may not recognize hypoglycemia, studies in such a patient population are important. β-Blockers may also decrease the number of ischemic events than would normally be present during hypoglycemic episodes. The time spent in hypoglycemia was far shorter than that spent in hyperglycemia or normoglycemia. Despite this, the number of ischemic events occurred almost exclusively during this short time period.

In six of the episodes with chest pain and glucose concentrations <70 mg/dl, there were no ECG changes, a finding compatible with other studies in patients with known CAD. In a study of 63 patients with documented CAD, only 33% of the reported anginal chest pain was associated with ischemic ST depression (32). Myocardial ischemia can occur without ST-segment shift, as documented by evidence of left ventricular abnormalities. In 119 patients who underwent exercise echocardiography, 74% of them developed angina during exercise, but only 53% developed ST-segment depression (33).

Further studies are needed to understand the mechanisms involved so that strategies can be developed to minimize such events, thus rendering intensive insulin therapy safer in such patients.

The CGMS has limitations, particularly because it measures interstitial fluid rather than blood glucose. Nevertheless, studies suggest that the CGMS is able to accurately track acute changes in plasma glucose when calibrated across a range of plasma glucose and insulin levels (34). However, this accuracy diminishes toward the 40-mg/dl glucose level and may give false readings below this level (35).

We conclude that hypoglycemia is more likely to be associated with cardiac ischemia than are hyperglycemia and normoglycemia. These data may be important in the institution of insulin treatment and attempting near-normal glucose levels in patients with known CAD. However, this association does not prove a causal relationship between hypoglycemia and myocardial ischemia in patients with type 2 diabetes and CAD. Further research involving larger numbers of subjects is needed to determine strategies to prevent ischemia associated with hypoglycemia.

Table 1—

Patient characteristics and CGMS features

ParameterValue
Mean duration of known diabetes (years) 12.9 ± 5.6
Mean age at diagnosis of diabetes (years) 50.4 ± 7.1
Number of patients taking β-blockers 15
Number of patients with known neuropathy 10
Mean episodes of hypoglycemia per patient (mg/dl) 3.2 ± 1.6
Mean episodes of rapid glucose changes per patient (mg/dl) 3.8 ± 2.1
Mean duration of hypoglycemia per patient (h) 3.01 ± 0.5
Mean duration of hyperglycemia per patient (h) 6.44 ± 0.92
Mean duration of normoglycemia per patient (h) 61.72 ± 5.6
Mean depth of hypoglycemia per patient (mg/dl) 50.1 ± 7.6
ParameterValue
Mean duration of known diabetes (years) 12.9 ± 5.6
Mean age at diagnosis of diabetes (years) 50.4 ± 7.1
Number of patients taking β-blockers 15
Number of patients with known neuropathy 10
Mean episodes of hypoglycemia per patient (mg/dl) 3.2 ± 1.6
Mean episodes of rapid glucose changes per patient (mg/dl) 3.8 ± 2.1
Mean duration of hypoglycemia per patient (h) 3.01 ± 0.5
Mean duration of hyperglycemia per patient (h) 6.44 ± 0.92
Mean duration of normoglycemia per patient (h) 61.72 ± 5.6
Mean depth of hypoglycemia per patient (mg/dl) 50.1 ± 7.6

Data are means ± SD.

Table 2—

CGMS and Holter monitoring abnormalities

Total episodesEpisodes with chest pain/anginaEpisodes with ECG abnormalities
Hypoglycemia 54 10* 6*
 Symptomatic 26 10* 4*
 Asymptomatic 28 —
Normoglycemia without rapid changes N/A
Hyperglycemia 59
Rapid changes in glucose (>100 mg · dl−1 · h−150 9*
Total episodesEpisodes with chest pain/anginaEpisodes with ECG abnormalities
Hypoglycemia 54 10* 6*
 Symptomatic 26 10* 4*
 Asymptomatic 28 —
Normoglycemia without rapid changes N/A
Hyperglycemia 59
Rapid changes in glucose (>100 mg · dl−1 · h−150 9*
*

P < 0.01 vs. episodes during hyperglycemia and normoglycemia.

This study was supported in part by National Institutes of Health Grant 5M01RR05096 from the Division of Research Resources. Diabetes research at Tulane University Health Sciences Center was supported in part by the John C. Cudd Memorial fund and the Tullis-Tulane Alumni Chair in Diabetes.

We thank Minimed for the loan of the CGMS system and the gift of sensors.

1.
United Kingdom Prospective Diabetes Study Group: United Kingdom Prospective Diabetes Study 24: a 6-year, randomized, controlled trial comparing sulfonylurea, insulin, and metformin therapy in patients with newly diagnosed type 2 diabetes that could not be controlled with diet therapy.
Ann Intern Med
128
:
165
–175,
1998
2.
Abraira C, Colwell JA, Nuttall FQ, Sawin CT, Nagel NJ, Comstock JP, Emanuele NV, Levin SR, Henderson W, Lee HS: Veterans Affairs Cooperative Study on glycemic control and complications in type II diabetes (VA CSDM): results of the feasibility trial: Veterans Affairs Cooperative Study in Type II Diabetes.
Diabetes Care
18
:
1113
–1123,
1995
3.
DeFronzo RA, Hendler R, Christensen N: Stimulation of counterregulatory hormonal responses in diabetic man by a fall in glucose concentration.
Diabetes
29
:
125
–131,
1980
4.
Galassetti P, Davis SN: Effects of insulin per se on neuroendocrine and metabolic counter-regulatory responses to hypoglycaemia.
Clin Sci (Lond)
99
:
351
–362,
2000
5.
Heller SR: Abnormalities of the electrocardiogram during hypoglycaemia: the cause of the dead in bed syndrome?
Int J Clin Pract Suppl
129
:
27
–32,
2002
6.
Libby P, Maroko PR, Braunwald E: The effect of hypoglycemia on myocardial ischemic injury during acute experimental coronary artery occlusion.
Circulation
51
:
621
–626,
1975
7.
Bansal S, Toh SH, LaBresh KA: Chest pain as a presentation of reactive hypoglycemia.
Chest
84
:
641
–642,
1983
8.
Pladziewicz DS, Nesto RW: Hypoglycemia-induced silent myocardial ischemia.
Am J Cardiol
63
:
1531
–1532,
1989
9.
Marques JL, George E, Peacey SR, Harris ND, Macdonald IA, Cochrane T, Heller SR: Altered ventricular repolarization during hypoglycaemia in patients with diabetes.
Diabet Med
14
:
648
–654,
1997
10.
Lindstrom T, Jorfeldt L, Tegler L, Arnqvist HJ: Hypoglycaemia and cardiac arrhythmias in patients with type 2 diabetes mellitus.
Diabet Med
9
:
536
–541,
1992
11.
Landstedt-Hallin L, Englund A, Adamson U, Lins PE: Increased QT dispersion during hypoglycaemia in patients with type 2 diabetes mellitus.
J Intern Med
246
:
299
–307,
1999
12.
Kennedy HL, Wiens RD. Ambulatory (Holter) electrocardiography and myocardial ischemia.
Am Heart J
117
:
164
–176,
1989
13.
Gross TM, Bode BW, Einhorn D, Kayne DM, Reed JH, White NH, Mastrototaro JJ: Performance evaluation of the MiniMed continuous glucose monitoring system during patient home use.
Diabetes Technol Ther
2
:
49
–56,
2000
14.
Amanullah AM, Lindvall K: Prevalence and significance of transient–predominantly asymptomatic–myocardial ischemia on Holter monitoring in unstable angina pectoris, and correlation with exercise test and thallium-201 myocardial perfusion imaging.
Am J Cardiol
72
:
144
–148,
1993
15.
Cryer PE: Hierarchy of physiological responses to hypoglycemia: relevance to clinical hypoglycemia in type I (insulin dependent) diabetes mellitus.
Horm Metab Res
29
:
92
–96,
1997
16.
Cryer PE: Symptoms of hypoglycemia, thresholds for their occurrence, and hypoglycemia unawareness.
Endocrinol Metab Clin North Am
28
:
495
–500, v-vi, 1999
17.
Davis SN, Goldstein RE, Price L, Jacobs J, Cherrington AD: The effects of insulin on the counterregulatory response to equivalent hypoglycemia in patients with insulin-dependent diabetes mellitus.
J Clin Endocrinol Metab
77
:
1300
–1307,
1993
18.
Davis SN, Shavers C, Collins L, Cherrington AD, Price L, Hedstrom C: Effects of physiological hyperinsulinemia on counterregulatory response to prolonged hypoglycemia in normal humans.
Am J Physiol
267
:
E402
–E410,
1994
19.
Nesto RW, Phillips RT, Kett KG, Hill T, Perper E, Young E, Leland OS Jr: Angina and exertional myocardial ischemia in diabetic and nondiabetic patients: assessment by exercise thallium scintigraphy.
Ann Intern Med
108
:
170
–175,
1988
20.
Deedwania PC, Carbajal EV: Silent myocardial ischemia: a clinical perspective.
Arch Intern Med
151
:
2373
–2382,
1991
21.
Deanfield JE, Shea M, Ribiero P, de Landsheere CM, Wilson RA, Horlock P, Selwyn AP: Transient ST-segment depression as a marker of myocardial ischemia during daily life.
Am J Cardiol
54
:
1195
–1200,
1984
22.
Deedwania PC, Carbajal EV: Silent ischemia during daily life is an independent predictor of mortality in stable angina.
Circulation
81
:
748
–756,
1990
23.
Koh H, Nambu S, Tsushima M, Nishioheda Y, Murakami K, Ikeda M: The effects of insulin on the cardiovascular system in patients with coronary heart disease.
Arzneimittelforschung
34
:
185
–190,
1984
24.
Rogers WJ, Bourassa MG, Andrews TC, Bertolet BD, Blumenthal RS, Chaitman BR, Forman SA, Geller NL, Goldberg AD, Habib GB, et al: Asymptomatic Cardiac Ischemia Pilot (ACIP) study: outcome at 1 year for patients with asymptomatic cardiac ischemia randomized to medical therapy or revascularization: the ACIP Investigators.
J Am Coll Cardiol
26
:
594
–605,
1995
25.
Nair CK, Khan IA, Esterbrooks DJ, Ryschon KL, Hilleman DE: Diagnostic and prognostic value of Holter-detected ST-segment deviation in unselected patients with chest pain referred for coronary angiography: a long-term follow-up analysis.
Chest
120
:
834
–839,
2001
26.
Tzivoni D: Value and limitations of ambulatory ECG monitoring for assessment of myocardial ischemia.
Ann Noninvasive Electrocardiol
6
:
236
–242,
2001
27.
Tremblay A, Pinsard D, Coveney S, Catellier C, Laferriere G, Richard D, Nadeau A: Counterregulatory response to insulin-induced hypoglycemia in trained and nontrained humans.
Metabolism
39
:
1138
–1143,
1990
28.
Amiel SA, Simonson DC, Tamborlane WV, DeFronzo RA, Sherwin RS: Rate of glucose fall does not affect counterregulatory hormone responses to hypoglycemia in normal and diabetic humans.
Diabetes
36
:
518
–522,
1987
29.
Russell RR 3rd, Chyun D, Song S, Sherwin RS, Tamborlane WV, Lee FA, Pfeifer MA, Rife F, Wackers FJ, Young LH: Cardiac responses to insulin-induced hypoglycemia in nondiabetic and intensively treated type 1 diabetic patients.
Am J Physiol Endocrinol Metab
281
:
E1029
–E1036,
2001
30.
de Galan BE, Hoekstra JB: Glucose counterregulation in type 2 diabetes mellitus.
Diabet Med
18
:
519
–527,
2001
31.
Miller CD, Phillips LS, Ziemer DC, Gallina DL, Cook CB, El-Kebbi IM: Hypoglycemia in patients with type 2 diabetes mellitus.
Arch Intern Med
161
:
1653
–1659,
2001
32.
Krantz DS, Hedges SM, Gabbay FH, Klein J, Falconer JJ, Merz CN, Gottdiener JS, Lutz H, Rozanski A: Triggers of angina and ST-segment depression in ambulatory patients with coronary artery disease: evidence for an uncoupling of angina and ischemia.
Am Heart J
128
:
703
–712,
1994
33.
Beleslin BD, Ostojic M, Stepanovic J, Djordjevic-Dikic A, Stojkovic S, Nedeljkovic M, Stankovic G, Petrasinovic Z, Gojkovic L, Vasiljevic-Pokrajcic Z, et al: Stress echocardiography in the detection of myocardial ischemia: head-to-head comparison of exercise, dobutamine, and dipyridamole tests.
Circulation
90
:
1168
–1176,
1994
34.
Monsod TP, Flanagan DE, Rife F, Saenz R, Caprio S, Sherwin RS, Tamborlane WV: Do sensor glucose levels accurately predict plasma glucose concentrations during hypoglycemia and hyperinsulinemia?
Diabetes Care
25
:
889
–893,
2002
35.
McGowan K, Thomas W, Moran A: Spurious reporting of nocturnal hypoglycemia by CGMS in patients with tightly controlled type 1 diabetes.
Diabetes Care
25
:
1499
–1503,
2002

Address correspondence and reprint requests to Vivian Fonseca, Professor of Medicine, Department of Medicine, Section of Endocrinology, 1430 Tulane Ave., SL 53, New Orleans, LA 70112-2699. E-mail: vfonseca@tulane.edu.

Received for publication 21 November 2002 and accepted in revised form 1 February 2003.

A table elsewhere in this issue shows conventional and Système International (SI) units and conversion factors for many substances.
