Charcot neuroarthropathy is defined by painful or relatively painless bone and joint deformity in limbs that have lost sensory innervation (1). The incidence is ∼0.1–5% in diabetic patients with peripheral neuropathy (2,3). The pathogenesis of Charcot neuroarthropathy is unknown (1,4). In acute Charcot neuroarthropathy, osteoclast activity increases (5). Alendronate is a bisphosphonate that induces the apoptosis of the osteoclasts (6). The utilization of the alendronate could improve the clinical signs of acute Charcot neuroarthropathy and stop bone reabsorption.

A total of 20 consecutive patients with a new diagnosis of acute painful Charcot neuroarthropathy were enrolled after the approval of the ethics committee. The patients gave informed consent. Acute Charcot neuroarthropathy was defined on the basis of at least three of the following clinical signs: edema, erythema, and skin temperature increase of 2°C compared with contralateral foot (temperature was measured using an infrared thermometer [Riester] at the site of the maximum deformity of the affected foot and on a similar site on the contralateral foot), deformity, tenderness, abnormal motility, and palpatory crunches.

According to a blinded randomization, 11 patients, who were treated with 70 mg alendronate by mouth once a week (test group), and 9 control subjects were followed for 6 months. All patients received a total contact cast boot for the first 2 months and pneumatic walker for the other 4 months and were examined twice a week (7). Afterward they were transferred to special shoes. Baseline levels of pain were recorded by using 10-cm visual analog scales (VASs), where 0 was minimal and 10 was maximal pain. Repeat VASs of pain were performed after 6 months. X-rays of the affected feet were taken in two different projections, according to the protocol described by Cavanagh et al. (8). A labeled white cell (In-WBC) bone scan combined with a three-phase technetium bone scan (Tc-MDP) and with magnetic resonance of the foot (9) were done to obtain a differential diagnosis with osteomyelitis.

Serum collagen COOH-terminal telopeptide of type 1 collagen (ICTP), osteocalcin, testosterone, estradiol, thyroid hormones, parathyroid hormone, follicle-stimulating hormone, and leutinizing hormone were measured in serum by immunoassay in eletrochemiluminescence (Roche, Montclair, NJ).

IGF-1 and calcitriol were measured by chemiluminescence (Nichols), estron by immunoradiometric assay (Immunotech Beckman, Fullerton, CA), and urinary hydroxyprolin through high-performance liquid chromatography (Biorad, Richmond, CA) from 24-h urine collection.

Serum alkaline phosphatase was measured by colorimetric assay (Roche-Hitachi) and serum bone alkaline phosphatase by electrophoretic method (Isopal Sebia ITA). Bone mineral density (BMD) measurements of the lumbar spine (L2-L4), proximal femur, and feet were performed by dual-energy X-ray absorptiometry using a Hologic QDR 2000 densitometer. The affected foot was manually positioned on the scan table and the scan started at the toes and moved toward calcaneus. The software used for the lumbar spine was automatically applied to the foot scan. Determination of size and location of the region of interest (phalanx, tarsus, or metatarsus) was made manually, and the measure of the BMD of the single region of interest was defined automatically by the spinal software. Reproducibility was assessed by taking 10 repeated measurements; the foot was moved and repositioned between measurements. ANOVA was used to compare the test group and the control group. Significance was set at P < 0.05.

All patients had a Neuropathy Disability Score >5 (10), a pathological conduction velocity, a vibration perception threshold >25 volts (11), and an autonomic neuropathy according to Ewing and Clarke with a score >4 (12). No subjects had osteomyelitis or peripheral vascular disease (defined as an ankle-brachial index of <0.9) throughout the study (Table 1). The midfoot was the most affected. Five patients had uninfected foot ulcers (cultures of debrided tissue were always negative) that healed during the study.

ICTP did not show significant difference between the two groups (0.54 ± 0.05 vs. 0.56 ± 0.06 ng/ml, P < 0.6) at the outset, but after 6 months, the test group showed a significant decrease (0.54 ± 0.05 vs. 0.30 ± 0.03 ng/ml, P < 0.05). In the test group, hydroxyprolin followed the same trend (18 ± 3.2 vs. 13 ± 3.6 mg/l, P < 0.05). Bone alkaline phosphatase reduction was almost significant (36 ± 4.8 vs. 23 ± 3.9%, P = 0.06). Dual-energy X-ray absorptiometry demonstrated an improvement in total foot mineralization (0.18 ± 0.06 vs. 0.24 ± 0.08 g/cm2, P < 0.05) and in the distal phalanxes (0.194 ± 0.03 vs. 0.242 ± 0.05 g/cm2, P < 0.01) in the test group that had an improvement of the mineralization of the femur. VAS score for pain was significantly improved in the test group (6.5 ± 0.9 vs. 4.2 ± 0.8, P < 0.05). No significant changes were evident in the control group (6.7 ± 1 vs. 6.1 ± 1.1).

At the outset, the affected foot was 3.6 ± 1.1°C hotter in the test group and 3.4 ± 1.2°C hotter in the control group. After 6 months, both groups had a significant improvement (−1.7°C in the test group and −1.5°C in the control group). Reduction of IGF-1 was observed only in the test group (142.8 ± 24 vs. 123.5 ± 41 ng/ml, P < 0.05). No side effects were reported.

This study is based on the utilization of alendronate taken by mouth to stop the progression of Charcot neuroarthropathy (13). After 6 months, we showed that there is a significant reduction of ICTP and hydroxyprolin, markers indicative of bone reabsorption. The test group showed an increase of the foot bone density compared with the control group that was more evident in the distal phalanxes, which were the foot bones with the lowest BMD, than in the midfoot. We suppose that bisphosphonates are more effective where bone reabsorbtion is more marked. The significant reduction of IGF-1 levels in the test group could improve bone density, lowering the blood supply to bones (14).

Off-loading, which reduces inflammation, together with alendronate, which decreases the cytokine production within the bones of the foot, could explain the reduction of pain (15,16). Furthermore, bisphosphonates have a central antinociceptive effect connected with the Ca2+ mechanism. Ca influx releases substances involved in nociception and inflammation, such as substance P, vasoactive intestinal peptide, neuropeptide Y, prostaglandin, serotonin, and kinines (1719). We did not detect the initial fall of the temperature linked to the bisphosphonates because we checked it at the beginning and end of the study (20). In conclusion, we observed a clinical improvement of acute Charcot neuroarthropathy by using alendronate.

Table 1—

Test group results

At the outsetAfter 6 months
ICTP (ng/ml) 0.56 ± 0.06 0.30 ± 0.03
Urinary hydroxyprolin (mg/l) 18 ± 3.2 13 ± 3.6
BMD foot (g/cm20.18 ± 0.06 0.24 ± 0.08
BMD distal phalanxes (g/cm20.194 ± 0.03 0.242 ± 0.05
VAS pain score 6.5 ± 0.9 4.2 ± 0.8
IGF-1 (ng/ml) 142.8 ± 24 123.5 ± 41
At the outsetAfter 6 months
ICTP (ng/ml) 0.56 ± 0.06 0.30 ± 0.03
Urinary hydroxyprolin (mg/l) 18 ± 3.2 13 ± 3.6
BMD foot (g/cm20.18 ± 0.06 0.24 ± 0.08
BMD distal phalanxes (g/cm20.194 ± 0.03 0.242 ± 0.05
VAS pain score 6.5 ± 0.9 4.2 ± 0.8
IGF-1 (ng/ml) 142.8 ± 24 123.5 ± 41

Data are means ± SD.

1.
Edmonds ME: Progress in care of the diabetic foot.
Lancet
354
:
270
–272,
1999
2.
Sanders LJ, Frykberg RG: Diabetic neuropathic osteoarthropathy: Charcot foot. In
The High Risk Foot in Diabetes Mellitus
. Levin ME, O’Neal LW, Bowker JH, Eds. New York, Churchill Livingstone,
1991
, p.
297
–338
3.
Rajbhandari SM, Jenkins RC, Davies C, Tesfaye S: Charcot neuroarthropathy in diabetes mellitus.
Diabetologia
45
:
1085
–1096,
2002
4.
Frykberg RG, Kozak GP: The diabetic charcot foot. In
Management of Diabetic Foot Problems
. 2nd ed. Kozak GP, Campbell DR, Fryberg RG, Haberwshaw GM, Eds. Philadelphia, WB Saunders,
1995
,
88
–97
5.
Piaggesi A, Marcocci C, Golia F, Gregorio S, Baccetti F, Navalesi R: Markers for Charcot’s neurogenic osteoarthropathy in diabetic patients (Abstract).
Diabetes
49 (Suppl. 1)
:
A32
,
2000
6.
Rogers MJ: New insights into the molecular mechanism of action of bisphosphonate.
Curr Pharm Des
9
:
2643
–2658,
2003
7.
Armstrong DG, Tood WF, Lavery LA, Harkless LB, Bushmann TR: The natural history of acute Charcot’s arthropathy in a diabetic foot speciality clinic.
Diabet Med
14
:
357
–363,
1997
8.
Cavanagh PR, Young MJ, Adams JE, Vickers KL, Boulton AJM: Radiographic abnormalities in the feet of patients with diabetic neuropathy.
Diabetes Care
17
:
201
–209,
1994
9.
Tomas MB, Patel M, Marvin SE, Palestro CJ: The diabetic foot.
Br J Radiol
73
:
443
–450,
2000
10.
Young MJ, Boulton AJM, Macleod AF, Williamd DRR, Sonksen PK: A multicentre study of the prevalence of diabetic peripheral neuropathy in the UK hospital clinic population.
Diabetologia
36
:
150
–154,
1993
11.
MJ Young, Breddy JL, Veves A, Boulton AJM: The prediction of diabetic neuropathic foot ulceration using vibration perception thresholds: a prospective study.
Diabetes Care
17
:
557
–560,
1994
12.
Ewing DJ, Clarke BF: Diagnosis and management of diabetic autonomic neuropathy.
BMJ
285
:
916
–918,
1982
13.
Jude EB, Boulton AJ: Medical treatment of Charcot’s arthropathy.
J Am Podiatr Med Assoc
92
:
381
–383,
2002
14.
Kapitola J, Zak J, Lacinova Z, Justova V: Effect of growth hormone and pamidronate on bone blood flow, bone mineral and IGF-I levels in the rat.
Physiol Res
49 (Suppl. 1)
:
S101
–S106,
2000
15.
Mc Crory JL, Morag E, Norkitis AJ: Healing of Charcot fractures: skin temperature and radiographic correlates.
Foot
8
:
158
–165,
1998
16.
Haworth CD, Selby PL, Webb AK, Mawer EB, Adams JE, Freemont AJ: Severe bone pain after intravenous pamidronate in adult patients with cystic fibrosis.
Lancet
352
:
1753
–1754,
1998
17.
Bonabello A, Galmozzi MR, Bruzzese T, Zara GP: Analgesic effect of bisphosphonates in mice.
Pain
91
:
269
–275,
2001
18.
Carr DB, Goudas LC: Acute pain.
Lancet
353
:
2051
–2058,
1997
19.
Miranda HF, Bustamante D, Kramer V, Pelissier T, Saavedra H, Paeile C, Fernandez E, Pinardi G: Antinociceptive effects of Ca2+ channel blockers.
Eur J Pharmacol
217
:
137
–141,
1992
20.
Jude EB, Selby PL, Burgess J, Lilleystone P, Mawer EB, Page SR, Donohoe M, Foster AVM, Edmonds ME, Boulton AJM: Bisphosphonates in the treatment of Charcot neuroarthropathy: a double-blind randomised controlled trial.
Diabetologia
44
:
2032
–2037,
2001

D.P. and V.R. contributed equally to this work.

A table elsewhere in this issue shows conventional and Système International (SI) units and conversion factors for many substances.
