OBJECTIVE

To examine the prospective association of retinal vascular fractal dimension with diabetic retinopathy risk in young people with type 1 diabetes.

RESEARCH DESIGN AND METHODS

This was a hospital-based prospective study of 590 patients aged 12–20 years with type 1 diabetes free of retinopathy at baseline. All patients had seven-field retinal photographs taken of both eyes. Incident retinopathy was ascertained from retinal photographs taken at follow-up visits. Fractal dimension was measured from baseline photographs using a computer-based program following a standardized protocol.

RESULTS

Over a mean ± SD follow-up period of 2.9 ± 2.0 years, 262 participants developed mild nonproliferative diabetic retinopathy (15.0 per 100 person-years). After adjusting for age, sex, diabetes duration, A1C, and other risk factors, we found no association between retinal vascular fractal dimension and incident retinopathy.

CONCLUSIONS

Retinal vascular fractal dimension was not associated with incident early diabetic retinopathy in this sample of children and adolescents with type 1 diabetes.

Fractal objects are self-similar structures that retain a similar level of complexity across all scales. For example, blood vessels repeatedly subdivide downstream into smaller blood vessels with similar network patterns. Fractal dimension (Df) quantifies the degree of complexity into a single value and is particularly useful for quantifying non-Euclidean geometric shapes such as vascular networks. The retinal circulation is a fractal object (1,3), and fractal analysis has been used to study the embryological development of the retinal vasculature (2) and vascular changes associated with diabetic retinopathy (3,,,7). Variations in retinal vascular Df may reflect geometric alterations in the vascular network in response to hypoxia (2,7).

Earlier case-control studies showed that retinal vascular Df was associated with proliferative diabetic retinopathy (5,6), suggesting that neovascularization increases the complexity of the retinal vascular branching pattern. More recently, using a computer-based program to reliably measure Df of the retinal vasculature (8), we reported that retinal vascular Df was cross-sectionally associated with the prevalence of early retinopathy in patients with type 1 diabetes (9). However, prospective data are needed to elucidate the significance of this interesting finding. We therefore aimed to determine whether retinal vascular Df measured from baseline photographs of eyes without retinopathy is associated with subsequent risk of retinopathy development in a cohort of type 1 diabetic subjects.

The study participants were children and adolescents (aged 12–20 years) with type 1 diabetes managed at the Children's Hospital at Westmead, Sydney, Australia. The methodology of this study has been described previously (10,12). Type 1 diabetes was defined following the Australasian Pediatric Endocrine Group diabetes register and national guidelines. All participants had retinal photography and assessment at baseline (1990–2002) and had at least one follow-up assessment before reaching 20 years of age.

Stereoscopic retinal photographs of seven fields were taken of both eyes following a standardized protocol (10,12). Diabetic retinopathy was graded by an ophthalmologist masked to participants' characteristics following the Early Treatment Diabetic Retinopathy Study (ETDRS) adaptation of the modified Airlie House classification of diabetic retinopathy. Incident diabetic retinopathy was defined as ETDRS level 21 (minimal nonproliferative diabetic retinopathy) or greater at the follow-up visits in those free of diabetic retinopathy at baseline. We performed fractal analysis using ETDRS field one (centered on the optic disc) photographs and a computer-based program with a standardized protocol (8). Reproducibility of the measurements was high, with an intragrader intraclass correlation coefficient of 0.98. Retinal arteriolar and venular calibers were measured as described previously (13,15). Participants also underwent standardized interviews, clinical examinations, and laboratory investigations (10,12). All risk factors were collected at baseline.

Statistical analysis

Cox proportional hazards regression model was used to determine the hazard ratio (HR) for incident diabetic retinopathy in relation to Df. Three multivariable-adjusted models were constructed: model 1 adjusted for age and sex; model 2 adjusted additionally for other diabetic retinopathy risk factors; model 3 adjusted for all variables in model 2 plus retinal arteriolar or venular calibers, given their previously documented associations with diabetic retinopathy (13,15). Retinal vascular Df was categorized into quartiles. Eye-specific analyses, using data from the right eyes, were performed initially and then repeated using data from both eyes and generalized estimation equation models (SPSS version 16.1). With a sample of 590 subjects, our study has 80% power to detect a minimum HR of 1.5 for diabetic retinopathy by Df quartiles.

Of the 810 baseline participants, 807 were followed. We excluded patients with diabetic retinopathy at baseline (n = 136), with photographs of insufficient quality for analysis (n = 80), or with diabetic retinopathy assessment (n = 1), leaving 590 (72.8%) participants included. Baseline characteristics were similar between excluded and included participants (9).

The median Df was 1.462 (interquartile range [IQR] 1.450–1.472). Over a mean ± SD follow-up period of 2.9 ± 2.0 years, 262 (44%) developed diabetic retinopathy in one or both eyes, with an incidence of 15.0 per 100 person-years. All incident cases had mild nonproliferative diabetic retinopathy (ETDRS level ≤31). The median Df in participants with incident diabetic retinopathy (1.4597 [IQR 1.4485–1.4696]) was not significantly different from that of those without incident diabetic retinopathy (1.4613 [1.4479–1.4706]; P = 0.886). There was no significant association between retinal vascular Df and incident retinopathy after adjusting for covariables (Table 1).

Table 1

Relationship between retinal vascular Df and incident diabetic retinopathy

Retinal vascular DfnIncidence per 100 person-yearsModel 1*
Model 2
Model 3
HR (95% CI)PHR (95% CI)PHR (95% CI)P
Right eye only
    Quartile 1 (≤1.4497) 132 10.7 1.00 (Ref)  1.00 (Ref)  1.00 (Ref)
    Quartile 2 (1.4498–1.4628) 132 9.1 0.84 (0.56–1.26) 0.39 0.80 (0.52–1.21) 0.29 0.82 (0.53–1.26) 0.36
    Quartile 3 (1.4629–1.4738) 132 10.4 0.97 (0.65–1.46) 0.89 0.95 (0.62–1.45) 0.80 0.97 (0.63–1.49) 0.88
    Quartile 4 (≥1.4739) 133 10.3 0.95 (0.63–1.45) 0.82 0.90 (0.58–1.40) 0.64 0.93 (0.60–1.45) 0.75
    Ptrend    0.84  0.75  0.82
Right and left eyes combined§
    Quartile 1 (≤1.4471) 279 10.8 1.00 (Ref)  1.00 (Ref)  1.00 (Ref)
    Quartile 2 (1.4472–1.4598) 278 9.3 0.89 (0.67–1.18) 0.41 0.88 (0.65–1.19) 0.41 0.90 (0.66–1.21) 0.47
    Quartile 3 (1.4599–1.4730) 266 10.3 0.98 (0.74–1.30) 0.89 0.98 (0.73–1.32) 0.88 0.99 (0.73–1.33) 0.93
    Quartile 4 (≥1.4731) 257 9.5 0.91 (0.67–1.22) 0.52 0.92 (0.68–1.26) 0.92 0.95 (0.69–1.30) 0.74
    Ptrend    0.82  0.84  0.89
Retinal vascular DfnIncidence per 100 person-yearsModel 1*
Model 2
Model 3
HR (95% CI)PHR (95% CI)PHR (95% CI)P
Right eye only
    Quartile 1 (≤1.4497) 132 10.7 1.00 (Ref)  1.00 (Ref)  1.00 (Ref)
    Quartile 2 (1.4498–1.4628) 132 9.1 0.84 (0.56–1.26) 0.39 0.80 (0.52–1.21) 0.29 0.82 (0.53–1.26) 0.36
    Quartile 3 (1.4629–1.4738) 132 10.4 0.97 (0.65–1.46) 0.89 0.95 (0.62–1.45) 0.80 0.97 (0.63–1.49) 0.88
    Quartile 4 (≥1.4739) 133 10.3 0.95 (0.63–1.45) 0.82 0.90 (0.58–1.40) 0.64 0.93 (0.60–1.45) 0.75
    Ptrend    0.84  0.75  0.82
Right and left eyes combined§
    Quartile 1 (≤1.4471) 279 10.8 1.00 (Ref)  1.00 (Ref)  1.00 (Ref)
    Quartile 2 (1.4472–1.4598) 278 9.3 0.89 (0.67–1.18) 0.41 0.88 (0.65–1.19) 0.41 0.90 (0.66–1.21) 0.47
    Quartile 3 (1.4599–1.4730) 266 10.3 0.98 (0.74–1.30) 0.89 0.98 (0.73–1.32) 0.88 0.99 (0.73–1.33) 0.93
    Quartile 4 (≥1.4731) 257 9.5 0.91 (0.67–1.22) 0.52 0.92 (0.68–1.26) 0.92 0.95 (0.69–1.30) 0.74
    Ptrend    0.82  0.84  0.89

*Model 1 adjusted for age and sex.

†Model 2 adjusted for age, sex, diabetes duration, A1C, mean arterial blood pressure, BMI, and total cholesterol.

‡Model 3 adjusted for variables in model 2 as well as central retinal arteriolar equivalent and central retinal venular equivalent.

§Analysis performed using the generalized estimation equation model.

There has been increasing evidence showing structural retinal vascular changes associated with diabetic retinopathy (13,15). However, previous studies largely focused on the associations with retinal vascular caliber (13,15), which represents only one of the many geometric properties of the retinal vascular network. Retinal vascular Df is a global measure of complexity of the vascular branching pattern. Recently, we reported a strong cross-sectional association between retinal vascular Df and the prevalence of diabetic retinopathy (9). In the present study, we could not find similar a association using the longitudinal data from the same study sample of young patients with type 1 diabetes over a median follow-up of 2.9 years. This suggests that variations in retinal vascular Df are likely consequential, rather than antecedent to, the development of diabetic retinopathy.

Our study has several limitations. First, the follow-up period was relatively short, and all of the incident cases had mild nonproliferative diabetic retinopathy only. Therefore, it remains unclear whether retinal vascular Df could predict the risk of more severe diabetic retinopathy (e.g., proliferative diabetic retinopathy). Second, the possibility of selection bias may exist because this cohort was not a population-based sample and some patients (10.0%) were further excluded due to ungradable photographs. Third, there are potential sources of measurement error in fractal analysis (8), but these random errors could only bias our findings toward the null. Finally, although our study has adequate power to detect clinically important associations with a HR of 1.5 or greater (i.e., 50% difference in diabetic retinopathy risk by fractal quartiles), we have limited power to detect weaker associations.

In summary, our data demonstrate no longitudinal association between retinal vascular Df and risk of developing early diabetic retinopathy in young patients with type 1 diabetes. Further studies with larger sample size and longer follow-up are required to determine whether retinal fractal analysis is useful in predicting more severe levels of diabetic retinopathy and whether similar associations are present in older patients with type 2 diabetes.

The costs of publication of this article were defrayed in part by the payment of page charges. This article must therefore be hereby marked “advertisement” in accordance with 18 U.S.C. Section 1734 solely to indicate this fact.

This study is supported by the National Health and Medical Research Council Grant 475605 (to T.Y.W., K.C.D., and A.J.J.), the Juvenile Diabetes Research Foundation Innovative Grant (to T.Y.W., K.C.D., A.J.J., and N.C.), and the Royal Victorian Eye and Ear Hospital Research Grant (to N.C.).

No potential conflicts of interest relevant to this article were reported.
