OBJECTIVE

The vascular benefits of statins might be attenuated by inhibition of coenzyme Q10 (CoQ10) synthesis. We investigated whether oral CoQ10 supplementation improves endothelial dysfunction in statin-treated type 2 diabetic patients.

RESEARCH DESIGN AND METHODS

In a double-blind crossover study, 23 statin-treated type 2 diabetic patients with LDL cholesterol <2.5mmol/l and endothelial dysfunction (brachial artery flow-mediated dilatation [FMD] <5.5%) were randomized to oral CoQ10 (200 mg/day) or placebo for 12 weeks. We measured brachial artery FMD and nitrate-mediated dilatation (NMD) by ultrasonography. Plasma F2-isoprostane and 24-h urinary 20-hydroxyeicosatetraenoic acid (HETE) levels were measured as systemic oxidative stress markers.

RESULTS

Compared with placebo, CoQ10 supplementation increased brachial artery FMD by 1.0 ± 0.5% (P = 0.04), but did not alter NMD (P = 0.66). CoQ10 supplementation also did not alter plasma F2-isoprostane (P = 0.58) or urinary 20-HETE levels (P = 0.28).

CONCLUSIONS

CoQ10 supplementation improved endothelial dysfunction in statin-treated type 2 diabetic patients, possibly by altering local vascular oxidative stress.

Endothelial dysfunction portends diabetic vasculopathy. Endothelial dysfunction reflects increased vascular oxidative stress, whereby uncoupling of endothelial nitric oxide synthase activity and mitochondrial oxidative phosphorylation impairs the bioavailability and action of nitric oxide (1).

Statins are widely used in diabetes management and can reduce cardiovascular events (2). However, a proportion of statin-treated patients remain at risk of cardiovascular disease. Statins inhibit conversion of 3-hydroxy-3-methylglutaryl-CoA to mevalonate, but may thereby also decrease production of other intermediates in the cholesterol biosynthetic pathway, such as coenzyme Q10 (CoQ10) (3), an important intracellular antioxidant. We hypothesized that oral CoQ10 supplementation would improve endothelial dysfunction in statin-treated type 2 diabetic patients.

We recruited type 2 diabetic patients aged 40–79 years on stable-dose statin therapy for ≥6 weeks. Inclusion criteria were serum LDL cholesterol <2.5 mmol/l and endothelial dysfunction, defined as brachial artery flow-mediated dilatation (FMD) <5.5%. Exclusions included use of antioxidant supplements or other lipid-regulating medications, GHb >8.5%, and blood pressure >150/90 mmHg.

Eligible subjects were assigned in a double-blind and randomized manner to oral CoQ10 (200 mg/day) (Blackmores, Balgowlah, Australia) or placebo for 12 weeks. After a 4-week washout, participants crossed over to the alternate treatment. Brachial artery ultrasonography was performed, and fasting blood and 24-h urine samples were collected at the start and end of each treatment period. The Royal Perth Hospital Ethics Committee approved the study.

The brachial artery was imaged using a 12-MHz transducer connected to an Acuson Aspen ultrasound system (Siemens Medical Solutions, Malvern, PA), and FMD was measured as previously described (4). Endothelium-independent nitrate-mediated dilatation was measured following sublingual administration of glyceryl trinitrate (400 μg). Ultrasound images were analyzed using semiautomated edge-detection software (5).

Total cholesterol, triglycerides, and HDL cholesterol were determined by enzymatic methods, and LDL cholesterol was calculated using the Friedewald equation. GHb was measured using high-performance liquid chromatography. Plasma CoQ10 was measured by reverse-phase high-performance liquid chromatography using electrochemical detection (interassay coefficient of variation 14%). Plasma F2-isoprostane and 24-h urinary 20-hydroxyeicosatetraenoic acid levels (markers of systemic oxidative stress) were measured by gas chromatography-mass spectrometry (interassay coefficients of variation 5.6 and 10%, respectively) (6,8).

Data were analyzed using SPSS 15.0 (Chicago, IL) and SAS 9.1 (Cary, NC). Plasma CoQ10 data (skewed distribution) were logarithmically transformed for parametric analysis. Treatment effects were compared using mixed-effects models. Carryover effects were examined for and excluded.

Participants were typically middle-aged (mean ± SD age 68 ± 6 years) and overweight (BMI 29 ± 4 kg/m2), with satisfactory control of glycemia (GHb 6.9 ± 0.7%), blood pressure (systolic 123 ± 14 mmHg and diastolic 65 ± 7), and lipids (LDL cholesterol 1.8 ± 0.3 mmol/l). Median duration of diabetes was 8 years. Seventy-eight percent of subjects had a history of hypertension, 48% had a history of stroke or coronary disease, and 26% had microvascular complications. Eighty-three percent of subjects were taking antihyperglycemic medication, most commonly metformin (78%); 52% were taking ACE inhibitors; 21% were taking angiotensin receptor blockers; and 65% were taking aspirin. Atorvastatin was the most commonly prescribed statin (52%), followed by simvastatin (35%) and pravastatin (13%).

Baseline brachial artery diameter was similar at all assessments and unaltered by CoQ10 supplementation (Table 1). CoQ10 increased brachial artery FMD by mean ± SEM 1.0 ± 0.5% (P = 0.04) compared with placebo but did not alter nitrate-mediated dilatation (P = 0.66). Absolute percent FMD pre- and postplacebo, pre- and post-CoQ10, and change in percent FMD with placebo and CoQ10 are shown in supplemental Figures A1, A2, and A3 (available in an online appendix at http://care.diabetesjournals.org/cgi/content/full/dc08-1736/DC1), re- spectively. Despite increasing plasma CoQ10 levels 2.7-fold (P < 0.001), CoQ10 supplementation did not alter plasma F2-isoprostane (P = 0.58) or urinary 20-hydroxyeicosatetraenoic acid levels (P = 0.28) or influence glycemia, blood pressure, or lipids (P > 0.05).

Table 1

Effect of placebo and oral CoQ10 on arterial function, biochemical variables, and blood pressure

PlaceboOral CoQ10P
Baseline brachial artery diameter (mm)
    Pretreatment 3.9 ± 0.1 3.9 ± 0.1
    Treatment end 3.9 ± 0.1 3.9 ± 0.1
    Change −0.1 ± 0.0 0.0 ± 0.0 0.69
Brachial artery FMD (%)
    Pretreatment 2.2 ± 0.6 2.2 ± 0.7
    Treatment end 2.1 ± 0.7 3.2 ± 0.5
    Change 0.0 ± 0.5 1.0 ± 0.6 0.04
Brachial artery NMD (%)
    Pretreatment 16.9 ± 1.1 17.3 ± 0.9
    Treatment end 17.8 ± 1.0 17.5 ± 1.0
    Change 0.9 ± 0.9 0.2 ± 0.8 0.66
Plasma CoQ10 (μmol/l)
    Pretreatment 0.9 (0.2) 0.8 (0.3)
    Treatment end 0.8 (0.2) 2.2 (1.5)
    Change 0.0 (0.1) 1.2 (1.5) <0.001
Plasma F2-isoprostanes (pmol/l)
    Pretreatment 1,302 ± 68 1,284 ± 70
    Treatment end 1,275 ± 86 1,298 ± 69
    Change −27 ± 55 14 ± 42 0.58
Urinary 20-HETE (pmol/24 h)
    Pretreatment 828 ± 102 831 ± 109
    Treatment end 775 ± 104 888 ± 126
    Change −53 ± 80 57 ± 117 0.28
GHb (%)
    Pretreatment 7.0 ± 0.1 7.0 ± 0.2
    Treatment end 6.9 ± 0.2 7.0 ± 0.2
    Change −0.1 ± 0.1 −0.1 ± 0.1 0.58
LDL cholesterol (mmol/l)
    Pretreatment 1.9 ± 0.1 1.7 ± 0.1
    Treatment end 1.9 ± 0.1 2.0 ± 0.1
    Change 0.1 ± 0.1 0.2 ± 0.1 0.41
Systolic blood pressure (mmHg)
    Pretreatment 126 ± 4 122 ± 3
    Treatment end 121 ± 3 121 ± 4
    Change −4 ± 3 −1 ± 2 0.38
Diastolic blood pressure (mmHg)
    Pretreatment 67 ± 1 64 ± 2
    Treatment end 65 ± 1 66 ± 1
    Change −2 ± 1 1 ± 1 0.09
PlaceboOral CoQ10P
Baseline brachial artery diameter (mm)
    Pretreatment 3.9 ± 0.1 3.9 ± 0.1
    Treatment end 3.9 ± 0.1 3.9 ± 0.1
    Change −0.1 ± 0.0 0.0 ± 0.0 0.69
Brachial artery FMD (%)
    Pretreatment 2.2 ± 0.6 2.2 ± 0.7
    Treatment end 2.1 ± 0.7 3.2 ± 0.5
    Change 0.0 ± 0.5 1.0 ± 0.6 0.04
Brachial artery NMD (%)
    Pretreatment 16.9 ± 1.1 17.3 ± 0.9
    Treatment end 17.8 ± 1.0 17.5 ± 1.0
    Change 0.9 ± 0.9 0.2 ± 0.8 0.66
Plasma CoQ10 (μmol/l)
    Pretreatment 0.9 (0.2) 0.8 (0.3)
    Treatment end 0.8 (0.2) 2.2 (1.5)
    Change 0.0 (0.1) 1.2 (1.5) <0.001
Plasma F2-isoprostanes (pmol/l)
    Pretreatment 1,302 ± 68 1,284 ± 70
    Treatment end 1,275 ± 86 1,298 ± 69
    Change −27 ± 55 14 ± 42 0.58
Urinary 20-HETE (pmol/24 h)
    Pretreatment 828 ± 102 831 ± 109
    Treatment end 775 ± 104 888 ± 126
    Change −53 ± 80 57 ± 117 0.28
GHb (%)
    Pretreatment 7.0 ± 0.1 7.0 ± 0.2
    Treatment end 6.9 ± 0.2 7.0 ± 0.2
    Change −0.1 ± 0.1 −0.1 ± 0.1 0.58
LDL cholesterol (mmol/l)
    Pretreatment 1.9 ± 0.1 1.7 ± 0.1
    Treatment end 1.9 ± 0.1 2.0 ± 0.1
    Change 0.1 ± 0.1 0.2 ± 0.1 0.41
Systolic blood pressure (mmHg)
    Pretreatment 126 ± 4 122 ± 3
    Treatment end 121 ± 3 121 ± 4
    Change −4 ± 3 −1 ± 2 0.38
Diastolic blood pressure (mmHg)
    Pretreatment 67 ± 1 64 ± 2
    Treatment end 65 ± 1 66 ± 1
    Change −2 ± 1 1 ± 1 0.09

Data are means ± SEM or medians (interquartile range). Treatment effects compared using mixed-effects models, with adjustment for baseline, treatment sequence, and period. 20-HETE, 20-hydroxyeicosatetraenoic acid; NMD, nitrate-mediated dilatation.

The new finding was that CoQ10 supplementation improved endothelial dysfunction in statin-treated type 2 diabetic patients, with no alteration in two markers of systemic oxidative stress. This is consistent with our previous study in statin-naive dyslipidemic type 2 diabetic patients in whom oral CoQ10 also improved brachial artery FMD but did not alter plasma F2-isoprostane levels (4). However, a study in coronary heart disease patients (20% with diabetes and 80% statin-treated) showed that oral CoQ10 increased both brachial artery FMD and endothelium-bound extracellular superoxide dismutase activity, suggesting that the beneficial effects on endothelial function are related to improvements in local vascular oxidative stress (9). CoQ10 could also decrease vascular oxidative stress by recoupling endothelial nitric oxide synthase and/or mitochondrial oxidative phosphorylation. The fact that plasma F2-isoprostane levels in our diabetic subjects were not significantly different from those in our previously studied nondiabetic control subjects (1,360 ± 74 vs. 1,394 ± 122 pmol/l, respectively; P = 0.80) (4) probably reflects their satisfactory glycemic control; our results might have differed had we included patients with greater degrees of hyperglycemia and systemic oxidative stress. Whether CoQ10 supplementation might improve endothelial function by modulating other vasoactive mediators, such as endothelin 1 (10) or asymmetric dimethylarginine, (11) merits further investigation.

Our statin-treated subjects had lower plasma CoQ10 concentrations compared with those in the statin-naive dyslipidemic type 2 diabetic patients in our previous study (0.8 [0.2] vs. 1.3 [0.6] μmol/l; P < 0.01) (4). Although the lowering of plasma CoQ10 concentrations with pravastatin therapy was not shown to predict cardiovascular outcomes in coronary patients (12), the effect of pravastatin (40 mg/day) on plasma CoQ10 levels was modest (∼15% reduction vs. placebo) and inhibition of endogenous CoQ10 production may be greater with higher doses of more potent statins (3).

The patients in our study had endothelial dysfunction despite satisfactory control of blood pressure, glycemia, and lipids and may be representative of the proportion of statin-treated patients at increased residual risk of cardiovascular disease. Our absolute improvement in FMD of 1% with CoQ10 supplementation may potentially translate to a 10–25% reduction in residual cardiovascular risk in these patients (13,14). Impaired FMD is a consistent predictor of adverse cardiovascular events. Several interventions that improve FMD also improve cardiovascular outcomes (13,15). The significance of the findings in our report, however, requires further investigation in a clinical end point trial.

The costs of publication of this article were defrayed in part by the payment of page charges. This article must therefore be hereby marked “advertisement” in accordance with 18 U.S.C. Section 1734 solely to indicate this fact.

S.J.H. and G.T.C. were supported by National Health and Medical Research Council Postgraduate Research Scholarships.

This study was funded by a Cardiovascular Lipid Research Grant from Pfizer (West Ryde, Australia). Blackmores (Balgowlah, Australia) kindly supplied the CoQ10 and matching placebo capsules. No other potential conflicts of interest relevant to this article were reported.

Parts of this study were presented in poster form at the annual scientific meeting of the Australian Atherosclerosis Society, Sydney, Australia, 28–31 October 2008.

We thank Lisa Rich for assistance with ultrasonography, Professor Kevin Croft and Adeline Indrawan for assistance with laboratory analyses, and the study participants involved.

1.
Chew
GT
,
Watts
GF
:
Coenzyme Q10 and diabetic endotheliopathy: oxidative stress and the ‘recoupling hypothesis’
.
QJM
2004
; 
97
:
537
548
2.
Collins
R
,
Armitage
J
,
Parish
S
,
Sleigh
P
,
Peto
R
:;
Heart Protection Study Collaborative Group
.
MRC/BHF Heart Protection Study of cholesterol-lowering with simvastatin in 5963 people with diabetes: a randomised placebo-controlled trial
.
Lancet
2003
; 
361
:
2005
2016
3.
Littarru
GP
,
Langsjoen
P
:
Coenzyme Q10 and statins: biochemical and clinical implications
.
Mitochondrion
2007
; 
7
(
Suppl.
):
S168
S174
4.
Watts
GF
,
Playford
DA
,
Croft
KD
,
Ward
NC
,
Mori
TA
,
Burke
V
:
Coenzyme Q10 improves endothelial dysfunction of the brachial artery in Type II diabetes mellitus
.
Diabetologia
2002
; 
45
:
420
426
5.
Woodman
RJ
,
Playford
DA
,
Watts
GF
,
Cheetham
C
,
Reed
C
,
Taylor
RR
,
Puddey
IB
,
Beilin
LJ
,
Burke
V
,
Mori
TA
,
Green
D
:
Improved analysis of brachial artery ultrasound using a novel edge-detection software system
.
J Appl Physiol
2001
; 
91
:
929
937
6.
Mori
TA
,
Croft
KD
,
Puddey
IB
,
Beilin
LJ
:
An improved method for the measurement of urinary and plasma F2-isoprostanes using gas chromatography-mass spectrometry
.
Anal Biochem
1999
; 
268
:
117
125
7.
Rivera
J
,
Ward
N
,
Hodgson
J
,
Puddey
IB
,
Falck
JR
,
Croft
KD
:
Measurement of 20-hydroxyeicosatetraenoic acid in human urine by gas chromatography-mass spectrometry
.
Clin Chem
2004
; 
50
:
224
226
8.
Ward
NC
,
Puddey
IB
,
Hodgson
J
,
Beilin
LJ
,
Croft
KD
:
Urinary 20-hydroxyeicosatetraenoic acid excretion is associated with oxidative stress in hypertensive subjects
.
Free Radic Biol Med
2005
; 
38
:
1032
1036
9.
Tiano
L
,
Belardinelli
R
,
Carnevali
P
,
Principi
F
,
Seddaiu
G
,
Littarru
GP
:
Effect of coenzyme Q10 administration on endothelial function and extracellular superoxide dismutase in patients with ischaemic heart disease: a double-blind, randomized controlled study
.
Eur Heart J
2007
; 
28
:
2249
2255
10.
Cardillo
C
,
Campia
U
,
Bryant
MB
,
Panza
JA
:
Increased activity of endogenous endothelin in patients with type II diabetes mellitus
.
Circulation
2002
; 
106
:
1783
1787
11.
Yasuda
S
,
Miyazaki
S
,
Kanda
M
,
Goto
Y
,
Suzuki
M
,
Harano
Y
,
Nonogi
H
:
Intensive treatment of risk factors in patients with type-2 diabetes mellitus is associated with improvement of endothelial function coupled with a reduction in the levels of plasma asymmetric dimethylarginine and endogenous inhibitor of nitric oxide synthase
.
Eur Heart J
2006
; 
27
:
1159
1165
12.
Stocker
R
,
Pollicino
C
,
Gay
CA
,
Nestel
P
,
Colquhoun
D
,
Whiting
M
,
Tonkin
A
,
Sullivan
D
,
Simes
J
:
Neither plasma coenzyme Q10 concentration, nor its decline during pravastatin therapy, is linked to recurrent cardiovascular disease events: a prospective case-control study from the LIPID study
.
Atherosclerosis
2006
; 
187
:
198
204
13.
Neunteufl
T
,
Heher
S
,
Katzenschlager
R
,
Wolfl
G
,
Kostner
K
,
Maurer
G
,
Weidinger
F
:
Late prognostic value of flow-mediated dilation in the brachial artery of patients with chest pain
.
Am J Cardiol
2000
; 
86
:
207
210
14.
Shimbo
D
,
Grahame-Clarke
C
,
Miyake
Y
,
Rodriguez
C
,
Sciacca
R
,
Di Tullio
M
,
Boden-Albala
B
,
Sacco
R
,
Homma
S
:
The association between endothelial dysfunction and cardiovascular outcomes in a population-based multi-ethnic cohort
.
Atherosclerosis
2007
; 
192
:
197
203
15.
Widlansky
ME
,
Gokce
N
,
Keaney
JF
,
Vita
JA
:
The clinical implications of endothelial dysfunction
.
J Am Coll Cardiol
2003
; 
42
:
1149
1160
