OBJECTIVE

We investigated in a cross-sectional study the levels of serum and urinary damage markers in diabetic patients (n = 94) and nondiabetic control subjects (n = 45) to study the association of glomerular (IgG), proximal tubular (kidney injury molecule [KIM]-1, N-acetyl-β-d-glucosaminidase [NAG], neutrophil gelatinase–associated lipocalin [NGAL], and cystatin C), and distal tubular (heart fatty acid–binding protein [H-FABP]) damage markers with kidney disease severity, as assessed by albuminuria and estimated glomerular filtration rate (eGFR).

RESEARCH DESIGN AND METHODS

Damage markers were measured in triplicate in fresh morning urine samples and in plasma.

RESULTS

Of the diabetic patients, 41 were normoalbuminuric, 41 were microalbuminuric, and 12 were macroalbuminuric. Urinary NAG (ninefold), NGAL (1.5-fold), and H-FABP (3.5-fold) were significantly elevated in normoalbuminuric diabetic patients compared with nondiabetic control subjects. Urinary concentrations of all markers increased per albuminuria stratum, except KIM-1. All urinary damage markers, except KIM-1, were significantly associated with albuminuria, independent of age, sex, and plasma concentrations of the corresponding biomarker (standard βs between 0.35 and 0.87; all P ≤ 0.001). All urinary damage markers, except KIM-1, were significantly associated with the eGFR in univariate models (standard βs between −0.38 and −0.21; all P < 0.04). After adjusting for age, sex, plasma concentration of the corresponding damage marker, and albuminuria, only the association of H-FABP with eGFR remained significant (standard β −0.26; P = 0.037).

CONCLUSIONS

Glomerular and tubular markers are associated with albuminuria, independently of eGFR, suggesting that albuminuria reflects both glomerular and tubulointerstitial damage. Only urinary H-FABP is associated with eGFR independently of albuminuria and, therefore, may be a promising urinary damage marker to assess diabetic kidney disease.

Diabetic nephropathy occurs in 20–40% of patients with diabetes and is the leading cause of chronic kidney disease and end-stage renal disease in the U.S. and many other Western countries (1,2). The onset of elevated levels of urinary albumin excretion is an early sign of diabetic nephropathy. Various studies have shown that in subjects with diabetes, microalbuminuria predicts the occurrence of macroalbuminuria and renal function decline (3). As a result, high albuminuria has become an established renal risk marker in these patients (4).

Classically, albuminuria is regarded as the consequence of diabetes-induced glomerular damage. More recently, it is increasingly appreciated that the renal tubulointerstitium plays a role in the pathogenesis of diabetic nephropathy, with prolonged exposure to a variety of metabolic and hemodynamic injuring factors associated with sustained diabetes disease as contributing factors (5,6). Furthermore, persistent albuminuria secondary to glomerular lesions may be directly harmful to renal tubular cells, leading to tubular inflammation and tubulointerstitial fibrosis (7,8).

Several tubular damage markers recently have been discovered. Increased levels of these markers are supposed to indicate proximal tubular damage in the case of kidney injury molecule (KIM)-1, neutrophil gelatinase–associated lipocalin (NGAL), N-acetyl-β-d-glucosaminidase (NAG), and cystatin C and distal tubular damage in the case of heart fatty acid–binding protein (H-FABP). These tubular damage markers have been extensively investigated in the field of predicting the occurrence of acute kidney injury after various nephrotoxic insults, such as ischemia during cardiac surgery, sepsis, and administration of contrast medium (911). Little research has been done in patients with chronic kidney disease. In this study, we investigated the serum and urinary levels of the aforementioned damage markers in diabetic patients and nondiabetic control subjects in order to investigate the relation of these markers to the severity of kidney disease as assessed by albuminuria and the estimated glomerular filtration rate (eGFR). As a secondary aim, we investigated whether these damage markers are related to eGFR independent of albuminuria.

Type 1 and type 2 diabetic patients who were visiting a diabetes specialty clinic were recruited. Inclusion was between April 2009 and September 2009. They were stratified by the amount of albuminuria, based on a first morning urine void. We included 94 diabetic patients, of whom 41 had normoalbuminuria, 41 had microalbuminuria, and 12 had macroalbuminuria. To ensure that macroalbuminuria was the consequence of diabetic nephropathy, patients with macroalbuminuria were required to have diabetic retinopathy. Patients who had cancer, infections or inflammatory conditions, and renal disease other than diabetic nephropathy; those who used nephrotoxic drugs; those who had a renal transplant; or those who were pregnant were excluded. Patients aged <18 years also were excluded. For a control group, we included 45 nondiabetic subjects without chronic kidney disease (1:2 vs. diabetic patients). Subjects were excluded from the control group if they had a fasting glucose >7.0 mmol/L, used glucose-lowering medication, had an eGFR <60 mL/min per 1.73 m2, or had an albumin-to-creatinine ratio (ACR) >30 mg/g. The study protocol was approved by the local ethics committee.

Measurements

We instructed patients to collect their first morning urine void on the day of their clinic visit. Blood pressure was assessed with a single measurement. Urinary albumin concentration was determined by nephelometry (BNII; Dade Behring Diagnostics, Marburg, Germany). Serum and urine creatinine were measured with an enzymatic creatinine assay (Roche, Mannheim, Germany). Glucose, HbA1c, and cholesterol levels were measured with standard laboratory testing.

Definitions

We defined history of cardiovascular disease as having had a myocardial infarction, a stroke, surgery, or endovascular treatment for coronary carotid or peripheral (legs, abdominal, and aorta) artery disease. Hypertension was defined as systolic blood pressure >140 mmHg, diastolic blood pressure >90 mmHg, or use of blood pressure–lowering medication. Normoalbuminuria was defined as an ACR <3 mg/mmol, microalbuminuria as an ACR 3–30 mg/mmol, and macroalbuminuria as an ACR >30 mg/mmol (12). Serum creatinine values were used to calculate an eGFR, using the abbreviated Modification of Diet in Renal Disease formula.

Damage markers

We measured IgG as a glomerular damage marker; KIM-1, NGAL, NAG, and cystatin CAs as markers of proximal tubular damage; and H-FABP as a marker of distal tubular damage. Urinary concentrations of KIM-1, NGAL, H-FABP, and IgG were measured by enzyme-linked immunosorbent assay. For KIM-1 and NGAL, antibodies were obtained from R&D Systems (Minneapolis, MN). H-FABP and IgG antibodies were obtained from Hytest (Turku, Finland). We measured urinary concentration of NAG using a modified enzyme assay according to Lockwood and corrected for nonspecific conversion (HaemoScan, Groningen, the Netherlands). Cystatin C was measured by nephelometry (reagents obtained from Siemens [Marburg, Germany]). We measured all samples in triplicate in fresh samples of both urine and plasma. Urinary damage-marker concentrations are expressed per millimole creatinine.

Statistical analyses

Analyses were performed with SPSS version 16.0 (SPSS, Chicago, IL). Characteristics were calculated per albuminuria stratum. Parametric variables were expressed as means ± SD, whereas nonparametric variables were given as median (interquartile range). We tested P values for trend over albuminuria strata in diabetic patients using ANOVA for normal distributed variables. For nonnormal distributed variables, we used a Kruskall-Wallis test. Logarithmic transformation of damage-marker excretion was applied. To investigate the association between the individual damage marker and eGFR or albuminuria, we performed a linear regression analysis by using eGFR or albuminuria as independent variables and the various damage markers as dependent variables. Various models were gradually built to adjust for possible confounding. First, we investigated the crude association between the damage marker and eGFR or albuminuria. Second, we performed multivariate analysis, adjusting for age and sex. Third, we tested whether plasma levels of the corresponding damage marker influenced the association between the damage marker and eGFR or albuminuria. Finally, to investigate whether knowledge about urinary damage-marker concentrations may be of value to assess the severity of diabetic kidney disease in addition to knowledge about albuminuria status, we performed multivariable regression analysis with eGFR as dependent variable and the damage markers as independent variables, adjusting for albuminuria. We added the use of diuretics, the use of ACE inhibitors/angiotensin receptor blockers (ARBs), and the type of diabetes to the final multivariable models (model 3 for albuminuria and model 4 for eGFR) as a sensitivity analysis. If any of these covariates showed a significant association with either albuminuria or eGFR, we tested for interaction by entering the urinary biomarker, the investigated characteristic, and their product term in the multivariable regression model. For all analyses, a two-sided P < 0.05 was considered statistically significant.

A total of 94 patients with diabetes and 45 control subjects participated in this study. Characteristics of patients and control subjects are given in Table 1. Patients in the microalbuminuric and macroalbuminuric groups were more often male and smokers, more often had a history of cardiovascular disease, used more antihypertensive medications, and had a lower eGFR when compared with normoalbuminuric diabetic subjects.

Table 1

Characteristics of nondiabetic control subjects (n = 45) and diabetic patients (n = 94) according to albuminuria stratum

Nondiabetic subjectsSubjects with diabetesP value in diabetes
NormoalbuminuriaMicroalbuminuriaMacroalbuminuria
n 45 41 41 12
Age (years) 53 ± 13 59 ± 13 64 ± 12* 63 ± 13 0.12
Male sex (%) 56 73 66 83 0.48
Diabetes duration (years) — 24 ± 11 20 ± 9 27 ± 8 0.064
Type diabetes (% type 2) — 49 78 83 0.007
History of cardiovascular disease (%) 22 45 64 0.018
Smoking (%) 22 10 32 33 0.035
BMI (kg/m227 ± 6 30 ± 5 32 ± 6 32 ± 5 0.28
Systolic blood pressure (mmHg) 132 ± 16 139 ± 15 141 ± 17 152 ± 14* 0.052
Diastolic blood pressure (mmHg) 74 ± 9 78 ± 10 77 ± 77 77 ± 13 0.90
Antihypertensive medication (%) 18 72* 95* 100* 0.006
ACE inhibitors/ARBs (%) 65* 80* 83* 0.24
 Diuretics 11 32* 63* 75* 0.015
 Hypertension 36 85* 97* 100* 0.071
HbA1c (%) 5.4 ± 0.3 7.7 ± 1.0* 7.6 ± 1.3* 7.8 ± 0.7* 0.87
eGFR Modification of Diet in Renal Disease (mL/min per 1.73 m286 ± 14 85 ± 21 72 ± 22 55 ± 24 <0.001
ACR (mg/mmol) 0.56 (0.44–1.0) 0.70 (0.36–1.21) 8.7 (5.6–13.7)* 115 (71–130)* <0.001
Nondiabetic subjectsSubjects with diabetesP value in diabetes
NormoalbuminuriaMicroalbuminuriaMacroalbuminuria
n 45 41 41 12
Age (years) 53 ± 13 59 ± 13 64 ± 12* 63 ± 13 0.12
Male sex (%) 56 73 66 83 0.48
Diabetes duration (years) — 24 ± 11 20 ± 9 27 ± 8 0.064
Type diabetes (% type 2) — 49 78 83 0.007
History of cardiovascular disease (%) 22 45 64 0.018
Smoking (%) 22 10 32 33 0.035
BMI (kg/m227 ± 6 30 ± 5 32 ± 6 32 ± 5 0.28
Systolic blood pressure (mmHg) 132 ± 16 139 ± 15 141 ± 17 152 ± 14* 0.052
Diastolic blood pressure (mmHg) 74 ± 9 78 ± 10 77 ± 77 77 ± 13 0.90
Antihypertensive medication (%) 18 72* 95* 100* 0.006
ACE inhibitors/ARBs (%) 65* 80* 83* 0.24
 Diuretics 11 32* 63* 75* 0.015
 Hypertension 36 85* 97* 100* 0.071
HbA1c (%) 5.4 ± 0.3 7.7 ± 1.0* 7.6 ± 1.3* 7.8 ± 0.7* 0.87
eGFR Modification of Diet in Renal Disease (mL/min per 1.73 m286 ± 14 85 ± 21 72 ± 22 55 ± 24 <0.001
ACR (mg/mmol) 0.56 (0.44–1.0) 0.70 (0.36–1.21) 8.7 (5.6–13.7)* 115 (71–130)* <0.001

Parametric variables are expressed as means ± SD and nonparametric variables are median (interquartile range).

*P < 0.001;

P < 0.05;

P < 0.01 vs. nondiabetic control subjects, calculated using the independent-samples t test for normal distributed variables and the Mann-Whitney U test for nonnormal distributed variables. Hypertension was defined as systolic blood pressure >140 mmHg, diastolic blood pressure >90 mmHg, or use of antihypertensive medication.

Damage-marker concentrations

Damage-marker concentrations in nondiabetic control subjects and in diabetic patients are shown in Table 2 and Fig. 1. Urinary damage-marker concentrations of NAG, NGAL, and H-FABP were higher in normoalbuminuric patients with diabetes than in control subjects and increased with increasing categories of albuminuria in patients with diabetes. In contrast, cystatin C was lower in normoalbuminuric diabetic patients than in nondiabetic control subjects but again increased with increasing categories of albuminuria in patients with diabetes. KIM-1 was higher in normoalbuminuric patients with diabetes than in control subjects but was not different between the categories of albuminuria in patients with diabetes (Fig. 1 and Table 2). Differences between the categories of albuminuria were most pronounced for the glomerular marker IgG (>30-fold increase from normoalbuminuria to macroalbuminuria) and the distal tubular marker H-FABP (>21-fold). Differences were less pronounced for the proximal tubular markers (from no increase to an 8.5-fold increase for NGAL). Plasma concentrations of the various markers are given in Supplementary Table 1.

Table 2

Damage-marker concentrations in nondiabetic control subjects and in diabetic patients according to albuminuria stratum

Nondiabetic subjectsSubjects with diabetesP value in diabetes
NormoalbuminuriaMicroalbuminuriaMacroalbuminuria
Albumin (mg/mmol) 0.56 (0.44–1.0) 0.70 (0.36–1.21) 8.7 (5.6–13.7)* 115 (71–130)* <0.001
Glomerular
 IgG (μg/mmol) 465 (279–867) 242 (151–751) 1,320 (590–3,780) 7,379 (5,079–9,202)* <0.001
Proximal tubular
 KIM-1 (ng/mmol) 65 (33–104) 168 (116–216)* 122 (73–221)* 305 (112–417)* 0.53
 NAG (units/mmol) 0.10 (0.07–0.14) 0.9 (0.6–1.4)* 1.2 (0.9–2.1)* 2.5 (1.4–3.4)* <0.001
 NGAL (μg/mmol) 1.3 (0.8–2.0) 2.1 (1.1–7.2) 5.5 (2.9–14.0)* 18.0 (6.9–45.1)* 0.001
 Cystatin C (μg/mmol) 4.2 (3.3–5.1) 2.6 (1.8–4.4) 3.9 (2.7–5.0) 10.3 (6.7–33.3)* <0.001
Distal tubular
 H-FABP (ng/mmol) 34 (24–44) 130 (59–413)* 300 (104–1,215)* 2,742 (712–7,199)* <0.001
Nondiabetic subjectsSubjects with diabetesP value in diabetes
NormoalbuminuriaMicroalbuminuriaMacroalbuminuria
Albumin (mg/mmol) 0.56 (0.44–1.0) 0.70 (0.36–1.21) 8.7 (5.6–13.7)* 115 (71–130)* <0.001
Glomerular
 IgG (μg/mmol) 465 (279–867) 242 (151–751) 1,320 (590–3,780) 7,379 (5,079–9,202)* <0.001
Proximal tubular
 KIM-1 (ng/mmol) 65 (33–104) 168 (116–216)* 122 (73–221)* 305 (112–417)* 0.53
 NAG (units/mmol) 0.10 (0.07–0.14) 0.9 (0.6–1.4)* 1.2 (0.9–2.1)* 2.5 (1.4–3.4)* <0.001
 NGAL (μg/mmol) 1.3 (0.8–2.0) 2.1 (1.1–7.2) 5.5 (2.9–14.0)* 18.0 (6.9–45.1)* 0.001
 Cystatin C (μg/mmol) 4.2 (3.3–5.1) 2.6 (1.8–4.4) 3.9 (2.7–5.0) 10.3 (6.7–33.3)* <0.001
Distal tubular
 H-FABP (ng/mmol) 34 (24–44) 130 (59–413)* 300 (104–1,215)* 2,742 (712–7,199)* <0.001

Data are per mmol urinary creatinine concentration and given as medians (25th–75th percentile).

*P < 0.001;

P < 0.01 vs. nondiabetic control subjects, calculated using the Mann-Whitney U test.

Figure 1

Biomarker concentrations in nondiabetic control subjects and in diabetic patients, according to albuminuria stratum (normoalbuminuria, microalbuminuria, and macroalbuminuria). Box plots show medians (25th–75th percentile). Significance was tested using the Mann-Whitney U test. Control subjects were included when subjects had a fasting glucose <7.0 mmol/L or did not use glucose-lowering medication.

Figure 1

Biomarker concentrations in nondiabetic control subjects and in diabetic patients, according to albuminuria stratum (normoalbuminuria, microalbuminuria, and macroalbuminuria). Box plots show medians (25th–75th percentile). Significance was tested using the Mann-Whitney U test. Control subjects were included when subjects had a fasting glucose <7.0 mmol/L or did not use glucose-lowering medication.

Close modal

Associations of damage markers with albuminuria in diabetic patients

Associations between the various urinary damage markers and albuminuria were analyzed in all diabetic patients. All damage markers were found to be significantly associated with albuminuria in crude models, except for KIM-1 (Table 3, model 1). Also, the results did not materially change after adjusting for age and sex (model 2) and, additionally, for the plasma concentration of the corresponding damage marker (model 3) and for eGFR (model 4). All investigated damage markers, except KIM-1, remained associated with albuminuria. When information on use of diuretics, the use of ACE inhibitors/ARBs, or the type of diabetes was added to the multivariable regression analyses, only the type of diabetes was a significant covariate for the association between urinary KIM-1, NAG, NGAL, cystatin C, and H-FABP with albuminuria. Sex was a significant covariate in only the association between NGAL and albuminuria. We subsequently tested for an interaction between these covariates and these damage markers in their association with albuminuria. Of all tested interaction terms, only the interaction between sex and NGAL reached statistical significance.

Table 3

Multivariable regression analysis of various damage markers vs. albuminuria or eGFR

Damage markers vs. albuminuria
IgGKIM-1NGALCystatin CNAGH-FABP
ModelStandard βPStandard βPStandard βPStandard βPStandard βPStandard βP
 1   0.78 <0.001 0.15 0.195 0.34 0.001 0.49 <0.001 0.37 <0.001 0.48 <0.001
 2   0.80 <0.001 0.13 0.252 0.42 <0.001 0.51 <0.001 0.37 <0.001 0.49 <0.001
 3





0.87

<0.001

0.12

0.311

0.45

<0.001

0.35

0.001

0.60

<0.001

0.50

<0.001



Damage markers vs. eGFR

Albumin

IgG

KIM-1

NGAL

Cystatin C

NAG

H-FABP

Model Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

 1 −0.37 <0.001 −0.35 0.034 −0.13 0.24 −0.38 <0.001 −0.26 0.012 −0.32 0.002 −0.34 0.001
 2 −0.32 <0.001 −0.34 0.026 0.03 0.74 −0.29 0.004 −0.28 0.002 −0.19 0.053 −0.35 <0.001
 3 −0.32 0.001 −0.39 0.018 −0.08 0.42 −0.26 0.014 −0.08 0.21 −0.23 0.074 −0.36 0.001
 4   0.03 0.91 0.11 0.27 −0.11 0.311 0.07 0.30 0.02 0.91 −0.26 0.037
Damage markers vs. albuminuria
IgGKIM-1NGALCystatin CNAGH-FABP
ModelStandard βPStandard βPStandard βPStandard βPStandard βPStandard βP
 1   0.78 <0.001 0.15 0.195 0.34 0.001 0.49 <0.001 0.37 <0.001 0.48 <0.001
 2   0.80 <0.001 0.13 0.252 0.42 <0.001 0.51 <0.001 0.37 <0.001 0.49 <0.001
 3





0.87

<0.001

0.12

0.311

0.45

<0.001

0.35

0.001

0.60

<0.001

0.50

<0.001



Damage markers vs. eGFR

Albumin

IgG

KIM-1

NGAL

Cystatin C

NAG

H-FABP

Model Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

Standard β

P

 1 −0.37 <0.001 −0.35 0.034 −0.13 0.24 −0.38 <0.001 −0.26 0.012 −0.32 0.002 −0.34 0.001
 2 −0.32 <0.001 −0.34 0.026 0.03 0.74 −0.29 0.004 −0.28 0.002 −0.19 0.053 −0.35 <0.001
 3 −0.32 0.001 −0.39 0.018 −0.08 0.42 −0.26 0.014 −0.08 0.21 −0.23 0.074 −0.36 0.001
 4   0.03 0.91 0.11 0.27 −0.11 0.311 0.07 0.30 0.02 0.91 −0.26 0.037

Bold print indicates associations between damage markers and albuminuria or eGFR that reach statistical significance. Model 1: crude; model 2: adjustment for age and sex; model 3: adjustment for age, sex, and plasma concentration of the corresponding damage marker; model 4: adjustment for age, sex, plasma concentration of the corresponding damage marker, and albuminuria.

Associations of damage markers with eGFR in diabetic patients

Table 3 also shows the associations between the various urinary damage markers and eGFR. Again, all damage markers, except KIM-1, were significantly associated with eGFR in crude models (model 1). However, after adjusting for age and sex, only albumin, the glomerular marker IgG, the proximal tubular markers NGAL and cystatin C, and the distal tubular marker H-FABP remained significantly associated with eGFR (model 2). When additionally adjusted for plasma concentration of the corresponding damage marker, IgG, albumin, NGAL, and H-FABP remained significant, whereas cystatin C lost significance. The association between the distal tubular marker H-FABP and eGFR was the only association that remained significant, after additional adjustment for albuminuria (standard β −0.26; P = 0.037). When information on sex, the use of diuretics, the use of ACE inhibitors/ARBs, or the type of diabetes was added to the multivariable regression analyses, only sex was a significant covariate for the association between urinary cystatin C with eGFR, but no significant interaction was found between sex and urinary cystatin C.

In the current study, we measured markers of glomerular, proximal tubular, and distal tubular damage to study the relationship between these damage markers with the severity of diabetic kidney disease as assessed by albuminuria and eGFR. We found that urinary concentrations of glomerular, proximal tubular, and distal tubular damage markers were higher when patients had more albuminuria. Interestingly, even in normoalbuminuric diabetic patients some of these markers already were elevated compared with nondiabetic subjects. In regression analyses, all damage markers that were significantly associated with albuminuria also were significantly associated with eGFR, except cystatin C and NAG. H-FABP was the only damage marker significantly associated with eGFR after adjustment for albuminuria.

In diabetic patients, the urinary concentration of the investigated glomerular damage marker, IgG, increased over the three albuminuria groups and is strongly associated with albuminuria. In healthy subjects, only trace amounts of these large–molecular weight proteins are leaked by the glomerulus. These data suggest, therefore, that in albuminuric diabetic patients, the amount of albuminuria reflects glomerular damage, at least to a certain extent. Similar observations have been previously described (13,14).

In general, all investigated tubular markers, except KIM-1, increased in higher albuminuria strata. Only a limited number of studies have, to date, investigated the association of tubular markers with the severity of chronic kidney disease in diabetic nephropathy. Our results, with respect to the proximal tubular markers, are similar to these studies insofar that they also showed that the urinary level of tubular damage markers parallels the degree of urinary albumin excretion (1518). It can be argued that this may be a result of the tubulotoxic effect of albumin and other proteins that are leaked into the tubular lumen (7). However, such tubulotoxic effects cannot fully explain our findings because some of the markers under investigation already were increased in the normoalbuminuric diabetic patients compared with nondiabetic control subjects, whereas albuminuria (and eGFR) in these normoalbuminuric diabetic patients was comparable with nondiabetic control subjects. A limited number of other studies (1719) have previously described elevated levels of tubular markers in normoalbuminuric diabetic subjects when compared with healthy control subjects. Urinary excretion of NGAL and lysosomal enzymes, such as NAG and cathepsin, have, for instance, been found to be increased. These data suggest a role of the tubulointerstitium in the pathogenesis and progression of renal damage in patients with diabetes. This assumption is strengthened by two other observations in our study. First, we found that some of these markers were associated with diabetes-related factors in normoalbuminuric diabetic subjects, such as BMI, duration of diabetes, and metabolic regulation. Second, to our knowledge, we are the first to show that a marker of distal tubular damage, H-FABP, also is associated with albuminuria, despite the fact that the distal tubule is assumed to be less sensitive to the toxic effects of urinary proteins.

Data in literature also support the finding that in diabetic kidney disease, the severity of chronic kidney disease depends not only on the severity of glomerular lesions but also on tubulointerstitial damage. A histological study (20) showed that proximal tubular basement membrane width already is thickened in normoalbuminuric diabetic patients compared with healthy control subjects. Another study (21) in microalbuminuric diabetic patients with similar GFR showed that only 29% had typical histological glomerular features of diabetic nephropathy, whereas 42% had severe tubulointerstitial lesions disproportional to the mild glomerular involvement.

All markers that were associated with albuminuria also were correlated with eGFR in crude models. However, the association of eGFR with the urinary NAG concentration lost significance after adjusting for age and sex, and the association with urinary cystatin C lost significance after additional adjustment for its plasma concentration. In healthy subjects, cystatin C is a marker for eGFR, with impaired GFR being associated with higher levels of cystatin C. Our data imply that the urinary concentration of cystatin C is largely determined by the amount that is filtrated through the glomerulus in subjects with diabetic nephropathy.

As secondary aim in our study, we investigated which damage markers are associated with eGFR independent of albuminuria. Albuminuria is widely acknowledged to be associated with eGFR in subjects with diabetic nephropathy (3,22). We found that the associations of all markers under investigation with eGFR lost statistical significance after adjusting for albuminuria, except for H-FABP. In addition, we found that the urinary H-FABP concentration already was significantly elevated in normoalbuminuric patients with diabetes compared with nondiabetic control patients who had a similar eGFR. These data suggest that urinary H-FABP concentration is a promising marker to predict the clinical outcome of diabetic nephropathy in addition to albuminuria.

We acknowledge that the current study has limitations. First, the current study is a single-center study, and the association of the measured damage markers with albuminuria and eGFR needs to be confirmed. Second, this study has a cross-sectional design. Whether the damage markers, as assessed in our study, predict the progression of diabetic nephropathy has to be investigated in long-term, prospective, observational studies. Finally, having a larger number of patients would have allowed us to perform the analyses in specific subgroups. However, the results of our multivariable regression analyses in which interactions were tested showed that there were almost no significant interactions between these covariates and the various urinary damage markers in their association with albuminuria or eGFR. This suggests that the associations between these damage markers and albuminuria or eGFR are not different in men versus women, in subjects using or not using diuretics, in subjects using or not using ACE inhibitors/ARBs, or in subjects with type 1 versus type 2 diabetes. The strengths of this study are that we measured a wide range of kidney damage markers, representing different parts of the nephron, ranging from the glomerulus, proximal, to distal tubules. Furthermore, we measured all our markers in fresh urine samples to ensure optimal sample quality. It has previously been shown for several markers that frozen storage and freeze-thaw cycles lead to a systematic decrease and increase in variability (9,23,24), which may negatively influence association studies such as the present one. Finally, most authors investigating urinary excretion of renal damage markers did not measure plasma concentrations (9,25). We also measured the corresponding plasma concentration of all urinary markers to rule out that a high plasma concentration instead of renal damage caused a high urinary concentration. This appeared to be the case for cystatin C.

In conclusion, urinary concentrations of most investigated damage markers are elevated in patients with diabetes when compared with nondiabetic control subjects. These damage markers are associated with the severity of diabetic nephropathy as assessed by albuminuria and eGFR. Interestingly, some of these markers already are elevated in normoalbuminuric diabetic patients with normal eGFR. This renders these proteins as potential sensitive markers of early diabetic kidney damage. Only the distal tubular marker H-FABP was found to be associated with eGFR independent of albuminuria, suggesting that especially measuring urinary H-FABP concentrations may be useful to assess the severity of diabetic kidney damage in addition to measuring albuminuria.

No potential conflicts of interest relevant to this article were reported.

F.L.N. and W.E.B. held the outpatient clinic, researched data, and wrote the manuscript. S.J.L.B. researched data and contributed to discussion. H.v.G. contributed to discussion and reviewed the manuscript. W.v.O. conducted measurements and contributed to discussion. P.E.d.J. reviewed the manuscript and contributed to discussion. H.B. helped in the outpatients clinic and contributed to the manuscript. R.T.G. researched data and edited the manuscript.

The authors thank Katinka Mulder, University Medical Center Groningen, Groningen, the Netherlands, for help with reviewing the manuscript.
