Insulitis in Autoantibody-Positive Pancreatic Donor With History of Gestational Diabetes Mellitus

• Hispanic G2P2002 female (i.e., gravida 2 para 2; two pregnancies with two living children) died at age 28 years, 32 days postoperative after cesarean delivery

• Normal BMI: 23.9 kg/m²

• Found unresponsive and in hypertensive crisis

• Clinical history included gestational diabetes mellitus, preeclampsia with severe features, acute renal failure, chronic hypertension, and anemia

• Admission glucose 259 mg/dL, pH 7.22, HCO3⁻ 18.4 mEq/L, C-peptide 10.54 ng/mL, HbA_1c not determined

• Negative for pulmonary embolus, sepsis, and hemorrhagic stroke

• Head computed tomography revealed anoxic encephalopathy with multiple infarcts in the dorsal midbrain and thalamus

• Type 1 diabetes–associated autoantibodies: positive for glutamic acid decarboxylase antibodies (GADA; 1,068 units/mL with assay cutoff 20) and islet cell antibodies (ICA; 2,560 JDFU with assay cutoff 10) and negative for other autoantibodies (against insulin [IAA], insulinoma-associated protein 2 [IA-2A], and islet-specific zinc transporter 8 [ZnT8A])

• HLA intermediate risk for type 1 diabetes: A*03:01, 30:01; DRB1*07:01, 11:02; DQA1*02:01, 05:01; DQB1*02:02, 03:19

• Cause of death: anoxic encephalopathy of unknown etiology

The patient (nPOD 6310) was a 28-year-old female, 32 days postoperative from a cesarean delivery. Her past medical history was significant for chronic hypertension, severe preeclampsia, acute renal failure, and gestational diabetes mellitus (GDM). She was brought to the emergency department after collapsing, with total downtime of 20–30 min. On arrival, she was admitted to the intensive care unit and found to be in hypertensive crisis. Her hospital course was complicated by renal failure requiring four rounds of hemodialysis, hypertension requiring multiple agents for control, and a degree of hyperglycemia requiring insulin. Computed tomography of the head demonstrated anoxic encephalopathy with multiple infarcts within the brain. The patient was declared brain-dead and, with authorization obtained from next of kin, became an organ donor. The pancreas, along with blood, was recovered for research through the Network for Pancreatic Organ Donors with Diabetes (nPOD) (1).

Diabetes is the most common medical complication of pregnancy, with potential for both maternal and fetal morbidity and mortality. Approximately 6–7% of pregnancies are complicated by diabetes, and approximately 90% of these cases are accounted for by GDM (2). GDM is a condition of carbohydrate intolerance with onset or first recognition during pregnancy. GDM places a mother at risk for developing overt diabetes outside of pregnancy, with up to 50% of mothers developing type 2 diabetes within 20–28 years (2,3) compared with as low as 2% incidence following a normoglycemic pregnancy (4).

Although the relationship between GDM and type 2 diabetes is well established, the relationship of GDM with type 1 diabetes is less clear. Indeed, this latter risk seems especially great when GDM is associated with type 1 diabetes autoantibodies (5,6). Nilsson et al. (6) demonstrated that among 385 women with GDM, 24 (6%) had β-cell–specific autoantibodies characteristic of type 1 diabetes. Of the 12 women who later developed this disease, 100% were glutamic acid decarboxlyase antibody (GADA)-positive during their pregnancy, although single, double, or triple autoantibody status for progressors was not reported. For the donor with history of GDM reported here, GADA and islet cell antibody (ICA) titers were exceedingly high (1,068 units/mL with assay cutoff 20 and 2,560 JDFU with assay cutoff 10, respectively), while autoantibodies against insulin (IAA), insulinoma-associated protein 2 (IA-2A), and islet-specific zinc transporter 8 (ZnT8A) were all negative by radioimmunoassay. It cannot be excluded that ICA reactivity detected in this donor may be attributable to the high-titer GADA, which has been shown to be a major antigen of the ICA reaction (7). Because of the polyclonal nature and indirect immunofluorescence detection methods (8), the ICA test clearly differs from other autoantibody testing via ELISA or radioimmunoassay in terms of antigen/epitope specificity. At this time, nPOD does not consider ICA for standard testing of autoantibodies (9–11). Future efforts are needed to determine the additional autoantibodies and their target antigens that contribute to ICA for more precise reporting of autoantibody status in subjects with positivity for both GADA and ICA.

Previous studies, albeit limited and largely focused on the natural history of type 1 diabetes, have demonstrated immunohistological changes in pancreatic islets, including insulitis, to be rare among autoantibody-positive adults (10–12). Thus, it was of great interest to evaluate whether this patient’s GADA positivity, in the presence of GDM, associated with unique immunohistological features of type 1 diabetes in the pancreatic islets and to compare the findings observed in the pancreata of GADA-positive persons without diabetes or individuals with recent-onset type 1 diabetes. For this purpose, the pancreas was evaluated for islet expression of insulin and islets with ≥6 CD3⁺ T cells. The pancreas of this patient showed numerous islets with insulin (Fig. 1A and B), an observation consistent with the noted serum C-peptide level of 10.54 ng/mL, indicating the potential for active insulin production. However, islets with low β-cell to α-cell ratios (Fig. 1C) and “pseudoatrophic” islets (i.e., insulin-negative) (Fig. 1D) were also seen. This latter finding was most intriguing because pseudoatrophic islets are considered a pathognomonic feature of the type 1 diabetes pancreas, reflective of β-cell destruction (11). Moreover, 44 of 2,026 (2.2%) pancreatic islets examined (methods as previously described by Campbell-Thompson et al. [11]) from nine blocks encompassing the pancreas head, body, and tail regions demonstrated CD3⁺ infiltration (insulitis), another classic feature of type 1 diabetes (13). The observed insulitis was mild. The average number of CD3⁺ cells per infiltrated islet in the donor 6310 pancreas was 9.2 ± 0.9 cells (mean ± SEM; range 6–21) inside (intrainsulitis) (Fig. 2A) or in the islet periphery (peri-insulitis) (Fig. 2B and C) compared with 0.1 ± 0.05 CD3⁺ cells per islet in control pancreata from three Hispanic female organ donors aged 21, 24, and 26 years. Other noteworthy findings included multifocal, mild chronic interstitial fibrosis, which has also been reported in GADA⁺ single-autoantibody pancreas donors (12). The residual β-cell mass was found to be 763 mg (methods as previously described by Campbell-Thompson et al. [11]), with a pancreas weight of 82.83 g and a relative pancreas weight of 1.24 g/kg (calculated as previously described by Campbell-Thompson et al. [14]). Approximately 5–10% of GDM cases may be associated with autoantibody positivity (5), and it is reasonable to suspect that the presence of autoantibodies reflects autoimmune destruction of pancreatic β-cells (2). However, direct histological evidence within the literature is lacking. The T-cell infiltration observed in this patient clearly resembles the insulitis found in individuals without diabetes positive for multiple type 1 diabetes–associated autoantibodies (e.g., GADA⁺IA-2A⁺ nPOD 6267 [Fig. 2D–F]) and as represented by a patient with recent-onset type 1 diabetes (e.g., GADA⁺ nPOD 6362 [Fig. 2G–I]).

It is well known that at the onset of type 1 diabetes, a majority of patients have circulating autoantibodies against single or multiple islet cell antigens and demonstrate insulitis in the pancreas. The autoantibodies can be detected in the circulation many years before disease onset. However, their role in initiating and perpetuating the autoimmune process in pancreatic islets is not completely established (13). Here, we present what we believe is an extremely rare, histology-based report of a patient positive for GADA and ICA who, in the presence of GDM, developed insulitis, as well as pseudoatrophic islets reflective of autoimmune type 1 diabetes–like loss of β-cells. Without prior medical history and longitudinal autoantibody measurements, it is not possible to ascertain from this single case a role for GDM in contributing to anti–β-cell autoimmunity, but taken together, it seems plausible to question whether the major physiological changes related to pregnancy and/or GDM may have been a potential factor that enhanced diabetes progression to the degree that eventually, had she not died of complications related to pregnancy, she would have subsequently developed overt type 1 diabetes or latent autoimmune diabetes in adults (LADA) (15). Future clinical and histopathological research of autoantibody-positive GDM is needed to improve our understanding of autoimmune diabetes during and following pregnancy.
