7. Diabetes Technology: Standards of Medical Care in Diabetes—2020

Diabetes technology is the term used to describe the hardware, devices, and software that people with diabetes use to help manage their condition, from lifestyle to blood glucose levels. Historically, diabetes technology has been divided into two main categories: insulin administered by syringe, pen, or pump, and blood glucose monitoring as assessed by meter or continuous glucose monitor. More recently, diabetes technology has expanded to include hybrid devices that both monitor glucose and deliver insulin, some automatically, as well as software that serves as a medical device, providing diabetes self-management support. Diabetes technology, when coupled with education and follow-up, can improve the lives and health of people with diabetes; however, the complexity and rapid change of the diabetes technology landscape can also be a barrier to patient and provider implementation.

• 7.1 Use of technology should be individualized based on a patient’s needs, desires, skill level, and availability of devices. Nonprofit websites can offer advice for providers and patients to determine the suitability of various options. E

Technology is rapidly changing, but there is no “one-size-fits-all” approach to technology use in people with diabetes. Insurance coverage can lag behind device availability, patient interest in devices and willingness to change can vary, and providers may have trouble keeping up with newly released technology. Not-for-profit websites such as DiabetesWise.org (1) and others can help providers and patients make decisions as to the initial choice of devices. Other sources, including health care providers and device manufacturers, can help people troubleshoot when difficulties arise.

• 7.2 Most patients using intensive insulin regimens (multiple daily injections or insulin pump therapy) should be encouraged to assess glucose levels using self-monitoring of blood glucose (and/or continuous glucose monitoring) prior to meals and snacks, at bedtime, prior to exercise, when they suspect low blood glucose, after treating low blood glucose until they are normoglycemic, and prior to and while performing critical tasks such as driving. B

• 7.3 When prescribed as part of a diabetes self-management education and support program, self-monitoring of blood glucose may help to guide treatment decisions and/or self-management for patients taking less-frequent insulin injections. B

• 7.4 Although self-monitoring of blood glucose in patients on noninsulin therapies has not shown clinically significant reductions in A1C, it may be helpful when altering diet, physical activity, and/or medications (particularly medications that can cause hypoglycemia) in conjunction with a treatment adjustment program. E

• 7.5 When prescribing self-monitoring of blood glucose, ensure that patients receive ongoing instruction and regular evaluation of technique, results, and their ability to use data from self-monitoring of blood glucose to adjust therapy. E

• 7.6 Health care providers should be aware of medications and other factors, such as high-dose vitamin C and hypoxemia, that can interfere with glucose meter accuracy and provide clinical management as indicated. E

• 7.7 Providers should be aware of the differences in accuracy among glucose meters—only U.S. Food and Drug Administration–approved meters should be used with unexpired strips, purchased from a pharmacy or licensed distributor. E

Major clinical trials of insulin-treated patients have included self-monitoring of blood glucose (SMBG) as part of multifactorial interventions to demonstrate the benefit of intensive glycemic control on diabetes complications (2). SMBG is thus an integral component of effective therapy of patients taking insulin. In recent years, continuous glucose monitoring (CGM) has emerged as a method for the assessment of glucose levels (discussed below). Glucose monitoring allows patients to evaluate their individual response to therapy and assess whether glycemic targets are being safely achieved. Integrating results into diabetes management can be a useful tool for guiding medical nutrition therapy and physical activity, preventing hypoglycemia, and adjusting medications (particularly prandial insulin doses). The patient’s specific needs and goals should dictate SMBG frequency and timing or the consideration of CGM use.

SMBG accuracy is dependent on the instrument and user, so it is important to evaluate each patient’s monitoring technique, both initially and at regular intervals thereafter. Optimal use of SMBG requires proper review and interpretation of the data, by both the patient and the provider, to ensure that data are used in an effective and timely manner. In patients with type 1 diabetes, there is a correlation between greater SMBG frequency and lower A1C (3). Among patients who check their blood glucose at least once daily, many report taking no action when results are high or low (4). Patients should be taught how to use SMBG data to adjust food intake, exercise, or pharmacologic therapy to achieve specific goals. The ongoing need for and frequency of SMBG should be reevaluated at each routine visit to avoid overuse, particularly if SMBG is not being used effectively for self-management (4–6).

SMBG is especially important for insulin-treated patients to monitor for and prevent hypoglycemia and hyperglycemia. Most patients using intensive insulin regimens (multiple daily injections or insulin pump therapy) should be encouraged to assess glucose levels using SMBG (and/or CGM) prior to meals and snacks, at bedtime, occasionally postprandially, prior to exercise, when they suspect low blood glucose, after treating low blood glucose until they are normoglycemic, and prior to and while performing critical tasks such as driving. For many patients using SMBG, this will require testing up to 6–10 times daily, although individual needs may vary. A database study of almost 27,000 children and adolescents with type 1 diabetes showed that, after adjustment for multiple confounders, increased daily frequency of SMBG was significantly associated with lower A1C (–0.2% per additional test per day) and with fewer acute complications (7).

The evidence is insufficient regarding when to prescribe SMBG and how often testing is needed for insulin-treated patients who do not use intensive insulin regimens, such as those with type 2 diabetes using basal insulin with or without oral agents. However, for patients using basal insulin, assessing fasting glucose with SMBG to inform dose adjustments to achieve blood glucose targets results in lower A1C (8,9).

In people with type 2 diabetes not using insulin, routine glucose monitoring may be of limited additional clinical benefit. By itself, even when combined with education, it has showed limited improvement in outcomes (10–13). However, for some individuals, glucose monitoring can provide insight into the impact of diet, physical activity, and medication management on glucose levels. Glucose monitoring may also be useful in assessing hypoglycemia, glucose levels during intercurrent illness, or discrepancies between measured A1C and glucose levels when there is concern an A1C result may not be reliable in specific individuals. It may be useful when coupled with a treatment adjustment program. In a year-long study of insulin-naive patients with suboptimal initial glycemic stability, a group trained in structured SMBG (a paper tool was used at least quarterly to collect and interpret seven-point SMBG profiles taken on 3 consecutive days) reduced their A1C by 0.3% more than the control group (14). A trial of once-daily SMBG that included enhanced patient feedback through messaging found no clinically or statistically significant change in A1C at 1 year (13). Meta-analyses have suggested that SMBG can reduce A1C by 0.25–0.3% at 6 months (15–17), but the effect was attenuated at 12 months in one analysis (15). Reductions in A1C were greater (−0.3%) in trials where structured SMBG data were used to adjust medications, but A1C was not changed significantly without such structured diabetes therapy adjustment (17). A key consideration is that performing SMBG alone does not lower blood glucose levels. To be useful, the information must be integrated into clinical and self-management plans.

Although many meters function well under a variety of circumstances, providers and people with diabetes need to be aware of factors that can impair meter accuracy. A meter reading that seems discordant with clinical reality needs to be retested or tested in a laboratory. Providers in intensive care unit settings need to be particularly aware of the potential for abnormal meter readings, and laboratory-based values should be used if there is any doubt. Some meters give error messages if meter readings are likely to be false (18).

Currently available glucose monitors utilize an enzymatic reaction linked to an electrochemical reaction, either glucose oxidase or glucose dehydrogenase (19). Glucose oxidase monitors are sensitive to the oxygen available and should only be used with capillary blood in patients with normal oxygen saturation. Higher oxygen tensions (i.e., arterial blood or oxygen therapy) may result in false low glucose readings, and low oxygen tensions (i.e., high altitude, hypoxia, or venous blood readings) may lead to false high glucose readings. Glucose dehydrogenase monitors are not sensitive to oxygen.

Because the reaction is sensitive to temperature, all monitors have an acceptable temperature range (19). Most will show an error if the temperature is unacceptable, but a few will provide a reading and a message indicating that the value may be incorrect.

There are a few physiologic and pharmacologic factors that interfere with glucose readings. Most interfere only with glucose oxidase systems (19). They are listed in Table 7.1.

Glucose meters meeting U.S. Food and Drug Administration (FDA) guidance for meter accuracy provide the most reliable data for diabetes management. There are several current standards for accuracy of blood glucose monitors, but the two most used are those of the International Organization for Standardization (ISO) (ISO 15197:2013) and the FDA. The current ISO and FDA standards are compared in Table 7.2. In Europe, currently marketed monitors must meet current ISO standards. In the U.S., currently marketed monitors must meet the standard under which they were approved, which may not be the current standard. Moreover, the monitoring of current accuracy is left to the manufacturer and not routinely checked by an independent source.

Patients assume their glucose monitor is accurate because it is FDA cleared, but often that is not the case. There is substantial variation in the accuracy of widely used blood glucose monitoring systems (20). The Diabetes Technology Society Blood Glucose Monitoring System Surveillance Program provides information on the performance of devices used for SMBG (diabetestechnology.org/surveillance). In a recent analysis, the program found that only 6 of the top 18 glucose meters met the accuracy standard (21).

Patients should be advised against purchasing or reselling preowned or second-hand test strips, as these may give incorrect results. Only unopened vials of glucose test strips should be used to ensure SMBG accuracy.

See Table 7.3 for definitions of types of CGM devices.

• 7.8 When prescribing continuous glucose monitoring (CGM) devices, robust diabetes education, training, and support are required for optimal CGM device implementation and ongoing use. People using CGM devices need to have the ability to perform self-monitoring of blood glucose in order to calibrate their monitor and/or verify readings if discordant from their symptoms. E

• 7.9 When used properly, real-time continuous glucose monitors in conjunction with insulin therapy are a useful tool to lower A1C levels and/or reduce hypoglycemia in adults with type 1 diabetes who are not meeting glycemic targets, have hypoglycemia unawareness, and/or have episodes of hypoglycemia. A

• 7.10 When used properly, intermittently scanned continuous glucose monitors in conjunction with insulin therapy are useful tools to lower A1C levels and/or reduce hypoglycemia in adults with type 1 diabetes who are not meeting glycemic targets, have hypoglycemia unawareness, and/or have episodes of hypoglycemia. C

• 7.11 When used properly, real-time and intermittently scanned continuous glucose monitors in conjunction with insulin therapy are useful tools to lower A1C and/or reduce hypoglycemia in adults with type 2 diabetes who are not meeting glycemic targets. B

• 7.12 Continuous glucose monitoring (CGM) should be considered in all children and adolescents with type 1 diabetes, whether using injections or continuous subcutaneous insulin infusion, as an additional tool to help improve glucose control. Benefits of CGM correlate with adherence to ongoing use of the device. B

• 7.13 Real-time continuous glucose monitoring (CGM) devices should be used as close to daily as possible for maximal benefit. Intermittently scanned CGM devices should be scanned frequently, at a minimum once every 8 h. A

• 7.14 Real-time continuous glucose monitors may be used effectively to improve A1C levels, time in range, and neonatal outcomes in pregnant women with type 1 diabetes. B

• 7.15 Blinded continuous glucose monitor data, when coupled with diabetes self-management education and medication dose adjustment, can be helpful in identifying and correcting patterns of hyper- and hypoglycemia in people with type 1 diabetes and type 2 diabetes. E

• 7.16 People who have been using continuous glucose monitors should have continued access across third-party payers. E

CGM measures interstitial glucose (which correlates well with plasma glucose). There are two basic types of CGM devices: those that provide unblinded data to the user and those that are blinded with data available to the patient and their health care provider for retrospective analysis. Table 7.3 provides the definitions for the types of CGM devices. For devices that provide patients unblinded data, most of the published randomized controlled trials (RCTs) have been performed using real-time CGM devices that have alarms and alerts. It is difficult to determine how much impact having these notices makes in terms of reacting to glucose levels. There is one small study in patients at risk for hypoglycemia that compares real-time CGM with intermittently scanned CGM (isCGM) (22). The study showed improvement in time spent in hypoglycemia with real-time CGM compared with isCGM.

Some real-time systems require calibration by the user, which varies in frequency depending on the device. Additionally, for some CGM systems, the FDA suggests SMBG for making treatment decisions. Devices that require SMBG confirmation are called “adjunctive,” while those that do not are called “nonadjunctive.” An RCT of 226 adults suggested that a CGM device could be used safely and effectively without regular confirmatory SMBG in patients with well-controlled type 1 diabetes at low risk of severe hypoglycemia (23). Two CGM devices are approved by the FDA for making treatment decisions without SMBG calibration or confirmation (24,25).

The abundance of data provided by CGM offers opportunities to analyze patient data more granularly than was previously possible, providing additional information to aid in achieving glycemic targets. A variety of metrics have been proposed (26) and are discussed in Section 6, “Glycemic Targets” (https://doi.org/10.21337/dc20-S006). CGM is essential for creating the ambulatory glucose profile (AGP) and providing data on time in range, percentage of time spent above and below range, and variability (27).

Data exist to support the use of real-time CGM in adults, both those on multiple daily injections (MDI) and continuous subcutaneons insulin infusion (CSII). In terms of RCTs in people with type 1 diabetes, there are four studies in adults with A1C as the primary outcome (28–32), three studies in adults with hypoglycemia as the primary outcome (33–35), four studies in adults and children with A1C as the primary outcome (36–39), and three studies in adults and children with hypoglycemia as a primary outcome (40–42).

In general, A1C reduction was shown in studies where the baseline A1C was higher. In two larger studies in adults with type 1 diabetes that assessed the benefit of real-time CGM in patients on MDI, there were significant reductions in A1C: –0.6% in one (28,29) and –0.43% in the other (30). No reduction in A1C was seen in a small study performed in underserved, less well-educated adults with type 1 diabetes (31). In the adult subset of the JDRF CGM study, there was a significant reduction in A1C of –0.53% (43) in patients who were primarily treated with insulin pump therapy. Better adherence in wearing the real-time CGM device resulted in a greater likelihood of an improvement in glycemic control (32,36).

In studies in adults where reduction in episodes of hypoglycemia was the primary end point, significant reductions were seen in individuals with type 1 diabetes on MDI or CSII (33–35). In one study in patients who were at higher risk for episodes of hypoglycemia (35), there was a reduction in rates of all levels of hypoglycemia (see Section 6 “Glycemic Targets,” https://doi.org/10.2337/dc20-S006, for hypoglycemia definitions). Real-time CGM may be particularly useful in insulin-treated patients with hypoglycemia unawareness and/or frequent hypoglycemic episodes, although studies have not been powered to show consistent reductions in severe (level 3) hypoglycemia (36–38).

isCGM does not currently provide alarms and alerts but is an option used by many patients. There is relatively little RCT data proving benefit in people with type 1 diabetes. One study, designed to show a reduction in episodes of hypoglycemia in patients at higher risk for hypoglycemia, showed a significant benefit in terms of time spent in a hypoglycemic range (P < 0.0001) (33). Additional observational studies have shown benefit in terms of A1C reduction (44).

There are several published reviews of data available on isCGM (45–47). The Norwegian Institute of Public Health conducted an assessment of isCGM clinical effectiveness, cost-effectiveness, and safety for individuals with type 1 and type 2 diabetes, based on data available until January 2017 (45). The authors concluded that, although there were few quality data available at the time of the report, isCGM may increase treatment satisfaction, increase time in range, and reduce frequency of nocturnal hypoglycemia, without differences in A1C or quality of life or serious adverse events. The Canadian Agency for Drugs and Technologies in Health reviewed existing data on isCGM performance and accuracy, hypoglycemia, effect on A1C, and patient satisfaction and quality of life and concluded that the system could replace SMBG, particularly in patients who require frequent testing (46). A final review (47) also supported the use of isCGM as a more affordable alternative to real-time CGM systems for individuals with diabetes who are on intensive insulin therapy.

Studies in people with type 2 diabetes are heterogeneous in design—in two, participants were using basal insulin with oral agents or oral agents alone (48,49); in one, individuals were on MDI alone (50); and in another, participants were on CSII or MDI (42). The findings in studies with MDI alone (50) and in two studies in people using oral agents with or without insulin (48,49) showed significant reductions in A1C levels. The Multiple Daily Injections and Continuous Glucose Monitoring in Diabetes (DIAMOND) study in people with type 2 diabetes on MDI did not show a reduction in hypoglycemia (50), although it did show a reduction in A1C. Studies in individuals with type 2 diabetes on oral agents with or without insulin did not show reductions in rates of hypoglycemia (48,49).

In one study of isCGM in people with type 2 diabetes on a variety of insulin regimens and an initial A1C of ∼8.8%, no reduction in A1C was seen; however, the time spent in a hypoglycemic range was reduced by 43% (51). In a study of isCGM in individuals with type 2 diabetes on MDI, the A1C was reduced by 0.82% in the intervention group and 0.33% in the control group (P = 0.005) with no change in rates of hypoglycemia (52).

Data regarding use of real-time CGM in youth consist of findings from RCTs and small observational studies as well as analysis of data collected by registries. Seven RCTs have included both adult and pediatric participants (36–42), while others have only included pediatric participants (53) or limited the analysis of larger studies to just the pediatric participants (36). Given the feasibility problems of performing RCTs in very young children, small observational studies have also provided data on real-time CGM use in the youngest age-groups (54–56). Finally, while limited by the observational nature, registry data provide some evidence of real-world use of the technologies (43,57).

When data from adult and pediatric participants are analyzed together, real-time CGM use in RCTs has been associated with reduction in A1C levels (37–39). Yet in the JDRF CGM trial, when youth were analyzed by age-group (8- to 14-year-olds and 15- to 24-year-olds), no change in A1C was seen, likely due to poor real-time CGM adherence (36). Indeed, in a secondary analysis of that RCT’s data in both pediatric cohorts, those who used the sensor ≥6 days/week had an improvement in their glycemic control (58). One critical component to success with CGM is near-daily wearing of the device (37,59–61).

Though data from small observational studies demonstrate that real-time CGM can be worn by patients <8 years old and the use of real-time CGM provides insight to glycemic patterns (54,55), an RCT in children aged 4–9 years did not demonstrate improvements in glycemic control following 6 months of real-time CGM use (53). However, observational feasibility studies of toddlers demonstrated a high degree of parental satisfaction and sustained use of the devices despite the inability to change the degree of glycemic control attained (56).

Registry data has also shown an association between real-time CGM use and lower A1C levels (43,57), even when limiting assessment of real-time CGM use to participants on injection therapy (57).

There are no studies solely including pediatric patients that assess rates of hypoglycemia as the primary outcome. Some of the studies where pediatric and adult patients were combined together did show potential reductions in hypoglycemia (10,62,63).

Data on use of isCGM in children come from observational studies. In these reports, isCGM is favorably adopted and is associated with improvements in outcomes (64–67).

For patients with type 1 diabetes using real-time CGM, an important predictor of A1C lowering for all age-groups was frequency of sensor use (36). In this study, overall use was highest in those aged ≥25 years (who had the most improvement in A1C) and lower in younger age-groups.

One well-designed RCT showed a reduction in A1C levels in adult women with type 1 diabetes on MDI or CSII who were pregnant (68). Neonatal outcomes were better when the mother used CGM during pregnancy (28). Two studies employing intermittent use of real-time CGM showed no difference in neonatal outcomes in women with type 1 diabetes (69) or gestational diabetes mellitus (70).

Blinded CGM devices, which provide retrospective data for analysis, can be used to identify patterns of hypo- and hyperglycemia. While minimal RCT data exist to support their use, in some settings, blinded CGM can be helpful to evaluate patients when either real-time or isCGM is not available to the patient or the patient prefers a blinded analysis. It can be particularly useful to evaluate periods of hypoglycemia in patients on agents that can cause hypoglycemia for making medication dose adjustments. It can also be useful to evaluate for periods of hyperglycemia. Use of blinded CGM should always be coupled with analysis and interpretation for the patient, along with education as needed to adjust medication and change lifestyle behaviors.

Contact dermatitis has been reported with all devices that attach to the skin (71). In some cases this has been linked to the presence of isobornyl acrylate, which is a skin sensitizer and can cause an additional spreading allergic reaction (72–74). Patch testing can be done to identify the cause of the contact dermatitis (75).

• 7.17 For people with diabetes who require insulin, insulin syringes or insulin pens may be used for insulin delivery with consideration of patient preference, insulin type and dosing regimen, cost, and self-management capabilities. B

• 7.18 Insulin pens or insulin injection aids may be considered for patients with dexterity issues or vision impairment to facilitate the administration of accurate insulin doses. C

• 7.19 Patients using insulin should have an examination of insulin injection/infusion sites on a routine basis—at least annually and if there are clinical issues related to insulin delivery. E

• 7.20 Smart pens may be useful for some patients to help with dose capture and dosing recommendations. E

• 7.21 U.S. Food and Drug Administration–approved insulin dose calculators/decision support systems may be helpful for titrating insulin doses. E

• 7.22 Competent patients using diabetes devices should be allowed to use them in an inpatient setting when proper supervision is available. E

Injecting insulin with a syringe or pen is the insulin delivery method used by most people with diabetes (76,77), although inhaled insulin is also available. Others use insulin pumps or automated insulin delivery devices (see sections on those topics below). For patients with diabetes who use insulin, insulin syringes and pens are both able to deliver insulin safely and effectively for the achievement of glycemic targets. When choosing among delivery systems, patient preferences, cost, insulin type and dosing regimen, and self-management capabilities should be considered. It is important to note that while many insulin types are available for purchase as either pens or vials, others may only be available in one form or the other and there may be significant cost differences between pens and vials (see Table 9.3 for a list of insulin product costs with dosage forms). Insulin pens may allow people with vision impairment or dexterity issues to dose insulin accurately (78–80), while insulin injection aids are also available to help with these issues. (For a helpful list of injection aids, see main.diabetes.org/dforg/pdfs/2018/2018-cg-injection-aids.pdf.) Inhaled insulin can be useful in people who have an aversion to giving injections.

The most common syringe sizes are 1 mL, 0.5 mL, and 0.3 mL, allowing doses of up to 100 units, 50 units, and 30 units of U-100 insulin, respectively. In a few parts of the world, insulin syringes still have U-80 and U-40 markings for older insulin concentrations and veterinary insulin, and U-500 syringes are available for the use of U-500 insulin. Syringes are generally used once but may be reused by the same individual in resourcelimited settings with appropriate storage and cleansing (81).

Insulin pens offer added convenience by combining the vial and syringe into a single device. Insulin pens, allowing pushbutton injections, come as disposable pens with prefilled cartridges or reusable insulin pens with replaceable insulin cartridges. Some reusable pens include a memory function, which can recall dose amounts and timing. “Smart” pens that can be programmed to calculate insulin doses and provide downloadable data reports are also available. Pens also vary with respect to dosing increment and minimal dose, which can range from half-unit doses to 2-unit dose increments.

Needle thickness (gauge) and length is another consideration. Needle gauges range from 22 to 33, with higher gauge indicating a thinner needle. A thicker needle can give a dose of insulin more quickly, while a thinner needle may cause less pain. Needle length ranges from 4 to 12.7 mm, with some evidence suggesting shorter needles may lower the risk of intramuscular injection. When reused, needles may be duller and thus injection more painful. Proper insulin technique is a requisite to obtain the full benefits of insulin injection therapy, and concerns with technique and using the proper technique are outlined in Section 9 “Pharmacologic Approaches to Glycemic Treatment” (https://doi.org/10.2337/dc20-S009).

Another insulin delivery option is a disposable patch-like device, which provides a continuous, subcutaneous infusion of rapid-acting insulin (basal), as well as 2 unit increments of bolus insulin at the press of a button (82).

Bolus calculators have been developed to aid in dosing decisions (83–87). These are subject to FDA approval to ensure safety in terms of dosing recommendations. People who are interested in using these systems should be encouraged to use those that are FDA approved. Provider input and education can be helpful for setting the initial dosing calculations with ongoing follow-up for adjustments as needed.

• 7.23 Insulin pump therapy may be considered as an option for all adults, children, and adolescents with type 1 diabetes who are able to safely manage the device. A

• 7.24 Individuals with diabetes who have been successfully using continuous subcutaneous insulin infusion should have continued access across third-party payers. E

CSII or insulin pumps have been available in the U.S. for 40 years. These devices deliver rapid-acting insulin throughout the day to help manage blood glucose levels. Most insulin pumps use tubing to deliver insulin through a cannula, while a few attach directly to the skin, without tubing.

Most studies comparing MDI with CSII have been relatively small and of short duration. However, a recent systematic review and meta-analysis concluded that pump therapy has modest advantages for lowering A1C (−0.30% [95% CI −0.58 to −0.02]) and for reducing severe hypoglycemia rates in children and adults (88). There is no consensus to guide choosing which form of insulin administration is best for a given patient, and research to guide this decision-making is needed (89). Thus, the choice of MDI or an insulin pump is often based upon the individual characteristics of the patient and which is most likely to benefit him or her. Newer systems, such as sensor-augmented pumps and automatic insulin delivery systems, are discussed elsewhere in this section.

Adoption of pump therapy in the U.S. shows geographical variations, which may be related to provider preference or center characteristics (90,91) and socioeconomic status, as pump therapy is more common in individuals of higher socioeconomic status as reflected by race/ethnicity, private health insurance, family income, and education (91,92). Given the additional barriers to optimal diabetes care observed in disadvantaged groups (93), addressing the differences in access to insulin pumps and other diabetes technology may contribute to fewer health disparities.

Pump therapy can be successfully started at the time of diagnosis (94,95). Practical aspects of pump therapy initiation include assessment of patient and family readiness (although there is no consensus on which factors to consider in adults [96] or pediatric patients), selection of pump type and initial pump settings, patient/family education of potential pump complications (e.g., diabetic ketoacidosis [DKA] with infusion set failure), transition from MDI, and introduction of advanced pump settings (e.g., temporary basal rates, extended/square/dual wave bolus).

Complications of the pump can be caused by issues with infusion sets (dislodgement, occlusion), which place patients at risk for ketosis and DKA and thus must be recognized and managed early (97); lipohypertrophy or, less frequently, lipoatrophy (98,99); and pump site infection (100). Discontinuation of pump therapy is relatively uncommon today; the frequency has decreased over the past few decades, and its causes have changed (100,101). Current reasons for attrition are problems with cost, wearability, disliking the pump, suboptimal glycemic control, or mood disorders (e.g., anxiety or depression) (102).

The safety of insulin pumps in youth has been established for over 15 years (103). Studying the effectiveness of CSII in lowering A1C has been challenging because of the potential selection bias of observational studies. Participants on CSII may have a higher socioeconomic status that may facilitate better glycemic control (104) versus MDI. In addition, the fast pace of development of new insulins and technologies quickly renders comparisons obsolete. However, RCTs comparing CSII and MDI with insulin analogs demonstrate a modest improvement in A1C in participants on CSII (105,106). Observational studies, registry data, and meta-analysis have also suggested an improvement of glycemic control in participants on CSII (107–109). Although hypoglycemia was a major adverse effect of intensified insulin regimen in the Diabetes Control and Complications Trial (DCCT) (110), data suggest that CSII may reduce the rates of severe hypoglycemia compared with MDI (109,111–113).

There is also evidence that CSII may reduce DKA risk (109,114) and diabetes complications, in particular, retinopathy and peripheral neuropathy in youth, compared with MDI (62). Finally, treatment satisfaction and quality-of-life measures improved on CSII compared with MDI (115,116). Therefore, CSII can be used safely and effectively in youth with type 1 diabetes to assist with achieving targeted glycemic control while reducing the risk of hypoglycemia and DKA, improving quality of life and preventing long-term complications. Based on patient–provider shared decision-making, insulin pumps may be considered in all pediatric patients. In particular, pump therapy may be the preferred mode of insulin delivery for children under 7 years of age (63). Because of a paucity of data in adolescents and youth with type 2 diabetes, there is insufficient evidence to make recommendations.

Common barriers to pump therapy adoption in children and adolescents are concerns regarding the physical interference of the device, discomfort with idea of having a device on the body, therapeutic effectiveness, and financial burden (107,117).

Certain patients with insulin deficiency, for instance those with long standing type 2 diabetes, those who have had a pancreatectomy, and/or individuals with cystic fibrosis may benefit from insulin pump therapy. This is an individual decision and must be tailored to fit patient needs and preferences.

Older individuals with type 1 diabetes benefit from ongoing insulin pump therapy. There is no data to suggest that measurement of C-peptide levels or antibodies predicts success with insulin pump therapy (118,119). Additionally, frequency of follow-up does not influence outcomes. Access to insulin pump therapy should be allowed/continued in older adults as it is for younger people.

• 7.25 Sensor-augmented pump therapy with automatic low glucose suspend may be considered for adults and children with type 1 diabetes to prevent/mitigate episodes of hypoglycemia. B

• 7.26 Automated insulin delivery systems may be considered in children B and adults with type 1 diabetes to improve glycemic control. A

• 7.27 Individual patients may be using systems not approved by the U.S. Food and Drug Administration such as do-it-yourself closed loop systems and others; providers cannot prescribe these systems but can provide safety information/troubleshooting/backup advice for the individual devices to enhance patient safety. E

Sensor-augmented pumps that suspend insulin when glucose is low or predicted to go low within the next 30 min have been approved by the FDA. The Automation to Simulate Pancreatic Insulin Response (ASPIRE) trial of 247 patients with type 1 diabetes and documented nocturnal hypoglycemia showed that sensor-augmented insulin pump therapy with a low glucose suspend function significantly reduced nocturnal hypoglycemia over 3 months without increasing A1C levels (39). In a different sensor-augmented pump, predictive low glucose suspend reduced time spent with glucose <70 mg/dL from 3.6% at baseline to 2.6% (3.2% with sensor-augmented pump therapy without predictive low glucose suspend) without rebound hyperglycemia during a 6-week randomized crossover trial (120). These devices may offer the opportunity to reduce hypoglycemia for those with a history of nocturnal hypoglycemia. Additional studies have been performed, in adults and children, showing the benefits of this technology (121,122).

Automated insulin delivery systems increase and decrease insulin delivery based on sensor derived glucose level to begin to approximate physiologic insulin delivery. These systems consist of three components: an insulin pump, a continuous glucose sensor, and an algorithm that determines insulin delivery. With these systems, insulin delivery can not only be suspended but also increased or decreased based on sensor glucose values. Emerging evidence suggests such systems may lower the risk of exercise-related hypoglycemia (123) and may have psychosocial benefits (124–127).

While eventually insulin delivery in closed-loop systems may be truly automated, currently meals must be announced. A so-called hybrid approach, hybrid closed-loop, has been adopted in first-generation closed-loop systems and requires users to bolus for meals and snacks. Multiple studies, utilizing a variety of systems with varying algorithms, pump, and sensors have been performed in adults and children (128–138). Use of these systems depends on patient preference and selection of patients (and/or caregivers) who are capable of safely and effectively using the devices.

Some people with type 1 diabetes have been using “do-it-yourself” (DIY) systems that combine a pump and a real-time CGM with a controller and an algorithm designed to automate insulin delivery (139–141). These systems are not approved by the FDA, although there are efforts underway to obtain regulatory approval for them. The information on how to set up and manage these systems is freely available on the internet, and there are internet groups where people inform each other as to how to set up and use them. Although not prescribed by providers, it is important to keep patients who are using these methods for automated insulin delivery safe. Part of this entails making sure people have a “backup plan” in case of pump failure. Additionally, in most DIY systems, insulin doses are adjusted based on the pump settings for basal rates, carbohydrate ratios, correction doses, and insulin activity. Therefore, these settings can be evaluated and changed based on the patient’s insulin requirements.

Increasingly, people are turning to the internet for advice, coaching, connection, and health care. Diabetes, in part because it is both common and numeric, lends itself to the development of apps and online programs. The FDA approves and monitors clinically validated, digital, usually online, health technologies intended to treat a medical or psychological condition—these are known as digital therapeutics or “digiceuticals” (142). Other applications, such as those that assist in displaying or storing data, encourage a healthy lifestyle or provide limited clinical data support. Therefore, it is possible to find apps that have been fully reviewed and approved and others designed and promoted by people with relatively little skill or knowledge in the clinical treatment of diabetes.

An area of particular importance is that of online privacy and security. There are established cloud-based data collection programs, such as Tidepool, Glooko, and others, that have been developed with appropriate data security features and are HIPAA (U.S. Health Insurance Portability and Accountability Act of 1996) compliant. These programs can be useful for monitoring patients, both by the patients themselves as well as their health care team (143). Consumers should read the policy regarding data privacy and sharing before providing data into an application and learn how they can control how their data will be used (some programs offer the ability to share more or less information, such as being part of a registry or data repository or not).

There are many online programs that offer lifestyle counseling to aid with weight loss and increase physical activity (144). Many of these include a health coach and can create small groups of similar patients in social networks. There are programs that aim to treat prediabetes and prevent progression to diabetes, often following the model of the Diabetes Prevention Program (145,146). Others assist in improving diabetes outcomes by remotely monitoring patient clinical data (for instance, wireless monitoring of glucose levels, weight, or blood pressure) and providing feedback and coaching (147–149). There are text messaging approaches that tie into a variety of different types of lifestyle and treatment programs, which vary in terms of their effectiveness (150,151). For many of these interventions, there are limited RCT data and long-term follow-up is lacking. But for an individual patient, opting into one of these programs can be helpful and, for many, is an attractive option.

Patients who are comfortable using their diabetes devices, such as insulin pumps and sensors, should be given the chance to use them in an inpatient setting if they are competent to do so (152,153). Patients who are familiar with treating their own glucose levels can often adjust insulin doses more knowledgably than inpatient staff who do not personally know the patient or their management style. However, this should occur based on the hospital’s policies for diabetes management, and there should be supervision to be sure that the individual can adjust their insulin doses in a hospitalized setting where factors such as infection, certain medications, immobility, changes in diet, and other factors can impact insulin sensitivity and the response to insulin.

The pace of development in diabetes technology is extremely rapid. New approaches and tools are available each year. It is hard for research to keep up with these advances because by the time a study is completed, newer versions of the devices are already on the market. The most important component in all of these systems is the patient. Technology selection must be appropriate for the individual. Simply having a device or application does not change outcomes unless the human being engages with it to create positive health benefits. This underscores the need for the health care provider to assist the patient in device/program selection and to support its use through ongoing education and training. Expectations must be tempered by reality—we do not yet have technology that completely eliminates the self-care tasks necessary for treating diabetes, but the tools described in this section can make it easier to manage.
