Effects of a Single Bout of Interval Hypoxia on Cardiorespiratory Control in Patients With Type 1 Diabetes

This placebo-controlled single-blinded study was carried out in fifteen patients with type 1 diabetes (2 females and 13 males) without clinical evidence of respiratory disease or definite autonomic abnormalities. The protocol was approved by the ethics committee of the University of Helsinki, and the study was conducted in accordance with the ethics standards defined in the Declaration of Helsinki. All subjects received extensive information of the study process, and written informed consent was obtained. Inclusion criteria were stable diabetes; absence of infections during the last month; absence of major cardiovascular complications such as coronary heart disease, unstable or stable angina, myocardial infarction, ventricular arrhythmias, and atrial fibrillation; therapy with β-blockers; severe hypertension (>180 mmHg systolic or >110 mmHg diastolic blood pressure); definite autonomic dysfunction; or proliferative retinopathy. Age limit for the selection of subjects was 20–45 years. All patients were on insulin treatment. In addition, five patients received antihypertension medications (angiotensin receptor inhibitors [1] and ACE inhibitors [4]). The patients maintained the same therapy during IH and placebo day. The clinical and anthropometric characteristics of the participants are reported in Table 1.

Measurement sessions were performed on two different days at least 5–7 days apart to exclude possible “learning” effects. On 1 day, the patients underwent the intermittent hypoxic protocol (hypoxia day), whereas on the other day room air was administered using the same protocol (placebo day). Baseline data were obtained in the morning of each testing day at least 2 h after breakfast. Subjects were advised to abstain from caffeinated beverages for 12 h and from alcohol for 36 h prior to testing. For avoidance of possible learning effects from one day to the other, the sequence of hypoxia or placebo day was randomized. Hypoxic or placebo exposures occurred during 1 h in the morning under standardized conditions after completion of baseline (t1) measurements (Fig. 1). During the hypoxia day, each hypoxia session consisted of five hypoxic periods (13% O₂ inspired fraction of oxygen) each lasting 6 min, with five normoxic intervals of same duration. During the normoxia day, the breathing program was performed in the same way, but the subjects inhaled normoxic air. On both days, participants were breathing hypoxic or normoxic air through a facial mask during the 1-h protocol. In each session, blood pressure (Finapres; FMS Medical Systems, Amsterdam, the Netherlands) and heart rate and arterial oxygen saturation (COSMOplus; Novametrix, Wallingford, CT) were continuously measured. In case of a decrease in oxygen saturation <80% or the occurrence of symptoms, hypoxia would have been discontinued until oxygen levels reached at least 80%. A technician regulated and controlled the breathing periods under supervision of a medical doctor in a way that the intervention could not be observed by any patient. Thereafter, three measurement sessions were performed: immediately after (t2), after 3 h (t3), and after 6 h (t4). After t2, each patient obtained an individual meal according to diet requirement that was equal on both testing days. Continuous acquisition of all signals to a personal computer was performed at 600 samples/channel.

Hypoxic ventilatory response (HVR) and hypercapnic ventilatory response (HCVR) were evaluated to determine respiratory system activity. All patients were tested in the supine position in a silent room at comfortable temperature. Before participants were connected to a rebreathing circuit through a mouthpiece with an antibacterial filter (18,31,32), spontaneous breathing of room air at rest was performed for 4 min in order to obtain baseline data.

During each condition, we performed continuous measurement of oxygen saturation (SaO₂) by a pulse oxymeter and end-tidal CO₂ (CO₂-et) using a capnograph connected to a mouthpiece (COSMOplus). Recordings of electrocardiogram were performed by chest leads, and continuous noninvasive blood pressure was recorded using the cuff method (Finapres). A heated Fleish pneumotachograph (Metabo, Epalinges, Switzerland) connected to a differential pressure transducer (RS part N395-257; RS Components, Corby, U.K.), was inserted in series to the expiratory component of the rebreathing system to measure airway flow.

For measurement of the response to hypoxia, the participants were connected to a rebreathing circuit inducing progressive decrease in SaO₂ while maintaining CO₂-et values at constant levels, until SaO₂ reached 80%, and measuring breath-to-breath changes in minute ventilation. The response to hypercapnia was evaluated by ventilatory changes induced by progressive increase in CO₂-et levels (up to 13 mmHg above resting levels), while SaO₂ was maintained >98% by oxygen at very low flow (18,32).

Cardiovascular autonomic function was determined performing four tests according to recent guidelines (33): deep-breathing, 30:15 ratio, Valsalva maneuver, and systolic blood pressure response to standing. Cardiovascular autonomic neuropathy was defined as the “presence of two or more abnormal tests” (33).

The slope of the linear regression line of minute ventilation versus SaO₂ or CO₂-et indicated in each case the chemoreflex sensitivity to hypoxia or hypercapnia. In the hypercapnic test, the point at which the ventilation started to increase was indicated as ventilatory recruitment threshold to CO₂ (VRT- CO₂) (Fig. 2). VRT- CO₂ was identified by interpolating the ventilation/CO₂-et plot by a fourth-order polynomial function (18,32).

The baroreflex sensitivity (BRS) was measured during spontaneous breathing at each measurement session. Since previous studies did not document a better performance of one method over the others (34), we calculated the average of seven different methods as previously described (35): positive and negative sequences, the α-coefficient in the low- and high-frequency bands and its average, the transfer function technique, and the ratio of SDs of R-R interval and systolic blood pressure variabilities (35). Besides BRS, SD of the R-R interval (SDNN) was applied to determine a global index of heart rate variability. This selection was done based on the fact that normal distribution is more pronounced in this variable compared with other indices of variability (e.g., variance).

Venous blood samples were drawn in the morning after a light breakfast and three times after hypoxic/placebo intervention in order to analyze erythrocyte and white blood cell count and for the determination of plasma glucose, HbA_1c, hemoglobin content, serum C-reactive protein (sCRP), serum lactate, and creatinine. HbA_1c was determined by immunoturbidimetry (Medix Biochemica, Kauniainen, Finland), serum creatinine by routine enzymatic methods, and sCRP by serum immunoprecipitation (ThermoScientific, Vantaa, Finland). One 24-h urinary collection was used to analyze urinary albumin excretion rate by immunoturbidimetry.

Hypoxia-induced lipid peroxidation was measured as the amount of MDA in serum LDL particles using capture sandwich chemiluminescent immunoassay and monoclonal antibody specific for MDA-epitope (clone HMN-08_34) (36). The measurements reported are the ratios of MDA epitopes to total LDL, and the average of two separate assays both carried out using duplicate measurements for each sample was calculated.

Data are presented as means ± SEM. SPSS statistical software package 18 was used for data analysis. Probability values ≤0.05 (two-tailed) were considered statistically significant. Unpaired t test was used to detect differences between baseline data of both testing days and data obtained from healthy control subjects. In order to assess potential effects generated by the IH, differences in the hypoxia and placebo days versus baseline values were compared using paired t test. Moreover, paired t test was also used to compare the same time point data between the hypoxia and placebo days and to assess changes from baseline (t1).

All study participants succeeded in performing the hypoxia/placebo protocols and the test sessions. No adverse effects were observed. Complete results of the cardiorespiratory data are summarized in Table 2, and hematological and metabolic variables are presented in Table 3. In the 15 subjects tested, there were 2 subjects with abnormal deep-breathing tests and 1 subject with borderline orthostatic hypotension.

Compared with our reference database, baseline HCVR were reduced in the type 1 diabetic patients, and baseline VRT-CO₂ was shifted to the right. Variables obtained at baseline on the hypoxia and the placebo days were not different, verifying the reproducibility of the tests.

On the hypoxia day, we observed a significant increase after the intervention in the HCVR (Fig. 3) that persisted until 6 h from the exposure to hypoxia. Even when one subject with large increase in HCVR was excluded from the analysis, the increase was still significant compared with placebo (P = 0.01). A slight increase was seen also on the placebo day, but the extent of the increase was significantly lower than on the hypoxia day. VRT-CO₂ was significantly reduced immediately after the intervention on the hypoxia day, whereas it increased on the placebo day (Fig. 3). HVR also improved after the intervention during the hypoxia day but not during placebo (Fig. 3). This effect still persisted after 3 h from IH, and values tended to be elevated even after 6 h from exposure. Tidal volume, minute ventilation, and respiration rate did not change in the course of the day either during hypoxia or placebo. CO₂-et was significantly elevated after both hypoxia and placebo exposure and persisted until 6 h from exposure on both intervention days. There was no change in oxygen saturation after hypoxia or placebo exposure.

Despite a fairly long exposure to hypoxia, BRS did not show any significant reduction after the intervention. Similarly, no adverse changes were apparent after hypoxia exposure in mean R-R interval or in heart rate variability (SDNN). A transient increase in systolic blood and diastolic blood pressures was observed after intervention (t2) on the hypoxia day; however, blood pressures dropped 3 h later (the change was significant for diastolic blood pressure). During placebo, blood pressures remained unchanged.

Plasma glucose concentration decreased after hypoxic and placebo exposure without significant differences between the 2 days (Fig. 4). After 3 h from the intervention, the glucose levels remained reduced on placebo, whereas after hypoxia the values increased toward baseline levels again.

Lactate decreased transiently and significantly after the intervention on the hypoxia day. No such changes were apparent on the placebo day. No changes were observed in erythrocyte counts or hemoglobin concentrations. sCRP remained unchanged. Relative neutrophil count increased 3 and 6 h after IH, whereas relative lymphocyte count diminished 6 h from intervention on the hypoxia day. During the placebo day, the level of MDA in serum LDL declined; however, no changes were observed during IH (Table 3).

In the present investigation, we examined the impact of a single bout of IH on the cardiorespiratory function in patients with type 1 diabetes. The major new finding was that IH induces substantial increases in the ventilatory responses to hypoxia and hypercapnia. IH induced also a transient reduction in lactate levels, suggesting improved use of the aerobic pathway. Overall, our findings show potentially useful effects of an approach aimed at improving the adaptation to hypoxia in patients with type 1 diabetes.

As we investigated the effects of IH in type 1 diabetes for the very first time, we excluded subjects with autonomic complications for safety reasons. In addition, because of the unknown effects of IH in these patients, we considered a single bout of IH an intervention adequate for testing “how” the patients would respond to an exposure to IH. In order to test the achievable response, one needs a full IH protocol (lasting several weeks). The observation that no differences were apparent at baseline during the control and hypoxia day verified the reproducibility of our tests. Altogether, based on the positive directional changes in this preliminary study, larger studies of prolonged duration are justified.

Different alterations in diabetes indicate that hypoxia, which may play an important role in the complications of diabetes, is present in type 1 diabetes. In fact, although SaO₂ may remain within normal range, oxygen saturation at rest in diabetic patients is slightly reduced compared with that in healthy control subjects (10). The importance of this finding should not be overlooked: due to the s-shape of the hemoglobin dissociation curve, a small reduction in SaO₂ in the normoxic range implies a much larger reduction in arterial oxygen pressure. Because the arterial oxygen pressure is the actual input to the peripheral chemoreflexes, any reduction in this variable will induce sustained sympathetic activation. Evidences of hypoxia stem from the evidence of glycosylation of basal membranes in the lungs, leading to lung diffusion abnormalities (reduced diffusing capacity for carbon monoxide) (7). Skin oxygenation (TcPO₂) was found to be reduced (though interpreted as insufficient vascular control in several studies) (4), and abnormal blood flow, evidenced by increased venous PO₂ compatible with arterio-venous shunting, was observed (5). The decrease in oxygen transport as a result of glycosylation of hemoglobin shifts the oxygen dissociation curve to the left, thus making O₂ release to the tissue difficult (6). Obstructive sleep apnea (OSAS) (8) is a frequent finding in diabetes. Finally, growing evidence in patients with diabetes indicates impaired responses to hypoxia (27,28).

IH, a technique developed for adapting the body to the consequences of hypoxia, has been applied clinically by Russian physicians to elderly people and to patients with various diseases for many years (37,38). We have reported improved exercise tolerance in different diseases (14,19) and improved cardiovascular and respiratory reflexes in patients with chronic obstructive pulmonary disease (22). Similarly, a positive effect of IH on peripheral chemoreflex sensitivity emerged in healthy people (32).

The term “intermittent hypoxia” is often linked to OSAS, leading to elevated sympathetic activity (due to diminished oxygen supply to the organs and tissues) and increased risk for hypertension and cardiovascular diseases (11,39). In contrast, IH can generate beneficial effects (14,19). OSAS is actually characterized by very short exposures to hypoxia (approximately 30 s) that arise many times (hundreds) during nighttime, leading to a stress response because of lack of time for a compensatory effect (40). In contrast, IH is defined by exposures of longer duration (5 min–1 h), with less repetitions per day (1–5) and more time for recovery (>5 min). IH repeated over a few weeks induced an increase in parasympathetic activity and an improvement in BRS (18) (similar to the effects of physical training), whereas OSAS induces sympathetic hyperactivity and reduces BRS (similar to a stress response).

Although some investigations did not find alterations in HVR (41) or HCVR (42), many studies indicate that ventilatory responses to hypoxia (21–24) or hypercapnia (23–26) are decreased in diabetic patients, possibly increasing the risk for severe cardiovascular diseases. In the present investigation, the baseline hypercapnic response was subnormal and VRT-CO₂ was higher than normal. As a consequence, ventilation starts to increase only at higher CO₂-levels, and the same respiratory stimulus, i.e., CO₂ levels, result in a lower respiratory activity, respectively.

In this study, IH resulted in an increased activity in both peripheral and central chemoreflexes. Our finding of an evident increase in HCVR initiated by IH concurs with the observation from a previous study evaluating the effects of IH in patients with chronic obstructive pulmonary disease (18), whereas the elevation in HVR is in line with previous findings from a study in healthy subjects, showing an increased HVR after a 2-week intervention of IH (32). In the present investigation, we were able to show that the first changes already appeared after only one single session of IH. These early changes are compatible with an early adaptation (training effect) of the respiratory system.

Interestingly, the increase in HVR was possible by virtue of the decrease in VRT-CO₂ observed after the intervention. If VRT-CO₂ remained elevated, then ventilation could not be sustained during hypoxia, due to the consequent hypocapnia. Therefore, a shifting to the left of the VRT-CO₂ enables an increase in the activity of the peripheral chemoreflex (43). This same phenomenon is normally observed (to a greater extent) during the early phases of acclimatization to hypoxia induced by high altitude. Therefore, our findings seem to imitate an adaptive process normally occurring under exposure to hypoxia.

Generally, impaired cardiovascular control (evidenced by blunted BRS or diminished heart rate variability in diabetes [9,44]) is associated with increased morbidity in patients with diabetes (1,2). Previous findings from our group showed a decreased BRS in patients with type 1 diabetes, which nevertheless increased above normal levels by interventions such as deep breathing (3) or short-term oxygen administration (9), indicating that these autonomic impairments might be at least at an initial stage of the disease of a functional origin. Similarly, a full IH protocol improved a blunted BRS in patients with chronic obstructive pulmonary disease (18), although a reduction in BRS is normally seen in hypoxia. After one bout of IH, we did not find a reduction in BRS. We cannot exclude that this could be due to the relatively well-preserved autonomic status of our patients. Alternatively, a potential increase in BRS even after the hypoxia could have been suppressed by the insulin treatment in our participants. Insulin is known to stimulate sympathetic nervous system activity in turn depressing the vagal arm of the BRS (45). We observed an increased systolic and diastolic blood pressure immediately after IH exposure. This might be the result of sympathetic stimulation or a direct initial effect of reoxygenation on the arterial endothelium (9). The fact that we did not show other evidences of sympathetic activation after hypoxia remains compatible with an initial adaptation process and suggests that progression of the intervention might lead to an increased stimulation of the baroreflex and therefore increase the parasympathetic activity, with minor changes or even reduction in blood pressures (18).

Plasma glucose decreased similarly after intermittent hypoxic and placebo exposure. Contrary to our expectations, we did not find elevations of lactate levels after the IH intervention. Generally, acute exposure to hypoxia is known to increase lactate production owing to anaerobic metabolism and also owing to sympathetic activation (46). Conversely, the final effect of a complete IH protocol is a stimulation of the aerobic metabolism that shifts the lactate-load curve to the right during exercise (19). Thus, our results suggest that the aerobic metabolism could have already been stimulated by IH. According to the short duration of the intervention, erythrocyte counts, hemoglobin content, and hematocrit did not show an increase after the intervention. IH increased relative neutrophil count 3 and 6 h after IH and decreased relative lymphocyte count 6 h from intervention on hypoxia day, indicating a first physiological stress response of the body, an effect typically occurring after physical exercise (47) and after acute exposure to hypoxia (20). However, the rise in the ratio of neutrophil and lymphocyte counts (in relative values), a measure of physiological stress (48), did not reach statistical significance over daytime. This might be ascribed again to the very short duration of the intervention performed in our study, and this trend should be confirmed over a full IH protocol. Moreover, sCRP did not change during daytime, suggesting no effect on inflammation. During the placebo day, there was a decrease in the level of MDA in LDL particles over the observation time. Similar reduction was not seen during the intermitted hypoxia. These findings suggest that during IH, there is a moderate increase in lipid peroxidation and formation of free radicals in agreement with previous findings (30). A moderate increase in free radicals was suggested to be an important trigger for a counterregulatory response, similar to what was described for physical training (49). Therefore, if repeated a sufficient number of times, IH might induce physiological stress reactions that potentially might be supportive of an increase of the immune defenses of the body similar to that associated with moderate physical exercise training.

In the current study, we selected patients without clinical evidence of autonomic dysfunction, as this was the first time that IH was tested in type 1 diabetes. The responses to the intervention may thus vary in patients with more advanced disease. A marginal exposure to IH took place on the placebo day as well, as the testing of HVR was performed four times a day on the hypoxia and the placebo day. The oxygen applied to test HCVR might have contributed to the blood pressure changes observed in the present investigation.

In conclusion, in type 1 diabetes one single session of IH elicits an initial adaptation in the ANS, showing increased respiratory reflexes. Impaired function of the autonomic system is a common finding in diabetes and might be reversible, at least at an early stage of the disease if originating from a functional impairment. Our findings provide the basis for accomplishing further studies with daily repetitions of IH at a prolonged duration (the IH protocol implemented in our study normally lasts at least 2 weeks) that might strengthen the positive outcome observed with this initial study.
