HSP72 Is a Mitochondrial Stress Sensor Critical for Parkin Action, Oxidative Metabolism, and Insulin Sensitivity in Skeletal Muscle

Cellular stress resistance against inflammatory and metabolic insult is critical for disease prevention and longevity (1–3). The heat shock response is an evolutionarily conserved defense system engaged during stress (e.g., thermal stress, ultraviolet exposure, and nutrient oversupply) so as to maintain cellular homeostasis. Heat shock factor (HSF) 1 is a key transcription factor regulating the induction of a number of heat shock proteins (HSPs), each identified by molecular mass, e.g., HSP27, HSP40, HSP60, HSP72, and HSP90. We have focused our efforts studying HSP72, the isoform most highly induced during cellular stress and with chronic endurance exercise (4). Importantly, basal HSP72 levels and induction response to cellular stress are diminished in muscle from obese and type 2 diabetic patients (5,6).

To improve our understanding of the relationship between HSP72 expression and disease susceptibility, we experimentally elevated HSP72 specifically in muscle or globally in mice by genetic or pharmacologic means and found that this conferred protection against diet- and leptin deficiency–induced obesity and insulin resistance (6). We hypothesized that the protective effect of HSP72 to maintain insulin action may be due in part to prevention of proinflammatory signaling via c-jun N-terminal kinase (6). In addition to the potential direct effects of HSP72 in blocking inflammation, oxidative metabolism was elevated in muscle overexpressing HSP72 (6), and this was associated with reduced adipose tissue mass and increased circulating adiponectin levels, factors also associated with preservation of insulin action in the context of overnutrition (6). Although we have provided strong evidence of a relationship between HSP72 expression and insulin action, it has remained unclear whether reduced HSP72 levels are causal for insulin resistance and, if so, by what mechanism(s).

For the first time, we show that HSP72 translocates to depolarized mitochondria and is critical for regulating functionality of the E3 ubiquitin ligase Parkin, a protein involved in mitochondrial quality control (7). Herein we show that mice lacking HSP72 display glucose intolerance and skeletal muscle insulin resistance. Moreover, Parkin-null myotubes recapitulated the impairment in oxygen consumption and insulin action observed with a Parkin loss-of-function phenotype in HSP72 knockout (KO) mice. Thus our findings suggest a novel link between diminished HSP72 levels and Parkin inactivation that precipitate derangements in skeletal muscle mitochondrial function and insulin action.

Male wild-type (WT) and HSP72-KO (global null mutation of Hspa1a/Hspa1b genes; Mutant Mouse Regional Resource Center Repository) were obtained at 8 weeks of age. WT and KO animals were confirmed to be of pure C57BL/6 background (The Jackson Laboratory). Ten cohorts of HSP72-KO mice bred at the University of California, Los Angeles (UCLA), were used for in vivo and ex vivo investigation. Although substrain analysis of inbred cohorts revealed a 16–86% C57BL/6 J:N, specific end points, i.e., Parkin protein and insulin action, were similarly and consistently altered between the genotypes of multiple cohorts of animals. Subsequently, KO mice were backcrossed to WT C57BL/6J or mice with muscle-specific transgenic overexpression of HSP72 (mHSP72^Tg) (6) to obtain WT, HSP72 homozygous and heterozygous littermates with and without the muscle-specific transgene. Male Parkin-null and WT mice were obtained from The Jackson Laboratory at 10 weeks of age, and muscle was harvested at 12 weeks to obtain primary myotubes. All procedures were performed in accordance with the Guide for Care and Use of Laboratory Animals of the National Institutes of Health and were approved by the Animal Subjects Committee of UCLA. At age 8–10 weeks, WT and HSP72-KO animals were divided into two groups: basal versus insulin-stimulated. Animals were studied in the 6-h fasted condition unless otherwise specified as fed or starved (24 h). Ages in which the animals were studied are indicated in Table 1 and in the figure legends.

Animals were exposed to one acute heat treatment to assess the induction of HSP72 in WT and HSP72-KO mice. Prior to heat treatment, mice were anesthetized with a mouse cocktail of ketamine, xylazine, and acepromazine maleate as described previously (8). While unconscious, a rectal thermometer was inserted, and mice were placed in a ventilated plastic container wrapped with a heating blanket (6). During heat treatment, body temperature was allowed to rise gradually (10–15 min) to 41.5°C and was maintained at this temperature for a total of 15 min. Animals were euthanized and tissues harvested 30 min after treatment.

To assess whether Parkin protein is degraded by the lysosome under basal conditions, 6-h fasted WT mice were treated for 1 h with leupeptin (L2884, Sigma-Aldrich; 40 mg/kg; intraperitoneal injection) to inhibit lysosomal proteases. Quadriceps muscle was harvested for Parkin and LC3B immunoblot analyses.

Blood was drawn from 6-h fasted 8-, 20-, 28-week-old mice and analyzed for circulating factors: insulin, leptin, resistin (Multiplex, Millipore), and adiponectin (radioimmunoassay; Millipore). Intraperitoneal glucose tolerance tests (GTTs; 1 g/kg dextrose) were performed on 6-h fasted mice as previously described (8,9). In a separate cohort of animals, mice were acclimated to the metabolic chambers (Columbus Instruments) over the first 24 h, and ambulatory movement was recorded over the subsequent 48 h.

At 28 weeks of age, dual catheters were surgically placed in the right jugular vein, and glucose clamp studies were performed 3 days postsurgery as previously described (8–10).

Muscle lysates were incubated with AMP-activated protein kinase (AMPK) α1- and α2-specific antibody-bound protein A agarose beads for 2 h. Sample immunocomplexes were washed and enzyme activity determined in the presence of 200 mmol/L AMP using SAMS peptide as described previously (11).

Fatty acid oxidation and esterification assays were performed on isolated soleus muscle as previously described (12).

At 8–12 weeks of age, primary skeletal muscle myoblasts were isolated from WT, HSP72-KO, and Parkin-KO mice as previously described (13). Myoblasts were cultured to confluence then differentiated to myotubes in Dulbecco’s modified Eagle’s medium (DMEM)/5% horse serum for 5–7 days before experimentation.

Cloning was performed using Gateway technology (Invitrogen). The mouse hspa1b open reading frame (ORF) entry clone was obtained from Open Biosystems (Thermo Scientific). HSP72-GFP and HSP72-pAD were generated by shuttling the hspa1b-ORF into pcDNA-DEST47 and pAd/CMV/V5-DEST, respectively, using LR Clonase Enzyme Mix II as per manufacturer’s instructions (Invitrogen). Parkin YFP (Addgene plasmid #23955), pDsRed2-mito, and mitofusin (Mfn) 2 plasmids were kind gifts from Antonio Zorzano (IRB Barcelona, Spain). HA Parkin and V5 Mfn2 entry clones were generated by BP-cloning (Gateway, Invitrogen) the ORF into pDONR221 using Parkin YFP and Mfn2 plasmids as templates, respectively. Inserts were then shuttled into custom Gateway N-Term HA- and V5-plasmids, respectively, using LR Clonase as described above. All positive clones were confirmed and sequenced for accuracy. Transfections were performed using Lipofectamine 2000 and PLUS reagent according to the manufacturer’s instructions (Invitrogen).

HEK293A cells (ATCC) and Neuro2A (N2a; a gift from Douglas Black, UCLA) cells were maintained in DMEM containing 10% FBS and penicillin/streptomycin at 5% CO₂ and 37°C. C2C12 myoblasts (ATCC) were maintained and proliferated in DMEM/10% FBS and differentiated in DMEM/2% horse serum. Cell treatments were performed as follows, unless otherwise stated: MG132 (Sigma; cell permeable proteasomal inhibitor used to reduce the degradation of ubiquitin-conjugated proteins) at 20 μmol/L for 4 h, carbonyl cyanide m-chlorophenyl hydrazone (Sigma; CCCP was used to inhibit oxidative phosphorylation by collapsing the mitochondrial proton gradient) at 20 μmol for 4 h, bafilomycin A1 (Baf; Sigma; a selective inhibitor of vacuolar H⁺-ATPases and thought to inhibit autophagy by blocking autophagosome–lysosome fusion and lysosomal degradation) at 25 nmol/L for 4 h, rotenone (specific inhibitor of electron transfer from iron–sulfur centers in mitochondrial complex I to ubiquinone) at 2 μmol/L for 4 h, antimycin (binds cytochrome c reductase inhibiting the oxidation of ubiquinol disrupting the proton gradient and ATP production) 40 μmol/L for 4 h, and starvation (Hanks’ balanced salt solution: PBS 1:1 plus 1% horse serum) for 4 h. Imatinib (STI-571), a tyrosine kinase inhibitor prescribed in the treatment of multiple cancers, was used at 10 μmol/L for 24 h to inhibit cABL from phosphorylating Parkin and altering its activity in HEK293A cells (14). Cellular heat shock was performed by placing cells at 42°C for 6 h with a 2-h recovery at 37°C prior to harvest as previously described (6).

Cultured skeletal muscle cell glucose uptake was performed in 12-well culture plates using the 2-deoxyglucose method described previously (10).

Mitochondrial respiration (oxygen consumption) in cultured skeletal muscle cells was measured using an XF24 Extracellular Flux Analyzer (Seahorse Biosciences). Briefly, cells were plated to confluence (24-well plates) and differentiated as described above. Measurements of oxygen consumption were made continuously (every 10 s) while cells were sequentially treated with oligomycin (ATP synthase inhibitor), FCCP (an uncoupling agent), and rotenone/myxothiazol (inhibitors of complex I/III of the electron transport chain).

Fatty acid oxidation and esterification in cultured skeletal muscle myotubes were performed in six-well culture plates, as adapted from the method previously described (10).

Whole muscle ex vivo glucose uptake was assessed using 2-deoxyglucose, with minor changes to that described previously (10,15).

Cells were plated on glass coverslips and cultured as described above. Following treatments, cells were washed and fixed in 4% phosphate-buffered formalin then mounted in VectaShield containing DAPI (Vector Laboratories) and sealed before being visualized on a Leica TCS-SP2 AOBS confocal microscope. Colocalization studies were assessed by ImageJ using the JACoP colocalization plugin (16).

Mitochondria were isolated from WT and HSP72-KO primary myotubes and from HEK293A cells using two different methods. Mitochondria were isolated using a Dounce homogenizer and the Mitochondria Isolation Kit for Cultured Cells according to the manufacturer's instructions (Pierce Thermo Scientific) or by sucrose density method (17). Briefly, cells in 10 cm dishes were washed in ice-cold PBS, drained, and then scraped from plates in 8 mL ice-cold isolation buffer. Cells were disrupted with a Dounce homogenizer (10 × 20 s strokes), and cell debris were pelleted at 1,800g for 10 min at 4°C. Mitochondria in the supernatant were then pelleted at 7,000g for 10 min at 4°C and washed twice in isolation buffer before being solubilized in radioimmunoprecipitation assay (RIPA) buffer.

Adenoviral constructs/plasmids containing HSP72 (Hspa1b) were generated as described above. Live virus particles were produced in HEK293A cells using the ViraPower Adenoviral Expression System (Invitrogen). High titer virus was then used in a dose-dependent manner (0, 10, and 50 multiplicity of infection) to determine successful and optimal expression in primary myotubes before performing final experiments.

Lentiviral particles (Mission Transduction Particles; 10130816MN) expressing short hairpin RNAs (shRNAs) against Hspa1b (NM_010478) and a scrambled shRNA were purchased from Sigma-Aldrich. C2C12 cells were seeded at 20,000 cells in a six-well plate and exposed to virus particles for 24 h, after which virus was removed and cells were allowed to grow to ∼80% confluence in normal growth media. Following this, cells were reseeded into a 10 cm dish, allowed to proliferate prior to selection over a 2-week period in sequential doses (1–10 μg/mL) of Puromycin (Enzo LifeSciences). After selection, cells were maintained in normal growth media, and successful knockdown (KD) of HSP72 was determined by both quantitative PCR (qPCR) and immunoblotting following heat shock.

Soluble and insoluble fractions of proteins were isolated as previously described (18).

Dissected tissues were harvested and immediately immersed in 2% glutaraldehyde in PBS for 2 h at room temperature and then at 4°C overnight. Fixed tissues were washed and postfixed in a solution of 1% OsO₄ for 2 h. Tissues were dehydrated, embedded in pure epon 812, and cured (60°C for 48 h). Muscle longitudinal sections of 60 nm thickness were cut using an ultramicrotome (RMC MTX). The sections were double stained in aqueous solutions of 8% uranyl acetate for 25 min at 60°C and lead citrate for 3 min at room temperature. Thin sections were subsequently examined with a 100CX JEOL electron microscope.

C2C12 myocytes were washed and incubated in low-glucose DMEM at 37°C, 5% CO₂ in the dark with 25 μmol/L of Carboxy-H₂DCF-DA (Molecular Probes, Invitrogen), washed with PBS and incubated 15 min with 5 μmol/L of MitoSOX, washed and quickly trypsinized, pelleted, and retained on ice. Cells were resuspended in fluorescence-activated cell sorter buffer (PBS 3% BSA) with DAPI (25 μg/mL) and analyzed immediately by flow cytometry on a LSRII (Becton Dickinson) with FlowJo software (Treestar Inc.). Unstained and single stains were used for establishing compensation and gates, and only live cells (DAPI negative) were analyzed.

Hspa1b or GFP expression plasmids were transferred into contralateral limbs of HSP72-KO and WT mice as previously described (12). Muscles were harvested after 14 days following electroporation.

Mouse tissues and cell cultures for immunoblotting were homogenized in RIPA lysis buffer containing protease and phosphatase inhibitors before being clarified and resolved by SDS-PAGE. Proteins for immunoprecipitations were solubilized in RIPA containing deoxycholate, 1% glycerol, and protease inhibitors by rotation at 4°C for 1 h, then cell debris were pelleted for 10 min at 5,000g. Total protein was measured, and 500 μg of sample was incubated with antibody (Mfn2, V5, HA, Parkin-4211) overnight then immobilized on protein-G agarose beads (Santa Cruz) for 2 h at 4°C prior to washing 3× in RIPA buffer. Proteins were resolved by SDS-PAGE. All samples for Western blotting were transferred to polyvinylidene fluoride membranes and probed with the following antibodies: HSP72 (Stressgen), glyceraldehyde-3-phosphate dehydrogenase (Millipore), p62 (ProGen), phosphatase and tensin homolog–induced putative kinase 1 (PINK1; Cayman Chemicals), DJ-1/Park7 (R&D Systems), Mfn2 (Abcam), porin/voltage-dependent anion channel (MitoSciences), Ubiquitin-FK2 (Enzo Life Sciences), HA-mouse (Covance), V5 (Invitrogen), DNAJB2 (Protein Tech Group), and cABL (BD Pharmingen). The following antibodies were all from Cell Signaling Technologies: p^Ser473-Akt (#9271), Parkin (#2132 & #4211), pan-actin, LC3B, Beclin1, LAMP1, HSP60, HSP90, and HA-rabbit. Densitometric analyses were performed using BioRad Chemidoc Quantity One image software.

Lipids were extracted from the quadriceps muscle (n = 6 per genotype) by the Folch method (19). Triacylglycerol, diacylglycerol, and ceramides were extracted and quantified as previously described (19–21). Lipidomic analyses were performed by the Baker IDI Lipidomics Core on quadriceps samples homogenized in 300 μl PBS buffer, pH 7.47 according to previous methods, with modifications (22).

RNA from tissues and cells was extracted using RNeasy columns as per manufacturer’s instructions (Qiagen). cDNA was synthesized from 1 µg of total RNA using SuperScript II as per manufacturer’s instructions (Invitrogen). qPCR was performed on 20 ng cDNA on a BioRad MyiQ PCR Detection System using SyBR Green chemistry and analyzed using iQ5 Software (BioRad version 2.1) as previously described (10).

Values presented are expressed as means ± SEM. Statistical analyses were performed using Student t tests as well as one- and two-way ANOVA with Tukey’s post hoc comparison for identification of significance within and between groups where appropriate (SPSS graduate pack, Chicago, IL). Significance was set a priori at P < 0.05.

Immunoblotting confirmed HSP72 protein was absent in glucoregulatory tissues harvested from male HSP72-KO mice compared with WT under both basal and heat shock conditions (Fig. 1A). Total body weight and gonadal fat pad mass were increased in HSP72-KO mice compared with WT despite consumption of a normal chow diet and no difference in ambulatory movement (Table 1). Basal glucose, leptin, resistin, and insulin levels were elevated, and adiponectin levels were reduced in plasma from HSP72-KO versus WT mice (Table 1). At ∼24 weeks of age, we performed GTTs and, following intraperitoneal injection of dextrose, the glucose excursion for HSP72-KO mice was elevated compared with WT (Fig. 1B) (area under the curve P = 0.005), indicating impaired glucose tolerance in normal chow–fed HSP72-KO mice. No difference in plasma insulin was detected at 15 min following intraperitoneal dextrose injection (Table 1), a finding consistent with peripheral insulin resistance in the absence of pancreatic insufficiency. Euglycemic-hyperinsulinemic clamp studies were performed on weight-matched mice to quantify the impact of HSP72 deletion on insulin sensitivity. During steady-state clamp conditions, circulating glucose and insulin levels were identical between the genotypes (P = 0.57 and 0.87, respectively). The rate of exogenous glucose infusion required to maintain euglycemia was reduced by 33% (P = 0.007) in HSP72-KO mice compared with WT (Table 1), consistent with peripheral insulin resistance also observed during GTT. The insulin-stimulated glucose disposal, predominantly reflecting skeletal muscle insulin sensitivity, was reduced by 42% (P = 0.01) (Fig. 1C) in normal chow–fed HSP72-KO mice along with mild hepatic insulin resistance (Fig. 1D) compared with WT. In a separate cohort of animals 3 months of age, soleus muscles were stimulated ex vivo with a physiological insulin dose (60 μU/mL), and consistent with glucose clamp studies, insulin-stimulated muscle glucose uptake was reduced by 81% (P = 0.03) in HSP72-KO versus WT (Fig. 1E). Akt^Ser473 phosphorylation paralleled the reduction in glucose uptake seen in KO muscle during insulin stimulation (Fig. 1F). Impaired insulin action could not be explained by a defect in myogenesis, Hsf1, or HSP90 expression, GLUT4 expression or total GLUT4 protein (Supplementary Fig. 1A–E).

Fatty acid oxidation was reduced (Fig. 1G), and fatty acid esterification (Fig. 1H) was elevated in HSP72-KO muscle versus WT, a finding consistent with a 28% reduction in AMPK activity (Fig. 1I) (P = 0.001), a 33% reduction β-hydroxyacyl CoA dehydrogenase activity (P = 0.035) (Supplementary Fig. 2A), and intramuscular accumulation of diacylglycerol and triacylglycerol (Fig. 1J and Supplementary Fig. 3). No difference in citrate synthase activity, expression of cytochrome C oxidase subunits 2 and 3, or protein levels of electron transport chain subunits II–V were detected between the genotypes (Supplementary Fig. 2B–D).

To determine if metabolic dysfunction observed in HSP72-KO mice was due to an intrinsic defect in skeletal muscle or secondary to increased adiposity, primary myoblasts were isolated from WT and HSP72-KO quadriceps muscle from 2-month-old mice. As expected, HSP72 transcript and protein levels were markedly reduced in HSP72-KO primary myotubes under both basal and heat shock conditions (Fig. 2A and B). HSP72-KO cells showed defective insulin-stimulated glucose uptake (Fig. 2C) consistent with reductions in insulin-stimulated Akt^Ser473-phosphorylation compared with WT (Fig. 2D). Similar to findings observed in soleus muscle from HSP72-KO mice, primary HSP72-KO myotubes, also exhibited reduced fatty acid oxidation and increased fatty acid esterification (Fig. 2E and F). Additionally, oxygen consumption (basal and maximal respiration) rates were reduced in primary myotubes from HSP72-KO mice compared with those from WT mice (Fig. 2G).

To validate these findings in an additional culture model, we generated C2C12 myotubes with HSP72-stable KD using lentiviral-mediated shRNA delivery compared with control scrambled shRNA cells (Fig. 2H). Fatty acid oxidation and esterification and cellular oxygen consumption at basal and during maximal stimulation in HSP72-KD C2C12 recapitulated findings for primary HSP72-KO myotubes relative to WT control (Fig. 2I–K). Impaired oxidative function tracked with cellular reactive oxygen species release as basal superoxide and H₂O₂ production were elevated in HSP72-KD myotubes compared with control scrambled (Fig. 2L and M).

To investigate the relationship between HSP72 expression and mitochondrial health, we assessed morphological differences in muscle mitochondria between WT and HSP72-KO animals. Electron micrographs of soleus muscle from 3-month-old animals showed enlarged, dysmorphic, and often fused intermyofibrillar mitochondria (Fig. 3A). Subsarcolemmal mitochondria also showed irregular morphology and reduced density by visual inspection. Since the subsarcolemmal mitochondrial compartment comprises only 20% of the total pool, the difference in mitochondrial number was not detected by a surrogate index of total mitochondrial DNA (mtDNA) (Supplementary Fig. 4). Considering that organelle fusion is a conserved mechanism engaged during chronic cellular stress (e.g., nutrient deprivation) as a means to maintain ATP production, avoid mitophagy, improve tolerance of mtDNA mutations by diluting damaged mitochondrial contents across the mitochondrial network (23), we investigated the underpinnings of this mitochondrial hyperfusion phenotype.

Typically, depolarized mitochondria are eliminated by a targeted autophagic process, mitophagy (24). The committed step in targeting mitochondria for lysosomal degradation occurs via activation of the PINK1/Parkin pathway (24). Parkin, an E3 ubiquitin ligase, translocates from the cytosol to depolarized mitochondria where it ubiquitinates mitochondrial-associated proteins, including Mfn1 and Mfn2, thus preventing fusion by promoting organelle isolation and subsequent autophagolysosome formation (24). Strikingly, we found that Parkin protein levels were dramatically increased in all glucoregulatory tissues from HSP72-KO mice. Importantly, Parkin protein was elevated 12-fold (P = 0.0001) (Fig. 3B) in skeletal muscle of HSP72-KO versus WT as early as 2 months of age prior to the onset of metabolic dysfunction (Supplementary Fig. 5). Under standard basal conditions, Parkin is rapidly turned over in WT cells replete with HSP72 (Supplementary Fig. 6); however, we found a marked accumulation of muscle Parkin in the absence of HSP72 under fed basal conditions. Thus the relative abundance of Parkin in WT or control samples was often difficult to visualize compared with the markedly increased abundance in HSP72-KO muscle and KD cells. In comparison with the dramatic elevation in Parkin protein in muscle, only a modest increase in muscle Park2 transcript was observed (twofold; P = 0.02) (Supplementary Fig. 7), suggesting an important role of HSP72 in Parkin protein turnover. We surmise that Parkin overexpression is not likely a secondary phenotype in response to other in vivo factors, but a direct effect of HSP72 deletion as primary myotubes from HSP72-KO mice, and C2C12 myotubes with HSP72-KD also exhibited markedly elevated Parkin protein levels (Fig. 3C and D). Moreover, the effect of HSP72 appears unique to Parkin, as we observed no change in transcript or protein expression of other Park family members associated with mitophagic signaling (Park6, PINK1 and Park7, DJ-1) (Supplementary Fig. 7A–C).

The majority of Parkin in WT primary myotubes formed complexes at ∼100 kDa and was sensitive to MG132 (a specific proteasomal inhibitor that reduces the degradation of ubiquitin-conjugated proteins), Baf (a specific inhibitor of vacuolar-type H+-ATPase that prevents lysosomal acidification and disturbs the fusion between autophagosomes and lysosomes), and the mitophagy inducer CCCP (an inhibitor of oxidative phosphorylation by destroying the mitochondrial electrochemical gradient) (Fig. 3C). However, Parkin was observed in its native unmodified form (∼50 kDa) in HSP72-KO primary myotubes, and in contrast to WT, Parkin levels were unaffected by MG132, Baf, or CCCP treatment (Fig. 3C).

In addition to altered Parkin protein, downstream autophagic signaling was also impaired in both C2C12 myotubes as well as skeletal muscle. Protein levels of p62 (functionally targets damaged proteins and organelles for autophagy) and LC3BI (18 kDa microtubule-associated protein light chain B1 is recruited and converted to LC3BII by proteolysis and lipidation, which correlates well with autophagosome formation) were elevated (Fig. 3D, lanes 1–3 vs. 7–9; P = 0.045 and 0.01, respectively), while conversion to LC3BII (LC3BII:I) was diminished collectively reflecting reduced basal autophagic signaling in HSP72-KD versus control scrambled cells (Fig. 3D, lanes 1–3 vs. 7–9) and during heat shock (Fig. 3D, lanes 4–6 vs. 10–12) in both the absence and presence of the lysosomal inhibitor bafilomycin. A reduction in Beclin and Lamp1 protein in HSP72-KD versus control scrambled (P = 0.001 and 0.045, respectively) independent of treatment further supports this claim (Fig. 3D).

Although no difference in gene expression of Sqstm1 (p62) and Maplc3b (LC3B) between the genotypes in the fed state was detected (Fig. 3E), p62 and LC3BI protein levels were elevated in HSP72-KO muscle compared with WT (Fig. 3F, lanes 1–3 vs. 4–6). When comparing the conversion of LC3BI to BII between the genotypes, this was also blunted in the HSP72-KO muscle (Fig. 3F, lanes 1–3 vs. 4–6). During starvation, both Sqstm1 (p62) and Map1LC3B (LC3B) transcripts were markedly induced in WT; however, this induction was significantly blunted in HSP72-KO muscle (Fig. 3E). Despite reduced gene expression in muscle from HSP72-KO during starvation, p62 and LC3B-I protein levels were identical between the groups. Moreover, we observed reduced LC3BI to LC3BII conversion in HSP72-KO muscle compared with WT during starvation. Collectively, these data indicate a defect in autophagic signaling reflected by a reduction in the turnover and processing of p62 and LC3B in muscle devoid of HSP72.

To determine whether HSP72 is directly involved in Parkin protein regulation as suggested by findings in Fig. 3, we first used adenoviral re-expression of HSP72 in KO primary myotubes and found that partial restoration of HSP72 was sufficient to reduce Parkin protein levels by 24% (P = 0.03) after only 24 h (Fig. 4A; Supplementary Fig. 8). Similarly, we observed in C2C12 myotubes that heat shock induced a small increase in HSP72 protein in HSP72-KD cells, and this was associated with a 40% reduction (P = 0.03) in Parkin protein (Fig. 3D, right panel, lanes 7–9 vs. 10–12). Next we induced HSP72 expression by DNA electroporation into soleus muscle of HSP72-KO animals. Surprisingly, partial restoration of HSP72 expression in KO muscle was sufficient to reduce Parkin protein by ∼50% versus soleus muscle electroporated with a plasmid to express GFP (Fig. 4B). In addition, we found that restoration of one Hspa1 allele (heterozygous mice; gray bar) or muscle-specific transgenic overexpression of HSP72 in HSP72-KO markedly reduced muscle Parkin protein in 2-month-old mice by nearly 30% and 73%, respectively (Fig. 4C; P = 0.02) (Supplementary Fig. 9; P = 0.001). Collectively, these data suggest that HSP72 is a critical regulator of Parkin protein abundance.

Next we tested whether Parkin inactivation is linked with insulin resistance. Since the muscle phenotype of Parkin^−/− mice is confounded by global Parkin deletion (25), we generated primary myotubes from these animals (Fig. 4D). Similar to HSP72-KO myotubes, maximal respiration was blunted in myotubes with Parkin inactivation (Fig. 4E), a finding consistent with observations in Parkin mutant Drosophila (26). Moreover, we found that basal glucose uptake was elevated; however, insulin-induced glucose uptake (Fig. 4F) and insulin signal transduction (Fig. 4G) were markedly reduced in Parkin-KO myotubes compared with WT. These findings strongly suggest that HSP72 is required for the regulation of Parkin protein levels and that Parkin functionality is directly linked with insulin action in muscle.

The aggregation of Parkin into nonfunctional clusters is thought to underlie Parkinson disease pathobiology (27). Thus we examined whether the inactivation and accumulation of Parkin in HSP72-KO muscle was due to Parkin aggregation and insolubility. We found that Parkin exists in the soluble fraction, suggesting that it does not form aggregates within muscle cells (Fig. 5A) and therefore is not likely to underlie the Parkin inactivation observed in this model.

Next we examined the cellular localization of Parkin using confocal microscopy. In the basal setting, Parkin was observed predominantly in the cytoplasm of myoblasts obtained from both WT and HSP72-KO mice (Fig. 5B). However, significantly more Parkin was observed in HSP72-KO than WT cells, a finding consistent with immunoblot analyses. Importantly, translocation of Parkin to depolarized mitochondria (CCCP treated) was impaired in HSP72-KO muscle cells (Fig. 5B). Specifically, in WT cells, CCCP induced mitochondrial depolarization and movement of Parkin from the cytosol to mitochondria (punctate staining); however, Parkin translocation was significantly blunted in HSP72-KO muscle cells (Fig. 5B). Furthermore, isolated mitochondria from WT myotubes contained more Parkin compared with HSP72-KO myotubes that showed no appreciable increase in Parkin following CCCP treatment (Fig. 5C). Moreover, Mfn2, typically ubiquitinated and targeted for proteasomal degradation by Parkin, was elevated in HSP72-KO myotubes compared with WT cells, a finding likely explained by reduced Parkin-mediated Mfn2 degradation (Fig. 5C).

Autoubiquitination can be used as a surrogate marker of Parkin activation. Immunoprecipitation studies showed that Parkin is ubiquitinated both basally and after CCCP treatment; however, the level of ubiquitination was significantly reduced in HSP72-KO compared with WT myotubes (Fig. 5D, right panel, lanes 5–6 vs. 7–8). Furthermore, basal Mfn2 protein levels in total lysates were markedly higher in HSP72-KO cells compared with control (Fig. 5D, left panel, lanes 1–2 vs. 3–4), a finding consistent with the mitochondrial hyperfusion phenotype. Considering this increase, the relative association and diminished subsequent turnover of Mfn2 in HSP72-KO compared with WT following CCCP treatment (Fig. 5D, right panel, lanes 5–6 vs. 7–8) supports our hypothesis of impaired Parkin activity in the context of HSP72 deficiency. Importantly, these data demonstrate for the first time in muscle cells that HSP72 complexes with Parkin and Mfn2 to orchestrate mitochondrial triage signaling.

To confirm the interaction between HSP72 and Parkin in a second cell type, we next performed similar immunoprecipitation studies in WT HEK293A cells. As predicted, after CCCP-induced mitochondrial depolarization, we observed increased interaction between Parkin, Mfn2, and HSP72. In contrast, this interaction of proteins was not observed in WT cells in an alternative cellular stress condition, starvation (Fig. 5E), when mitochondrial fusion is engaged to prevent the autophagic degradation of healthy organelles (28). These data suggest that HSP72 interaction with Parkin is only promoted in response to specific mitochondrial insult, e.g., alteration in membrane potential. Moreover, the interaction of Parkin with HSP72 and Mfn2 appeared to be tightly linked with the ubiquitination status of Parkin and Mfn2 (Fig. 5E), as CCCP-induced polyubiquitination of Parkin, whereas only Parkin monoubiquitination was detected during starvation (Fig. 5E).

Since an increased interaction between HSP72 and Parkin suggested possible comigration of these proteins to the same cellular compartment under specific organelle stress, e.g., CCCP-induced mitochondrial membrane depolarization, we next investigated the mitochondrial-specific targeting of these proteins by overexpressing fluorescently tagged HSP72 (GFP) and Parkin (YFP) in Neuro2a cells (N2a; an easily transfectable cell line expressing little to no endogenous HSP72 or Parkin and frequently used to assess autophagy by confocal microscopy). As shown previously, Parkin resides in the cytoplasm under basal conditions (DMSO) and translocates to mitochondria (RFP-labeled) after treatment with CCCP (4 h) (Fig. 5F). Under basal conditions, HSP72 also resides in the cytoplasm, and for the first time, we show in two separate cell systems (myotubes and N2a cells) that HSP72 translocates to mitochondria following treatment with CCCP (Fig. 5G). Furthermore, using a reciprocal immunoprecipitation approach in HEK293A cells, we confirm the interaction of HSP72 with Mfn2 and Parkin (Mfn2 immunoprecipitation and Parkin immunoprecipitation; Fig. 5H and I, respectively). Moreover, as shown previously (24), proteasomal inhibition using MG132 partially dampened CCCP-induced degradation of Mfn2 and Parkin; however, under basal conditions, Mfn2 and Parkin accumulated only during inhibition of lysosomal degradation in the presence of bafilomycin. These data reflect differential regulation of protein turnover based upon cellular status and protein localization (Fig. 5H and I). In contrast to Parkin and Mfn2, HSP72 is not degraded after CCCP treatment in HEK293A cells (Fig. 5H, right panel).

Finally, although others have suggested that DnaJB2/HSP40 and cABL interact with Parkin to control its folding and turnover in neuronal cells (14,29), no protein association was detected in muscle or HEK293A cells under basal conditions or following treatment with the cABL inhibitor imatinib (Fig. 5H, I, and E, respectively). Collectively, these data suggest that HSP72 is a cellular stress sensor that translocates to the site of mitochondrial damage where it interacts with both Parkin and Mfn2 to likely facilitate degradation of mitochondrial components via selective autophagy. We provide strong evidence for the conservation of this regulatory mechanism in three cell types: skeletal muscle, HEK293A cells, and N2a cells. Nevertheless, questions still remain regarding the timing and specific stress conditions in which these interactions occur and whether HSP72 mitochondrial translocation is an initiating step in this process.

Since the majority of studies presented above were performed over a 4-h period, the temporal order in which HSP72 and Parkin translocate to depolarized mitochondria in response to CCCP treatment was unknown. Thus confocal analyses were performed using the easily transfectable N2a cell system overexpressing fluorescently tagged HSP72 and Parkin. Surprisingly, HSP72 rapidly translocated to mitochondria beginning as early as 15 min following CCCP treatment (Fig. 6A). The entire cytosolic pool was observed at the mitochondrial membrane within 30 min and sustained presence of HSP72 was seen for up to 4 h (Fig. 6A, top panels). In contrast, Parkin remained in the cytoplasm up to 60 min after CCCP treatment, but by 4 h, the majority of cellular Parkin was observed in the same location as HSP72 (Fig. 6A, bottom panels). These observations were also supported by immunoblotting in a similar study conducted in isolated mitochondria from HEK293A, showing reduced cytoplasmic and increased mitochondrial-associated HSP72 at 30 min, whereas mitochondrial Parkin protein and subsequent degradation on Mfn2 was not observed until 1 h following CCCP treatment (Fig. 6B). These findings suggest that HSP72 translocates to depolarized mitochondria prior to the movement of molecular machinery necessary for the removal of mitochondria via selective autophagy, i.e., mitophagy. Thus it is reasonable to speculate that HSP72 may be sensitive to perturbations in mitochondrial membrane potential and be involved in facilitating early steps of mitophagic signaling.

To determine the specificity of the HSP72 response to mitochondrial stress, we used confocal microscopy to determine whether HSP72 translocation to mitochondria also occurred following rotenone (electron transport chain complex I inhibitor) and antimycin (cytochrome C reductase inhibitor) treatments. Neither compound induced the translocation of HSP72 or Parkin at 30 min; however, after 4 h, rotenone, but not antimycin, induced HSP72 movement to mitochondria (Fig. 6D). Considering that neither compound is known to induce mitophagy, as expected, Parkin remained dispersed in the cytoplasm (30) (Fig. 6C and D). Congruent with confocal analyses, immunoprecipitation studies showed no increase in HSP72–Parkin association with Mfn2, and no degradation of the Parkin target Mfn2 following rotenone or antimycin treatment (Fig. 6E, lanes 6–11).

To demonstrate that HSP72 is required for Parkin action, we performed studies in N2a cells that lack detectable endogenous HSP72 and Parkin protein (Fig. 6F). Similar to previous findings, we show that HSP72 is critical for basal regulation of Parkin and Mfn2 protein levels (Fig. 6F, lanes 5–6 vs. 9–10). Using YFP-labeled Parkin, we demonstrated that CCCP failed to induce mitophagy in N2a cells in the absence of HSP72 and Parkin, as evidenced by a lack of reduction in porin or HSP60 levels after mitochondrial depolarization (Fig. 6F, left panel, lanes 1–2 vs. 3–4). However, when Parkin and HSP72 were introduced into this cell type, porin and HSP60 were diminished both at basal (Fig. 6F, lanes 1–2 and 5–6 vs. 9–10) and after CCCP treatment compared with GFP control (Fig. 6F, lanes 1–4 vs. 9–12), an observation consistent with enhanced mitochondrial turnover. Collectively, we found that a reduction in HSP72 promotes an increase and an inactivation of Parkin protein that is associated with alterations in mitochondrial quality and insulin resistance (Fig. 7).

The heat shock response is one of the most highly conserved processes from fly to man, and impairments in this protective mechanism are associated with increased cellular death (31–33) and reduced life span (2,3,34). The heat shock response is engaged during cellular stress to protect against proteotoxicity (35,36), and we have previously shown that HSP72, the stress-inducible protein chaperone, is reduced in skeletal muscle from obese and type 2 diabetic subjects (5,6). Conversely, we and others have also shown that upregulation of HSP72 by genetic, thermal stress, or pharmacologic means protects rodents from metabolic dysfunction induced by genetic or diet-induced obesity (6,37,38). Although clinical and experimental evidence suggests a strong relationship between HSP72 expression and glucose homeostasis, it was unknown whether reductions in HSP72 were causal of early metabolic dysfunction and insulin resistance. Furthermore, the critical targets of HSP72 that confer cellular protection remained incompletely understood.

Herein we provide compelling evidence to show that mice harboring a homozygous null mutation for Hspa1a and Hspa1b develop impaired glucose homeostasis, insulin resistance, and increased adiposity with age. Muscles from these mice accumulate bioactive lipids likely resulting from reduced fatty acid oxidation, and we postulate that this, in part, drives tissue inflammation. In addition, muscle cells lacking HSP72 have reduced oxygen consumption rates at basal and during maximal stimulation and increased mitochondrial reactive oxygen species production, an additional underpinning promoting cellular inflammation. Electron micrographs show a pronounced mitochondrial phenotype in HSP72-KO muscle that is characterized by enlarged, dysmorphic, and fused organelles with reduced density in the subsarcolemmal compartment. Healthy mitochondria typically elongate and fuse together during nutrient deprivation to avoid elimination by macroautophagy, although evidence also indicates tabulation and hyperfusion of mitochondria as a chronic compensatory adaptation to prolonged cellular stress (28,39,40), including loss of function in the PINK1/Parkin signaling pathway (41). Additionally, depolarized mitochondria can also fuse with healthy organelles when selective autophagy is impaired, and this mechanism serves a protective response to dilute damaged contents and maintain cellular energetics by functional complementation, a process thought to counteract cellular aging (42–44). Thus the chronic fusion phenotype we observe is likely a compensatory mechanism to help maintain cellular energetics, enhance DNA mutation tolerance with age, and prevent cellular apoptosis.

Recent work suggests that preservation of mitochondrial network health is achieved by the maintenance of paired fission–fusion events that accelerate the removal of damaged mitochondrial components by autophagy. This process, however, requires selectivity of fusion, especially under conditions of elevated mtDNA damage (45). The mitochondrial theory of aging portends that excessive production of reactive oxygen species induce mutations in mtDNA, and this precipitates reduced mitochondrial function, loss of bioenergetic capacity, and eventually disease pathology (46–51). This theory is consistent with impaired removal of dysfunctional mitochondria, and indeed skeletal muscle imbalances in fusion–fission dynamics have been associated with insulin resistance and metabolic dysfunction (52). Since no alteration in total mtDNA was detected, reduced oxygen consumption and elevated reactive oxygen species production in cells lacking HSP72 is consistent with retention of dysfunctional organelles, likely mediated by indiscriminate fusion and impaired mitophagy.

Thus the striking mitochondrial phenotype observed in HSP72-KO mice prompted us to investigate the integrity of mitophagic signaling, and considering previous reports suggesting HSPs as Parkin binding partners (53), we hypothesized that the retention of aged, damaged mitochondria could be due, in part, to impaired Parkin signaling. Interestingly, we found that HSP72 translocates to depolarized mitochondria within 15 min following CCCP treatment, even prior to the movement of Parkin. In the absence of HSP72, Parkin translocation to depolarized mitochondria was significantly diminished, and Mfn2, HSP60, and porin levels were maintained compared with control cells, findings consistent with the cellular retention of damaged mitochondria. Importantly, ectopic expression of HSP72 in N2a cells promoted CCCP-induced movement of Parkin to depolarized mitochondria concomitant with a reduction in the abundance of the Parkin target Mfn and mitochondrial markers porin and HSP60. These data suggest that HSP72 is a pivotal regulator of the Parkin–Mfn axis essential for mitochondrial quality control, although alternative E3 ligases and scaffolding proteins could also be engaged in the absence of Parkin in a cell type- and stress-specific manner.

It is important to note that the observed phenotype of the HSP72-KO mice phenocopies Drosophila lacking Parkin (7). Mitochondria from flight muscles of Parkin^−/− flies appeared dysmorphic and were dysfunctional with impaired oxidative phosphorylation capacity and increased reactive oxygen species production. Similar to our findings in HSP72-KO mice, the mitochondrial defects in Parkin^−/− flies preceded the muscle degeneration and both could be ameliorated by reducing oxidative stress. Although mice with homozygous null mutation of Park2 (Parkin) show a less robust degeneration phenotype compared with Drosophila (54,55), Parkin^−/− mice were more susceptible to environmental and inflammation-induced neural degeneration than WT littermates (56). Herein, we show for the first time that Parkin inactivation induces insulin resistance in primary myotubes, a finding with clinical implications linking impaired mitophagy with a central defining feature of the metabolic syndrome and type 2 diabetes.

Clearly maintenance of elemental processes, including preservation of protein and organelle quality, is critical for cellular health. Whether impaired macroautophagy and microautophagy are causal or consequence of insulin resistance remains unclear. Based upon our collective work, we provide strong evidence supporting a critical role for HSP72 in cellular stress sensing and Parkin action. Importantly, similar to our previous observations in human subjects (5,6), reduced HSP72 levels are associated with increased adiposity and impaired insulin action, whereas upregulation of HSP72 by chronic exercise, genetic overexpression, or pharmacological stimulation is protective against obesity and insulin resistance. Thus our work provides the important preclinical foundation to suggest that targeted therapies aimed at increasing muscle HSP72 may provide health benefit by ameliorating cellular oxidative damage, tissue inflammation, and insulin resistance, all underlying features of the metabolic syndrome and type 2 diabetes.
