Gastric bypass (GBP) surgery, one of the most common bariatric procedures, induces weight loss and metabolic effects. The mechanisms are not fully understood, but reduced food intake and effects on gastrointestinal hormones are thought to contribute. We recently observed that GBP patients have lowered glucose levels and frequent asymptomatic hypoglycemic episodes. Here, we subjected patients before and after undergoing GBP surgery to hypoglycemia and examined symptoms and hormonal and autonomic nerve responses. Twelve obese patients without diabetes (8 women, mean age 43.1 years [SD 10.8] and BMI 40.6 kg/m2 [SD 3.1]) were examined before and 23 weeks (range 19–25) after GBP surgery with hyperinsulinemic-hypoglycemic clamp (stepwise to plasma glucose 2.7 mmol/L). The mean change in Edinburgh Hypoglycemia Score during clamp was attenuated from 10.7 (6.4) before surgery to 5.2 (4.9) after surgery. There were also marked postsurgery reductions in levels of glucagon, cortisol, and catecholamine and the sympathetic nerve responses to hypoglycemia. In addition, growth hormone displayed a delayed response but to a higher peak level. Levels of glucagon-like peptide 1 and gastric inhibitory polypeptide rose during hypoglycemia but rose less postsurgery compared with presurgery. Thus, GBP surgery causes a resetting of glucose homeostasis, which reduces symptoms and neurohormonal responses to hypoglycemia. Further studies should address the underlying mechanisms as well as their impact on the overall metabolic effects of GBP surgery.

Gastric bypass (GBP) surgery for the treatment of morbid obesity induces marked weight loss and metabolic effects. Excess BMI loss is typically ∼70–80% (1), and almost instant changes occur in glucose homeostasis postsurgery, including frequent remission of diabetes up to 70% (1). After a meal, the rise in glucose and insulin is ∼50% higher, reflecting the faster absorption of glucose postsurgery. Incretins are also affected; prandial gastric inhibitory polypeptide (GIP) and glucagon-like peptide 1 (GLP-1) peak at ∼2 and 10 times higher levels after surgery, respectively (2).

The sustained weight loss achieved by GBP surgery, superior to that achieved by diet regimens, reflects lowered caloric intake and possibly altered secretion of gastrointestinal peptides (2). Comparing eating habits before and after the GBP surgery, patients lowered the intake with marked reductions in carbohydrate intake in the form of sweets, soda, and milk/ice cream. Fear of dumping was suggested as the main mechanism (3). Dumping can occur within 10–30 min of food intake when, in the absence of a pyloric function, it quickly enters the intestine and produces an osmotic effect. Fluid is shifted from the circulation into the intestine, resulting in a fall of blood pressure and tachycardia. In a rat model, similar food preference adaptations evolved with time, indicating that the preference shift was dependent on learning and dumping (4).

In a recent study with continuous glucose monitoring (5), we observed hypoglycemic episodes (glucose <3.3 mmol/L [60 mg/dL]) in 50% of patients who had undergone GBP surgery, of whom none had experienced symptoms of hypoglycemia. On average, the patients spent 40 min per 24-h period in a hypoglycemic glucose range, mostly (80%) without any symptoms. Goldfine et al. (6) observed a high frequency of asymptomatic hypoglycemia after a mixed-meal test in patients after GBP surgery, and another study (7) reported asymptomatic hyperinsulinemic hypoglycemia in a small number of patients who have undergone gastric banding. Furthermore, in a well-documented study of eight subjects with massive weight loss after vertical banded gastroplasty, Guldstrand et al. (8) have demonstrated a reduction in the hypoglycemic response of classic counterregulatory hormones.

The brain relies on glucose as the sole source of energy unless ketone bodies are provided, typically upon starvation. Gluco-sensing neurons are placed in the brain (e.g., in the hypothalamus) and in peripheral tissues, such as the carotid body, oral cavity, gut, and the hepatic portal vein, conveying signals to the brain (9). Upon perceived hypoglycemia, the brain acts on the anterior pituitary, pancreas, and adrenal medulla to increase the levels of counterregulatory hormones such as growth hormone (GH), glucagon, cortisol, epinephrine, and norepinephrine (9,10). In addition, endocrine cells in the pancreatic islets can respond directly to surrounding glucose levels. Autonomic nerve activation contributes to hormonal responses and also directly influences glucose turnover in liver, muscle, and adipose tissue (11). Furthermore, the secretion of the incretins GLP-1 and GIP may be involved, regulated by vagal signaling and the enteric nervous system (12). These systems provide a highly conserved and powerful integrated defense against severe hypoglycemia.

In view of previous findings by our group and others, we hypothesized that the counterregulatory response to hypoglycemia would be attenuated postsurgery. In the current study, we examined symptoms and counterregulatory responses during hyperinsulinemic-hypoglycemic clamps in patients before and after GBP surgery. Further, we analyzed GLP-1 and GIP in view of the upregulation of their prandial levels after undergoing GBP surgery (13), as well as their reported role in enhancing the glucagon response to hypoglycemia (14).

Patients

Morbidly obese (BMI >35 kg/m2) patients without diabetes were recruited at the Metabolic Outpatient Clinic of the Uppsala University Hospital. Patients accepted for bariatric surgery were consecutively invited to participate in the study. Fifteen patients were enrolled in the study, but three patients discontinued their participation after the first clamp, one due to pregnancy and two due to lack of time. The per-protocol cohort thus consisted of eight women and four men who were examined 3 months (16) before and 4–5 months after surgery using a hyperinsulinemic-hypoglycemic clamp. All patients underwent laparoscopic Roux-en-Y GBP surgery, including a 100-cm Roux limb connected to a small proximal gastric pouch and a 50-cm biliopancreatic limb. The GBP surgery was preceded by 4 weeks of eating a low-calorie diet, according to clinical routine, to reduce liver size and intestinal fat. Baseline characteristics are shown in Table 1.

Table 1

Anthropometric measures and clinical biochemistry at start of clamp, presurgery and postsurgery

PresurgeryPostsurgery
Age (years) 43.1 (10.8)
Height (m) 1.69 (0.09)
Weight (kg)A 116.5 (15.7) 86.4 (16.2)***
BMI (kg/m240.6 (3.1) 30.1 (4.3)***
Body fat (%)B 43.3 (7.4) 36.0 (7.4)***
Body surface (m22.25 (0.2) 1.96 (0.2)***
Systolic BP initial (mmHg) 126 (12) 121 (12)*
Diastolic BP initial (mmHg) 81 (9) 75 (5)
Heart rate (bpm) 65 (8) 56 (10)***
Hemoglobin (g/L) 140.5 (10.7) 133.6 (10.1)*
Plasma creatinine (μmol/L) 75.8 (12.7) 66.7 (9.8)***
eGFR (mL/min/1.73 m282.2 (5.3) 88.1 (3.2)**
Plasma albumin (g/L) 35.2 (2.7) 34.7 (3.2)
HOMA-IR 6.32 (2.2) 1.96 (1.0)***
Fasting plasma glucose (mmol/L) 5.9 (0.5) 5.4 (0.4)***
HbA1c [% (mmol/mol)] 5.5 (1.5) (37.4 [4.6]) 5.2 (1.3) (32.8 [3.1])***
Serum insulin (mU/L) 22.3 (10.1) 8.1 (4.1)***
Serum C-peptide (nmol/L) 1.4 (0.3) 0.9 (0.2)***
Plasma cholesterol (mmol/L) 4.7 (1.0)* 3.8 (0.8)***
Plasma HDL cholesterol (mmol/L) 1.0 (0.3) 1.0 (0.3)
Plasma LDL cholesterol (mmol/L) 3.1 (0.8)* 2.3 (0.7)***
Plasma triglycerides (mmol/L) 1.7 (0.7)* 1.1 (0.3)**
Glucagon (pmol/L) 13.4 (6.9) 8.6 (5.4)**
Cortisol (nmol/L) 233 (99.8) 199 (49.0)
GH (μg/L) 0.18 (0.3) 1.3 (3.1)
Epinephrine (nmol/L) 0.3 (0.001) 0.3 (0.06)
Norepinephrine (nmol/L) 1.4 (0.7) 1.1 (0.3)
GLP-1 (pmol/L) 33.5 (36.5) 18.7 (13.4)
GIP (pg/mL) 55.9 (27.4) 40.0 (12.0)*
FFAs (μmol/L) 203 (55.8) 219 (64.8)
Glycerol (μmol/L) 60.0 (17.1) 61.6 (27.1)
PresurgeryPostsurgery
Age (years) 43.1 (10.8)
Height (m) 1.69 (0.09)
Weight (kg)A 116.5 (15.7) 86.4 (16.2)***
BMI (kg/m240.6 (3.1) 30.1 (4.3)***
Body fat (%)B 43.3 (7.4) 36.0 (7.4)***
Body surface (m22.25 (0.2) 1.96 (0.2)***
Systolic BP initial (mmHg) 126 (12) 121 (12)*
Diastolic BP initial (mmHg) 81 (9) 75 (5)
Heart rate (bpm) 65 (8) 56 (10)***
Hemoglobin (g/L) 140.5 (10.7) 133.6 (10.1)*
Plasma creatinine (μmol/L) 75.8 (12.7) 66.7 (9.8)***
eGFR (mL/min/1.73 m282.2 (5.3) 88.1 (3.2)**
Plasma albumin (g/L) 35.2 (2.7) 34.7 (3.2)
HOMA-IR 6.32 (2.2) 1.96 (1.0)***
Fasting plasma glucose (mmol/L) 5.9 (0.5) 5.4 (0.4)***
HbA1c [% (mmol/mol)] 5.5 (1.5) (37.4 [4.6]) 5.2 (1.3) (32.8 [3.1])***
Serum insulin (mU/L) 22.3 (10.1) 8.1 (4.1)***
Serum C-peptide (nmol/L) 1.4 (0.3) 0.9 (0.2)***
Plasma cholesterol (mmol/L) 4.7 (1.0)* 3.8 (0.8)***
Plasma HDL cholesterol (mmol/L) 1.0 (0.3) 1.0 (0.3)
Plasma LDL cholesterol (mmol/L) 3.1 (0.8)* 2.3 (0.7)***
Plasma triglycerides (mmol/L) 1.7 (0.7)* 1.1 (0.3)**
Glucagon (pmol/L) 13.4 (6.9) 8.6 (5.4)**
Cortisol (nmol/L) 233 (99.8) 199 (49.0)
GH (μg/L) 0.18 (0.3) 1.3 (3.1)
Epinephrine (nmol/L) 0.3 (0.001) 0.3 (0.06)
Norepinephrine (nmol/L) 1.4 (0.7) 1.1 (0.3)
GLP-1 (pmol/L) 33.5 (36.5) 18.7 (13.4)
GIP (pg/mL) 55.9 (27.4) 40.0 (12.0)*
FFAs (μmol/L) 203 (55.8) 219 (64.8)
Glycerol (μmol/L) 60.0 (17.1) 61.6 (27.1)

Values are reported as the mean (SD). BP, blood pressure; eGFR, estimated glomerular filtration rate; IR, insulin resistance.

AWeight on the day of surgery (112 kg) was not significantly changed compared with presurgery weight at clamp investigation.

BMeasured with bioimpedance.

*P < 0.05; **P < 0.01; ***P < 0.001.

Hypoglycemic Clamp

A hyperinsulinemic-hypoglycemic clamp was performed after an overnight fast (water intake allowed). The clamp was modified according to the study by Norjavaara et al. (15). After a priming infusion, insulin was infused at a fixed rate, 80 mU/m2 body surface/min together with a variable glucose (200 mg/mL) infusion to maintain plasma glucose at levels of 5 mmol/L (90 mg/dL) for 0–60 min, 4 mmol/L (72 mg/dL) for 60–90 min, 3.2 mmol/L (58 mg/dL) for 90–135 min, and 2.7 mmol/L (49 mg/dL) for 135–165 min.

At 165 min, the insulin infusion was stopped, with glucose infusion continued until a glucose level of >4.0 mmol/L (72 mg/dL) was achieved. Plasma glucose in arterialized venous blood was measured every 5 min during the clamp with the Contour Glucose Meter (Bayer Healthcare, Leverkusen, Germany). Levels of insulin, C-peptide, GH, glucagon, cortisol, epinephrine, norepinephrine, GLP-1, and GIP were measured at 0, 60, 90, 120, 135, 150, and 165 min during clamp, and free fatty acids (FFAs) and glycerol were measured at 0, 135, and 165 min. Participants were continuously monitored with electrocardiogram, and recordings were used for heart rate variability (HRV) assessment.

Symptom Score

The Edinburgh Hypoglycemia Score, composed of the 11 symptoms statistically derived to most closely associate with hypoglycemia, was used (16). The 11 hypoglycemic symptoms contain four autonomic symptoms (sweating, palpitation, shaking, and hunger), five neuroglycopenic symptoms (confusion, drowsiness, odd behavior, speech difficulty, and incoordination), and two malaise symptoms (nausea and headache). The participants graded their symptoms between 1 (no symptoms) and 7 (maximum symptoms) at 0, 60, 90, 120, 135, 150, and 165 min, and scores for all 11 symptoms were added.

Biochemical Measurements

Blood samples were taken at 8:00 a.m. after 10 h of fasting. Routine blood chemistry and most hormonal analyses were performed at the Department of Clinical Chemistry at the University Hospital, Uppsala, Sweden. If not analyzed immediately, samples were frozen at −80°C. The following analyses were used: insulin (Cobas e; Roche), cortisol (Cobas e; Roche), GH (Immulite XP; Siemens Healthcare Global), and C-peptide (Cobas e; Roche). Catecholamine analyses (liquid chromatography) were performed at the Laboratory of Clinical Chemistry at the Karolinska Universitetssjukhuset, Stockholm, Sweden).

Specific analyses were performed at the Clinical Diabetes Research Laboratory: glucagon was measured with ELISA (Glucagon #10–1271–01; Mercodia, Uppsala, Sweden). Total GLP-1 and total GIP were measured with ELISA (Merck Millipore, Darmstadt, Germany), FFAs were measured with the Free Fatty Acid Fluorometric Assay Kit (Cayman Chemical, Ann Arbor, MI), and glycerol was measured with Free Glycerol reagent (Sigma-Aldrich, St. Louis, MO). HOMA of insulin resistance was calculated as follows: (fasting insulin [in mU/L] × glucose [in mmol/L])/22.5.

HRV Analyses

As a marker of efferent activity in the autonomic nervous system, HRV analyses were performed as described previously (17,18). Six of the 12 subjects had complete recordings both presurgery and postsurgery that were used for the statistical analysis. In the other subjects, at least one recording was incomplete because of technical issues. The total spectral power (PTOT), the power of the low-frequency component (PLF) (0.04–0.15 Hz), and the power of the high-frequency component (PHF) (0.15–0.50 Hz), all log transformed, were calculated over consecutive 5-min periods from the complete recording. PHF mainly reflects the parasympathetic activity, whereas PLF reflects a combination of sympathetic and parasympathetic activity, and the PLF/PHF ratio is used as a marker of the balance between sympathetic and parasympathetic activity (18). The HRV analysis was performed using Matlab Software (MathWorks, Natick, MA).

Statistical Analyses

Statistical calculations were performed in Statistica (Dell Statistica; StatSoft, Aliso Viejo, CA) except for the analysis of HRV indices, which were performed using R (version 3.1, 2014, Vienna, Austria). Shapiro-Wilks tests were performed to assess normal distributions, in addition to visual graph inspection. Anthropometric and fasting laboratory results presurgery and postsurgery were compared using Student t tests. Metabolite and hormone levels during hypoglycemic clamp were analyzed with repeated-measures ANOVA. Areas under the curve during the hypoglycemic period (AUChypo) (90–165 min) were analyzed by paired t tests. Symptom scores were compared using paired t tests.

For HRV analysis, the time-variant changes in HRV during the complete recording were modeled using generalized additive mixed-effects models using thin plate splines (19). Differences between presurgery and postsurgery recordings were modeled as a binominal categorical variable. Changes during the euglycemic phase (0–60 min) and hypoglycemic phase (90–165 min) were evaluated by ANOVA for repeated measurements.

Ethics

The Regional Ethics Committee of Uppsala, Sweden, approved this study (Dnr 2013/480). Patients gave written informed consent, and the study was conducted according to the tenets of the Declaration of Helsinki.

Clinical Effects

GBP surgery induced marked metabolic effects, notably lower glucose, insulin, and HbA1c levels (Table 1).

Hypoglycemic Clamp

The glucose, insulin, and C-peptide levels during the clamp investigations are depicted in Fig. 1. The mean (SD) glucose levels achieved during the clamp investigations, presurgery versus postsurgery, were as follows: for the 5.0 mmol/L target period 5.0 (0.4) mmol/L vs. 5.0 (0.4) mmol/L; for the 4.0 mmol/L target period 4.3 (0.3) mmol/L vs. 4.1 (0.3) mmol/L; for the 3.2 mmol/L time period 3.2 (0.3) mmol/L vs. 3.0 (0.2) mmol/L; and for the 2.7 mmol/L target period: 2.9 (0.3) mmol/L vs. 2.8 (0.2) mmol/L (all differences were nonsignificant). The circulating levels of insulin during insulin infusion increased to ∼200 mU/L before surgery and 150 mU/L after surgery, suggesting an increase in insulin clearance after bariatric surgery, which is in line with what has been previously reported (8,20). The glucose infusion rate was significantly higher during the postsurgery clamp, indicating improvement in insulin sensitivity.

Figure 1

Values are reported as the mean (SD). A: Glucose levels during the different plateaus of the clamp, presurgery and postsurgery. B: Insulin levels during the different plateaus of the clamp, presurgery and postsurgery. C: C-peptide levels during the different plateaus of the clamp, presurgery and postsurgery. D: Glucose infusion rate (GIR) per lean body mass (LBM) during clamp, presurgery and postsurgery. All time points differ significantly. Note the marked increased demand for glucose during hypoglycemia during the postsurgery examination. Pre, presurgery; Post, postsurgery.

Figure 1

Values are reported as the mean (SD). A: Glucose levels during the different plateaus of the clamp, presurgery and postsurgery. B: Insulin levels during the different plateaus of the clamp, presurgery and postsurgery. C: C-peptide levels during the different plateaus of the clamp, presurgery and postsurgery. D: Glucose infusion rate (GIR) per lean body mass (LBM) during clamp, presurgery and postsurgery. All time points differ significantly. Note the marked increased demand for glucose during hypoglycemia during the postsurgery examination. Pre, presurgery; Post, postsurgery.

Patients experienced fewer symptoms during hypoglycemia in the postsurgical clamp. The total mean composite Edinburgh Hypoglycemia Score at the end of hypoglycemia (165 min) was 24.0 (SD 6.9) before surgery and 18.5 (5.2) after surgery. The hypoglycemia-induced increase in total symptom score was halved after surgery (Table 2).

Table 2

Parameters during hypoglycemic clamp examination

PresurgeryPostsurgery
ΔSymptom score 10.7 (6.4) 5.2 (4.9)*
Systolic BP peak (mmHg) 132 (13) 125 (12)*
ΔSystolic BP (mmHg) 6 (9) 4 (6)
Diastolic BP peak (mmHg) 82 (9) 78 (5)
ΔDiastolic BP (mmHg) 1 (6) 3 (6)
Peak HR (bpm) 75 (9) 69 (10)***
ΔHR (bpm) 10 (9) 13 (5)
M-value (mg/kg LBM/min) 2.36 (1.22) 4.19 (1.36)**
PresurgeryPostsurgery
ΔSymptom score 10.7 (6.4) 5.2 (4.9)*
Systolic BP peak (mmHg) 132 (13) 125 (12)*
ΔSystolic BP (mmHg) 6 (9) 4 (6)
Diastolic BP peak (mmHg) 82 (9) 78 (5)
ΔDiastolic BP (mmHg) 1 (6) 3 (6)
Peak HR (bpm) 75 (9) 69 (10)***
ΔHR (bpm) 10 (9) 13 (5)
M-value (mg/kg LBM/min) 2.36 (1.22) 4.19 (1.36)**

Values are reported as the mean (SD). Δ, rise from beginning to peak during clamp; BP, blood pressure; HR, heart rate; LBM, lean body mass; M-value, mean value during euglycemia; Symptom score, Edinburgh Hypoglycemia Score.

*P < 0.05; **P < 0.01; ***P < 0.001.

Heart rate increased during both clamps, from 65 to 75 bpm presurgery and from 56 to 69 bpm postsurgery, respectively. The mean time to peak heart rate was longer postsurgery; peaks appeared at 130 min presurgery and at 150 min postsurgery. There were no presurgery versus postsurgery difference in hypoglycemia-induced increase in systolic or diastolic blood pressure or heart rate (Table 2).

Counterregulatory Hormones

Counterregulatory hormone levels are shown in Fig. 2 and Table 3. The hypoglycemia-induced glucagon response was markedly decreased postsurgery. During presurgery examination, the glucagon rise started at 120 min and during the postsurgery examination at 135 min. Cortisol levels were similar during the euglycemic phase of both clamps, and hypoglycemia responses became significant at 135 min both presurgery and postsurgery but were lower postsurgery than presurgery (Table 3). Epinephrine and norepinephrine levels rose at 120 min during the clamp presurgery and later (at 135 min) postsurgery. The epinephrine and norepinephrine responses during hypoglycemia were lower postsurgery. Levels of GH were similar up to 120 min and then increased during the presurgery clamp. Postsurgery, the GH levels responded later, at 135 min, and reached a threefold higher level postsurgery versus presurgery.

Figure 2

Values are reported as the mean (SEM) for counterregulatory hormones, incretin hormones, and HRV during hypoglycemic clamp presurgery and postsurgery. *Significant difference. Target glucose levels during clamp are shown on top. Insets: AUChypo diagrams. A: Glucagon. B: Cortisol. C: Epinephrine. D: Norepinephrine. E: GH. F: HRV analysis; PLF/PHF ratio (log), shaded area is the SEM. Note the marked reduction of the response during postsurgery clamp, reflecting a downregulated sympathetic nervous response. G: Total GLP-1. H: Total GIP. Pre, presurgery; Post, postsurgery.

Figure 2

Values are reported as the mean (SEM) for counterregulatory hormones, incretin hormones, and HRV during hypoglycemic clamp presurgery and postsurgery. *Significant difference. Target glucose levels during clamp are shown on top. Insets: AUChypo diagrams. A: Glucagon. B: Cortisol. C: Epinephrine. D: Norepinephrine. E: GH. F: HRV analysis; PLF/PHF ratio (log), shaded area is the SEM. Note the marked reduction of the response during postsurgery clamp, reflecting a downregulated sympathetic nervous response. G: Total GLP-1. H: Total GIP. Pre, presurgery; Post, postsurgery.

Table 3

Counterregulatory hormones and lipolytic markers during hypoglycemic clamp

PresurgeryPostsurgery
ΔGlucagon (pmol/L) 30.4 (19.2) 15.2 (10.2)**
AUChypo glucagon (pmol/L/min) 2,130 (860) 1,080 (480)***
ΔCortisol (nmol/L) 392 (195) 300 (178)*
AUChypo cortisol (nmol/L/min) 28,940 (6,740) 21,250 (5,610)**
ΔGH (μg/L) 7.0 (4.2) 14.1 (8.9)*
AUChypo GH (μg/L/min) 271 (122) 436 (281)*
ΔEpinephrine (nmol/L) 2.8 (1.2) 2.2 (1.0)A
AUChypo epinephrine (nmol/L/min) 130 (62) 89 (36)B
ΔNorepinephrine (nmol/L) 1.3 (0.8) 0.9 (0.6)
AUChypo norepinephrine (nmol/L/min) 146 (50) 113 (42)*
ΔGLP-1 (pmol/L) 29 (25) 18 (15)
AUChypo GLP-1 (pmol/L/min) 2,620 (2,160) 1,250 (1,190)**
ΔGIP (pg/mL) 420 (44) 14 (11)*
AUChypo GIP (pg/mL/min) 4,690 (2,440) 2,910 (980)*
AUChypo FFAs (μmol/L/min) 1,720 (830) 800 (790)**
AUChypo glycerol (μmol/L/min) 1,370 (460) 810 (470)**
PresurgeryPostsurgery
ΔGlucagon (pmol/L) 30.4 (19.2) 15.2 (10.2)**
AUChypo glucagon (pmol/L/min) 2,130 (860) 1,080 (480)***
ΔCortisol (nmol/L) 392 (195) 300 (178)*
AUChypo cortisol (nmol/L/min) 28,940 (6,740) 21,250 (5,610)**
ΔGH (μg/L) 7.0 (4.2) 14.1 (8.9)*
AUChypo GH (μg/L/min) 271 (122) 436 (281)*
ΔEpinephrine (nmol/L) 2.8 (1.2) 2.2 (1.0)A
AUChypo epinephrine (nmol/L/min) 130 (62) 89 (36)B
ΔNorepinephrine (nmol/L) 1.3 (0.8) 0.9 (0.6)
AUChypo norepinephrine (nmol/L/min) 146 (50) 113 (42)*
ΔGLP-1 (pmol/L) 29 (25) 18 (15)
AUChypo GLP-1 (pmol/L/min) 2,620 (2,160) 1,250 (1,190)**
ΔGIP (pg/mL) 420 (44) 14 (11)*
AUChypo GIP (pg/mL/min) 4,690 (2,440) 2,910 (980)*
AUChypo FFAs (μmol/L/min) 1,720 (830) 800 (790)**
AUChypo glycerol (μmol/L/min) 1,370 (460) 810 (470)**

Values are reported as the mean (SD). Δ, difference between initial and peak level.

AP = 0.09.

BP = 0.07.

*P < 0.05; **P < 0.01; ***P < 0.001.

Incretin Hormones

Plasma levels of incretin hormones GLP-1 and GIP are shown in Table 3 and Fig. 2. Both hormones rose during the hypoglycemic part of the clamps. The responses were significantly attenuated postsurgery versus presurgery.

FFAs and Glycerol

FFAs and glycerol exhibited equal fasting levels presurgery and postsurgery. The levels fell, FFAs relatively more than glycerol, during the hyperinsulinemic-hypoglycemic clamps. The nadir levels were lower postsurgery versus presurgery (Fig. 3 and Table 3).

Figure 3

Values are reported as the mean (SEM) levels of lipolytic markers during hypoglycemic clamp presurgery and postsurgery. *Significant difference. Target glucose levels during clamp are shown on top. A: FFAs. B: Glycerol. Pre, presurgery; Post, postsurgery.

Figure 3

Values are reported as the mean (SEM) levels of lipolytic markers during hypoglycemic clamp presurgery and postsurgery. *Significant difference. Target glucose levels during clamp are shown on top. A: FFAs. B: Glycerol. Pre, presurgery; Post, postsurgery.

HRV

When comparing HRV presurgery and postsurgery, there were significant increases in PTOT (total variability measure) and spectral components (PLF, PHF) during both euglycemia and hypoglycemia (Table 4). PLF/PHF ratio, a measure of sympathetic/parasympathetic balance, showed less of an increase from the euglycemic part of the clamp to the hypoglycemic part after surgery compared with before surgery (Fig. 2). The interbeat R-R interval was longer postsurgery versus presurgery, corresponding to the decrease in heart rate, both during euglycemia and hypoglycemia.

Table 4

HRV analysis

PreoperativePostoperative
Normoglycemia
 RR (s) 0.92 (0.04) 1.08 (0.01)***
 PTOT (ms2, log) 3.64 (0.05) 3.79 (0.03)***
 PLF (ms2, log) 3.11 (0.05) 3.21 (0.03)**
 PHF (ms2, log) 2.88 (0.12) 3.02 (0.03)***
 PLF/PHF ratio (log) 0.23 (0.03) 0.19 (0.03)
Hypoglycemia
 RR (s) 0.89 (0.04) 0.99 (0.01)***
 PTOT (ms2, log) 3.57 (0.06) 3.77 (0.04)***
 PLF (ms2, log) 3.01 (0.06) 3.13 (0.04)**
 PHF (ms2, log) 2.66 (0.07) 2.89 (0.05)***
 PLF/PHF ratio (log) 0.36 (0.10) 0.25 (0.03)***
Change from normoglycemia to hypoglycemia
 RR (s) −0.03 (0.02) −0.08 (0.01)***
 PTOT (ms2, log) −0.07 (0.06) −0.01 (0.03)
 PLF (ms2, log) −0.09 (0.07) −0.07 (0.04)
 PHF (ms2, log) −0.23 (0.07) −0.14 (0.04)*
 PLF/PHF ratio (log) 0.14 (0.05) 0.07 (0.03)*
PreoperativePostoperative
Normoglycemia
 RR (s) 0.92 (0.04) 1.08 (0.01)***
 PTOT (ms2, log) 3.64 (0.05) 3.79 (0.03)***
 PLF (ms2, log) 3.11 (0.05) 3.21 (0.03)**
 PHF (ms2, log) 2.88 (0.12) 3.02 (0.03)***
 PLF/PHF ratio (log) 0.23 (0.03) 0.19 (0.03)
Hypoglycemia
 RR (s) 0.89 (0.04) 0.99 (0.01)***
 PTOT (ms2, log) 3.57 (0.06) 3.77 (0.04)***
 PLF (ms2, log) 3.01 (0.06) 3.13 (0.04)**
 PHF (ms2, log) 2.66 (0.07) 2.89 (0.05)***
 PLF/PHF ratio (log) 0.36 (0.10) 0.25 (0.03)***
Change from normoglycemia to hypoglycemia
 RR (s) −0.03 (0.02) −0.08 (0.01)***
 PTOT (ms2, log) −0.07 (0.06) −0.01 (0.03)
 PLF (ms2, log) −0.09 (0.07) −0.07 (0.04)
 PHF (ms2, log) −0.23 (0.07) −0.14 (0.04)*
 PLF/PHF ratio (log) 0.14 (0.05) 0.07 (0.03)*

Values are given as the mean (SEM). Spectral indices are log-transformed. Hypoglycemia, 90–165 min; normoglycemia, 0–60 min; RR, mean interbeat R-R interval. Results indicate higher parasympathetic activity during normoglycemia postsurgery and lower sympathetic response to hypoglycemia postsurgery.

*P < 0.05; **P < 0.01; ***P < 0.001.

In this study, we found that GBP surgery is followed by reduced symptoms and responses in classic counterregulatory hormones and autonomic nervous outflow during hypoglycemia. GLP-1 and GIP secretion rose during hypoglycemia, implicating a role of the incretins in counterregulation.

The glucagon, cortisol, catecholamine, and incretin responses to hypoglycemia were all attenuated postsurgery and showed a similar pattern with later and lower responses to hypoglycemia at the post-GBP examinations. GH, like the other counterregulatory hormones, exhibited a later response postsurgery compared with presurgery. During the postsurgery clamp, however, the magnitude of the response was higher than during the presurgery clamp. This may nonetheless be attenuated, in light of the participants’ loss of weight after surgery. GH levels are suppressed in obesity (21), and Corneli et al. (22) found a mean GH response of ∼30 μg/L in subjects with a BMI of ∼30 kg/m2 who were subjected to a GH-releasing hormone-arginine test compared with the rise to 15 μg/L during postsurgery hypoglycemia in the current study (BMI 30.1 kg/m2).

Insulin levels during clamps were ∼25% lower postsurgery versus presurgery, and the absolute insulin amount infused was ∼12% lower after surgery (data not shown), indicating increased insulin clearance, and more so if adjustments to body surface are performed. The difference in insulin concentration was not correlated with changes in hormonal responses (data not shown). The findings are in accordance with those of previous reports, and a more effective hepatic clearance after bariatric surgery has been proposed (8,20).

The nadir levels of FFAs and glycerol were lower postsurgery versus presurgery, reflecting the composite effects of increased insulin sensitivity; reduced levels of counterregulatory hormones, in particular catecholamines, glucagon, and cortisol; and attenuation of the sympathetic nervous response (see paragraph below). Sympathetic activity in the adipose tissue can stimulate lipolysis directly via norepinephrine release (reviewed in Bartness et al. [23]).

The HRV results are in accordance with a reduced sympathetic response to hypoglycemia postsurgery, which could contribute to the delayed and attenuated catecholamine levels and lipolysis. In a previous study (24), a rapid improvement in vasoreactivity and a reduction of heart rate were observed, indicating a reduced sympathetic activity after GBP.

Presurgery, GLP-1 levels doubled during the hypoglycemic phase, an increase of the same order as the response to hyperglycemia after a mixed meal in healthy control subjects (13). This is, however, less than the marked increase in GLP-1 levels typically seen during the postprandial hyperglycemic phase postsurgery (25). GLP-1 level has a role in glucagon secretion, and it may influence the α-cell either directly or via indirect mechanisms like insulin or autonomic nervous control (26). In fact, the effects on both insulin and glucagon secretion may be mediated primarily via nervous system circuits (27). There are data suggesting an effect of GLP-1 analogs on increasing glucagon secretion during hypoglycemia (28), an action similar to that of GIP (14). In a previous study (14), when GIP was infused in physiological doses during hypoglycemia, the glucagon level rose 1.5 times more than with saline infusion.

In patients with diabetes treated with insulin, hypoglycemia is known to lower the threshold for counterregulatory hormonal responses and symptoms (29). Resetting of the hypoglycemia threshold is also known to occur in pregnancy (30) and has been described in healthy subjects after exercise (31). Boyle et al. (32) kept healthy subjects in a hyperinsulinemic-hypoglycemic clamp (glucose 2.9 mmol/L [52 mg/dL]) for 4 consecutive days and reported that on day 1 the threshold for cognitive impairment was 3.05 mmol/L (55 mg/dL) and for symptoms 3.6 mmol/L (65 mg/dL), whereas it decreased to 2.5 mmol/L (45 mg/dL) for both on the final day. Collectively, previous reports and the present data illustrate a remarkable ability of the brain to adapt to lower glucose levels in different physiological settings. The potential adverse effects of an asymptomatic low glucose level have not been well established.

Our present data show an attenuated hypoglycemic response in multiple neuroendocrine pathways after GBP surgery. This indicates that glucose sensing and possibly glucose utilization in the brain have been augmented, but the underlying mechanisms need to be further characterized. Glucokinase activity in ventromedial hypothalamus modulates the counterregulatory responses, and an increased activity attenuates hormonal responses to hypoglycemia (33). An increase in gene expression for glucokinase, GLUT2, and GLP-1 receptor in the hypothalamus has been reported in food-restricted rats (34). Possibly, increased brain glucose uptake leads to an enhanced satiety signal in proopiomelanocortin neurons in the hypothalamus (35) and contributes to the weight maintenance seen in patients who have undergone GBP surgery.

The current study is limited by the relatively few participants. Moreover, the hypoglycemia was induced under experimental circumstances and not during real-life conditions, when the insulin concentration would drop during hypoglycemia. However, the participants in the current study closely resemble the average patient after GBP surgery (1,36) in that they were aged 43 years, two of three were women, and they had lost ∼10 BMI units. The activity level of participants was not known.

In conclusion, we found that GBP surgery is followed by attenuated symptoms, counterregulatory hormonal responses, and sympathetic nervous activation during hypoglycemia. We suggest that such adaptive mechanisms contribute to the occurrence of asymptomatic hypoglycemia and to the prevention of type 2 diabetes after GBP surgery.

Acknowledgments. The authors thank Jan Hall for invaluable work with the clamps and Prasad Kamble, Cherno Sidibeh, Caroline Moberg, Lovisa Nordlinder, and Maria Joao Pereira for invaluable assistance during clamps and laboratory work (all from the Department of Medical Sciences, Uppsala University). The authors also thank Marcus Karlsson (Department of Radiation Sciences, Biomedical Engineering, Umeå University) for analysis of the electrocardiogram recordings and calculation of the HRV indices.

Funding. This study was funded by grants from the Research Fund of the Swedish Diabetes Association, Exodiab, Ernfors Foundation, and ALF (Swedish Government Research Fund).

Duality of Interest. No potential conflicts of interest relevant to this article were reported.

Author Contributions. N.A., F.A.K., and J.W.E. designed the study; researched the data; and wrote, revised, and approved the manuscript. J.L.B., M.S., and U.W. researched the data and revised and approved the manuscript. N.A. is the guarantor of this work and, as such, had full access to all the data in the study and takes responsibility for the integrity of the data and the accuracy of the data analysis.

Prior Presentation. Parts of this study were presented in poster form at the 76th Scientific Sessions of the American Diabetes Association, New Orleans, LA, 10–14 June 2016.

1.
Ribaric
G
,
Buchwald
JN
,
McGlennon
TW
.
Diabetes and weight in comparative studies of bariatric surgery vs conventional medical therapy: a systematic review and meta-analysis
.
Obes Surg
2014
;
24
:
437
455
[PubMed]
2.
Falkén
Y
,
Hellström
PM
,
Holst
JJ
,
Näslund
E
.
Changes in glucose homeostasis after Roux-en-Y gastric bypass surgery for obesity at day three, two months, and one year after surgery: role of gut peptides
.
J Clin Endocrinol Metab
2011
;
96
:
2227
2235
[PubMed]
3.
Brolin
RE
,
Robertson
LB
,
Kenler
HA
,
Cody
RP
.
Weight loss and dietary intake after vertical banded gastroplasty and Roux-en-Y gastric bypass
.
Ann Surg
1994
;
220
:
782
790
[PubMed]
4.
Mathes
CM
,
Letourneau
C
,
Blonde
GD
,
le Roux
CW
,
Spector
AC
.
Roux-en-Y gastric bypass in rats progressively decreases the proportion of fat calories selected from a palatable cafeteria diet
.
Am J Physiol Regul Integr Comp Physiol
2016
;
310
:
R952
R959
[PubMed]
5.
Abrahamsson
N
,
Edén Engström
B
,
Sundbom
M
,
Karlsson
FA
.
Hypoglycemia in everyday life after gastric bypass and duodenal switch
.
Eur J Endocrinol
2015
;
173
:
91
100
[PubMed]
6.
Goldfine
AB
,
Mun
EC
,
Devine
E
, et al
.
Patients with neuroglycopenia after gastric bypass surgery have exaggerated incretin and insulin secretory responses to a mixed meal
.
J Clin Endocrinol Metab
92
:
4678
4685
7.
Scavini
M
,
Pontiroli
AE
,
Folli
F
.
Asymptomatic hyperinsulinemic hypoglycemia after gastric banding
.
N Engl J Med
2005
;
353
:
2822
2823
[PubMed]
8.
Guldstrand
M
,
Ahren
B
,
Wredling
R
,
Backman
L
,
Lins
PE
,
Adamsson
U
.
Alteration of the counterregulatory responses to insulin-induced hypoglycemia and of cognitive function after massive weight reduction in severely obese subjects
.
Metabolism
2003
;
52
:
900
907
9.
Watts
AG
,
Donovan
CM
.
Sweet talk in the brain: glucosensing, neural networks, and hypoglycemic counterregulation
.
Front Neuroendocrinol
2010
;
31
:
32
43
[PubMed]
10.
Cryer P. Hypoglycemia During Therapy of Diabetes, Endotext [Internet], 2015. Available from http://www.ncbi.nlm.nih.gov/books/NBK279100/. Accessed 29 April 2016
11.
Burcelin
R
,
Dolci
W
,
Thorens
B
.
Portal glucose infusion in the mouse induces hypoglycemia: evidence that the hepatoportal glucose sensor stimulates glucose utilization
.
Diabetes
2000
;
49
:
1635
1642
[PubMed]
12.
Rocca
AS
,
Brubaker
PL
.
Role of the vagus nerve in mediating proximal nutrient-induced glucagon-like peptide-1 secretion
.
Endocrinology
1999
;
140
:
1687
1694
[PubMed]
13.
Dirksen
C
,
Jørgensen
NB
,
Bojsen-Møller
KN
, et al
.
Gut hormones, early dumping and resting energy expenditure in patients with good and poor weight loss response after Roux-en-Y gastric bypass
.
Int J Obes
2013
;
37
:
1452
1459
[PubMed]
14.
Christensen
M
,
Vedtofte
L
,
Holst
JJ
,
Vilsbøll
T
,
Knop
FK
.
Glucose-dependent insulinotropic polypeptide: a bifunctional glucose-dependent regulator of glucagon and insulin secretion in humans
.
Diabetes
2011
;
60
:
3103
3109
[PubMed]
15.
Norjavaara
E
,
Ericsson
H
,
Sjöberg
F
, et al
.
Glucokinase activators AZD6370 and AZD1656 do not affect the central counterregulatory response to hypoglycemia in healthy males
.
J Clin Endocrinol Metab
2012
;
97
:
3319
3325
[PubMed]
16.
Deary
IJ
,
Hepburn
DA
,
MacLeod
KM
,
Frier
BM
.
Partitioning the symptoms of hypoglycaemia using multi-sample confirmatory factor analysis
.
Diabetologia
1993
;
36
:
771
777
[PubMed]
17.
Lindmark
S
,
Wiklund
U
,
Bjerle
P
,
Eriksson
JW
.
Does the autonomic nervous system play a role in the development of insulin resistance? A study on heart rate variability in first-degree relatives of Type 2 diabetes patients and control subjects
.
Diabet Med
2003
;
20
:
399
405
[PubMed]
18.
Wiklund
U
,
Hörnsten
R
,
Karlsson
M
,
Suhr
OB
,
Jensen
SM
.
Abnormal heart rate variability and subtle atrial arrhythmia in patients with familial amyloidotic polyneuropathy
.
Ann Noninvasive Electrocardiol
2008
;
13
:
249
256
[PubMed]
19.
Wood
S
.
Generalized Additive Models: An Introduction With R
.
Boca Raton, FL
,
Chapman and Hall/CRC
,
2006
20.
Bojsen-Møller
KN
,
Dirksen
C
,
Jørgensen
NB
, et al
.
Increased hepatic insulin clearance after Roux-en-Y gastric bypass
.
J Clin Endocrinol Metab
2013
;
98
:
E1066
E1071
[PubMed]
21.
Edén Engström
B
,
Burman
P
,
Holdstock
C
,
Ohrvall
M
,
Sundbom
M
,
Karlsson
FA
.
Effects of gastric bypass on the GH/IGF-I axis in severe obesity—and a comparison with GH deficiency
.
Eur J Endocrinol
2006
;
154
:
53
59
[PubMed]
22.
Corneli
G
,
Di Somma
C
,
Baldelli
R
, et al
.
The cut-off limits of the GH response to GH-releasing hormone-arginine test related to body mass index
.
Eur J Endocrinol
2005
;
153
:
257
264
[PubMed]
23.
Bartness
TJ
,
Liu
Y
,
Shrestha
YB
,
Ryu
V
.
Neural innervation of white adipose tissue and the control of lipolysis
.
Front Neuroendocrinol
2014
;
35
:
473
493
[PubMed]
24.
Lind
L
,
Zethelius
B
,
Sundbom
M
,
Edén Engström
B
,
Karlsson
FA
.
Vasoreactivity is rapidly improved in obese subjects after gastric bypass surgery
.
Int J Obes
2009
;
33
:
1390
1395
[PubMed]
25.
Holst
JJ
,
Christensen
M
,
Lund
A
, et al
.
Regulation of glucagon secretion by incretins
.
Diabetes Obes Metab
2011
;
13
(
Suppl. 1
):
89
94
26.
Gotoh
K
,
Masaki
T
,
Chiba
S
, et al
.
Hypothalamic brain-derived neurotrophic factor regulates glucagon secretion mediated by pancreatic efferent nerves
.
J Neuroendocrinol
2013
;
25
:
302
311
[PubMed]
27.
Balkan
B
,
Li
X
.
Portal GLP-1 administration in rats augments the insulin response to glucose via neuronal mechanisms
.
Am J Physiol Regul Integr Comp Physiol
2000
;
279
:
R1449
R1454
[PubMed]
28.
Degn
KB
,
Brock
B
,
Juhl
CB
, et al
.
Effect of intravenous infusion of exenatide (synthetic exendin-4) on glucose-dependent insulin secretion and counterregulation during hypoglycemia
.
Diabetes
2004
;
53
:
2397
2403
[PubMed]
29.
Berlin
I
,
Grimaldi
A
,
Thervet
F
,
Puech
AJ
.
Hypoglycaemia unawareness
.
Lancet
1987
;
2
:
966
[PubMed]
30.
Diamond
MP
,
Reece
EA
,
Caprio
S
, et al
.
Impairment of counterregulatory hormone responses to hypoglycemia in pregnant women with insulin-dependent diabetes mellitus
.
Am J Obstet Gynecol
1992
;
166
:
70
77
31.
Galassetti
P
,
Mann
S
,
Tate
D
, et al
.
Effects of antecedent prolonged exercise on subsequent counterregulatory responses to hypoglycemia
.
Am J Physiol Endocrinol Metab
2001
;
280
:
E908
E917
[PubMed]
32.
Boyle
PJ
,
Nagy
RJ
,
O’Connor
AM
,
Kempers
SF
,
Yeo
RA
,
Qualls
C
.
Adaptation in brain glucose uptake following recurrent hypoglycemia
.
Proc Natl Acad Sci U S A
1994
;
91
:
9352
9356
[PubMed]
33.
Levin
BE
,
Becker
TC
,
Eiki
J
,
Zhang
BB
,
Dunn-Meynell
AA
.
Ventromedial hypothalamic glucokinase is an important mediator of the counterregulatory response to insulin-induced hypoglycemia
.
Diabetes
2008
;
57
:
1371
1379
[PubMed]
34.
Zhou
J
,
Roane
DS
,
Xi
X
, et al
.
Short-term food restriction and refeeding alter expression of genes likely involved in brain glucosensing
.
Exp Biol Med (Maywood)
2003
;
228
:
943
950
[PubMed]
35.
Larsen
PJ
,
Tang-Christensen
M
,
Jessop
DS
.
Central administration of glucagon-like peptide-1 activates hypothalamic neuroendocrine neurons in the rat
.
Endocrinology
1997
;
138
:
4445
4455
[PubMed]
36.
Scandinavian Obesity Surgery Registry. SOReg. Annual Report 2014 [Swedish, with summary in English] [Internet], 2014. Available from http://www.ucr.uu.se/soreg/index.php/arsrapporter. Accessed 8 January 2016
Readers may use this article as long as the work is properly cited, the use is educational and not for profit, and the work is not altered. More information is available at http://diabetesjournals.org/site/license.
